Structural basis for human DPP4 receptor recognition by MERS-like coronaviruses 2014-422 and GX2012

TL;DR

This study reveals how two MERS-like bat coronaviruses interact with a human receptor, providing insights into their potential to infect humans.

Contribution

The study provides novel structural insights into how MERS-like coronaviruses bind to the human DPP4 receptor through cryo-EM analysis.

Findings

The spike proteins of 2014-422 and GX2012 adopt a more compact conformation compared to MERS-CoV.

An additional residue at position 514 alters the binding angle of the receptor-binding domain to hDPP4.

GX2012 efficiently enters human cells, while 2014-422 shows reduced entry efficiency due to structural differences.

Abstract

Since its emergence in 2012, Middle East respiratory syndrome coronavirus (MERS-CoV) has posed a significant threat to human health. Recently, novel MERS-like coronaviruses with the potential for cross-species transmission have been identified. In this study, we focused on two newly isolated bat strains with putative health concern: BatCoV/Ii/GD/2014-422 (2014-422) and BtTp-BetaCoV/GX2012 (GX2012). We determined the cryo-EM structures of the spike glycoprotein trimer in the closed state for these two viruses. These structures display a more compact conformation compared to MERS-CoV spike. Biochemical characterization demonstrates that the spike receptor-binding domains (RBDs) of 2014-422 and GX2012 can bind to human dipeptidyl peptidase 4 (hDPP4). To investigate the structural determinants of pseudovirus infection, we solved the cryo-EM structures of 2014-422 RBD-hDPP4 and GX2012 RBD-hDPP4 complexes. The binding mode of the complex is conserved, but the angle of the RBD binding undergoes significant tilting. Detailed structural analysis reveals that an additional residue at position 514 interacts with the N321 glycan in hDPP4, altering the binding angle and thus influencing receptor recognition. These findings offer valuable insights into the receptor utilization of Merbecovirus and provide a structural basis for future surveillance efforts.

Two MERS-like coronaviruses, BatCoV/Ii/GD/2014-422 (2014-422) and BtTp-BetaCoV/GX2012 (GX2012), have recently emerged as potential zoonotic threats. In this study, we provide a detailed structural analysis of these two viruses, focusing on their spike proteins and interactions with human Dipeptidyl Peptidase 4 (hDPP4), the receptor used by MERS-CoV. Using cryo-electron microscopy (cryo-EM), we determined high-resolution structures of 2014-422 and GX2012 spike glycoproteins in their closed conformations. Our results show that GX2012 mediates efficient pseudovirus entry into human cells, whereas 2014-422 shows markedly reduced entry efficiency. This difference is linked to structural variations, including a unique residue at position 514 in both viruses that affects the RBD binding angle and receptor recognition. Together, these findings provide key insights into the structural basis of receptor usage by MERS-like coronaviruses and suggest that HKU4r-CoVs may acquire the ability to infect human cells through two evolutionary routes: within bats and through pangolins as intermediate hosts.

Figures
