Single spin exact gradients for the optimization of complex pulses and pulse sequences
Stella Slad, Burkhard Luy
TL;DR
This paper introduces a faster method to calculate exact gradients for optimizing magnetic resonance pulses, significantly speeding up the process.
Contribution
The novel contribution is the derivation of highly efficient analytical gradient solutions for single spin systems with various controls.
Findings
Analytical gradients are calculated two orders of magnitude faster than previous methods.
The method is applied to broadband pulses for biomolecular applications involving 15N, 13C, and 19F.
The approach includes pseudo controls with holonomic constraints using a continuous hyperbolic tangent function.
Abstract
The efficient computer optimization of magnetic resonance pulses and pulse sequences involves the calculation of a problem-adapted cost function as well as its gradients with respect to all controls applied. The gradients generally can be calculated as a finite difference approximation, as a GRAPE approximation, or as an exact function, e.g. by the use of the augmented matrix exponentiation, where the exact gradient should lead to best optimization convergence. The calculation of the exact gradient, on the other hand, is computationally demanding and is one of the determining factors for the overall time needed for optimization. Its improved calculation, e.g. by faster analytical solutions, is therefore highly desired. The majority of pulse optimizations involve a single spin 1/2, for which propagation is either represented by 3D-rotations or quaternions. Here, highly efficient…
