P-615. Encapsulation of Disease-Causing and Commensal Streptococcus Mitis and Other Viridans Streptococci

TL;DR

This study uses electron microscopy to show that disease-causing and commensal Streptococcus mitis and related species have capsules, which may contribute to their role in pneumonia.

Contribution

First electron microscopy demonstration of capsules in a series of viridans streptococci, including disease-causing and commensal isolates.

Findings

MGNPS isolates were found to be encapsulated using ruthenium red/lysine acetate fixation, unlike standard uranyl acetate fixation.

No difference in capsule appearance was observed between disease-causing and commensal MGNPS strains within a species.

One S. mitis isolate was predicted as pneumococcus serotype 5 via CDC bioinformatics and showed a thick capsule.

Abstract

Viridans streptococci, specifically Streptococcus mitis, S. infantis and S. oralis, have been shown to cause bacteremia in immunocompromised hosts and, more recently, to be important causes of community-acquired pneumonia. These mitis group non-pneumococcal streptococci (MGNPS) often have capsular (cps) operons resembling those in pneumococci, and some may express cps-generated polysaccharides that antigenically cross-react with pneumococcal serotypes but, to date, a series of MGNPS isolates has not been studied by electron microscopy (EM) for the presence of a capsule.Transmission electron microscopy images after standard uranyl acetate fixationA. Streptococcus mitis showing no capsule; and B. S. pneumoniae serotype 5, showing clear evidence of a capsule. Scale bar 200 nmTransmission electron microscopy images after ruthenium red/lysine acetate fixationA. S. pneumoniae, type 15C, sputum isolate, patient with pneumonia. B. S. mitis, sputum isolate, patient with pneumonia. C. S. mitis commensal isolate from the mouth of a healthy adult. D. S. oralis, sputum isolate, patient with pneumonia; E. S. oralis, commensal isolate from the mouth of a healthy adult. F. S. mitis, commensal isolate with thick capsule, predicted as type 5 through the CDC bioformatics pipeline.

Transmission electron microscopy images after standard uranyl acetate fixation

A. Streptococcus mitis showing no capsule; and B. S. pneumoniae serotype 5, showing clear evidence of a capsule. Scale bar 200 nm

Transmission electron microscopy images after ruthenium red/lysine acetate fixation

A. S. pneumoniae, type 15C, sputum isolate, patient with pneumonia. B. S. mitis, sputum isolate, patient with pneumonia. C. S. mitis commensal isolate from the mouth of a healthy adult. D. S. oralis, sputum isolate, patient with pneumonia; E. S. oralis, commensal isolate from the mouth of a healthy adult. F. S. mitis, commensal isolate with thick capsule, predicted as type 5 through the CDC bioformatics pipeline.

We studied 21 MGNPS; 11 were isolated from sputum and determined to have caused pneumonia, 3 were isolated from blood, and 7 were commensal isolates cultured from the oral cavity of healthy adults. Isolates were fixed with two different protocols and examined by transmission EM.

EM after standard fixation and staining with uranyl acetate did not show capsules in MGNPS but clearly showed capsules in pneumococci (Figure 1A and 1B). In contrast, all MGNPS isolates studied after fixation with ruthenium red and lysine acetate were shown to be encapsulated. S. pneumoniae had the densest encapsulation (Fig 2A) followed by S. mitis (Fig 2B, 2C), S. infantis (not shown) and S. oralis (Fig 2D, 2E); in these MGNPS capsular material was more thinly spread over the bacterial surfaces. Within a species, there appeared to be no difference in capsules between disease-causing and commensal MGNPS strains. One S. mitis that identified as pneumococcus serotype 5 via the CDC bioinformatics platform had a thick capsule (Fig 1F) although it was not as dense as that seen on S. pneumoniae.

This is the first EM demonstration of capsules on a randomly selected series of viridans streptococci. Importantly, within a species, there was no apparent difference in the capsules on disease-causing vs. commensal isolates. MGNPS are implicated as a cause in about 20% of cases of community-acquired pneumonia. We hypothesize that aspiration of a sufficiently large inoculum of relatively avirulent organisms in a person who has reduced clearance mechanisms or poorly functioning PMNs causes pneumonia. The precise role of capsule in the pathogenesis of pneumonia due to MGNPS remains to be elucidated.

All Authors: No reported disclosures
