Assessment of Apical Patency in Permanent First Molars Using Deep Learning on CBCT-Derived Pseudopanoramic Images: A Retrospective Study

TL;DR

This study uses deep learning to assess the apical patency of permanent first molars from CBCT-derived pseudopanoramic images, showing promising accuracy for dental applications.

Contribution

The novel use of CNNs for automated apical patency assessment in dental imaging is demonstrated with high accuracy.

Findings

The CNN achieved an overall accuracy of 0.80 in assessing apical patency.

Precision and recall scores were 0.79 for open roots and 0.81 for closed roots.

The AUC of the ROC curve was 0.80, indicating strong model performance.

Abstract

Background: Assessment of root development and apical closure is critical in dental disciplines, including endodontics, trauma management, and age estimation. This study aims to leverage advances in deep learning Convolutional Neural Networks (CNNs) to automatically evaluate the apical region status of permanent first molars, highlighting a digital health application of AI in dentistry. Methods: In this retrospective study, 262 Cone Beam Computed Tomography (CBCT) scans were reviewed, and 147 anonymized dental images were cropped from pseudopanoramic radiographs, including standard measurements. Tooth regions were resized to 471 × 1075 pixels and split into training (80%) and test (20%) sets. CNN performance was assessed using accuracy, precision, recall, F1-score, and receiver operating characteristic (ROC) curves with area under the curve (AUC), demonstrating AI-based image analysis in a dental context. Results: Precision, recall, and F1-scores were 0.79 for open roots and 0.81 for closed roots, with a macro average of 0.80 across all metrics. The overall accuracy and AUC were also 0.80. Conclusions: These results suggest that CNNs can be effectively used to assess apical patency from ROI images derived from pseudopanoramic radiographs.

Figures
