Entropy-Inspired Aperture Optimization in Fourier Optics

TL;DR

This paper introduces a new method to optimize image quality in optical systems by using entropy to find the best aperture setting.

Contribution

A novel analytical technique using entropy to determine optimal apertures in 4f imaging systems is proposed.

Findings

Optimal aperture region maximizes imaging entropy for static and quasi-static objects.

The method is robust and applicable to various optical imaging devices.

Imaging entropy reflects imperfections in the object being imaged.

Abstract

The trade-off between resolution and contrast is a transcendental problem in optical imaging, spanning from artistic photography to technoscientific applications. To the latter, Fourier-optics-based filters, such as the 4f system, are well-known for their image-enhancement properties, removing high spatial frequencies from an optically Fourier-transformed light signal through simple aperture adjustment. Nonetheless, assessing the contrast–resolution balance in optical imaging remains a challenging task, often requiring complex mathematical treatment and controlled laboratory conditions to match theoretical predictions. With that in mind, we propose a simple yet robust analytical technique to determine the optimal aperture in a 4f imaging system for static and quasi-static objects. Our technique employs the mathematical formalism of the H-theorem, enabling us to directly access the information of an imaged object. By varying the aperture at the Fourier plane of the 4f system, we have empirically found an optimal aperture region where the imaging entropy is maximum, given that the object is fitted to the imaged area. At that region, the image is lit and well-resolved, and no further aperture decrease improves that, as information of the whole assembly (object plus imaging system) is maximum. With that analysis, we have also been able to investigate how the imperfections in an object affect the entropy during its imaging. Despite its simplicity, our technique is generally applicable and passable for automation, making it interesting for many imaging-based optical devices.
