Deep spatial sequencing revealing differential immune responses in human hepatocellular carcinoma

TL;DR

Deep spatial sequencing reveals that HCC cells show stronger immune responses compared to benign liver cells, suggesting differences in immune interactions.

Contribution

Ultra-depth spatial transcriptome sequencing uncovers novel immune response patterns in HCC compared to benign liver tissues.

Findings

HCC showed 16 distinct spatial expression clusters with unique gene patterns, unlike benign tissues.

HCC cells exhibited more intense and broader immune responses compared to benign liver cells.

Standard-depth sequencing missed significant genes and pathways identified through ultra-depth sequencing.

Abstract

Hepatocellular carcinoma (HCC) is one of the most lethal cancers for humans. HCC is highly heterogeneous. In this study, we performed ultra-depth (∼1 million reads per spot) sequencing of 6,320 spatial transcriptomes on a case of HCC. Sixteen distinct spatial expression clusters were identified. Each of these clusters was spatially contiguous and had distinct gene expression patterns. In contrast, benign liver tissues showed minimal heterogeneity in terms of gene expression. Numerous immune cell-enriched spots were identified in both HCC and benign liver regions. Cells adjacent to these immune cell-enriched spots showed significant alterations in their gene expression patterns. Interestingly, the responses of HCC cells to the nearby immune cells were significantly more intense and broader, while the responses of benign liver cells to immune cells were somewhat narrow and muted, suggesting an innate difference in immune cell activities towards HCC cells in comparison with benign liver cells. However, cell-cell interaction analyses showed significant immune evasion by HCC cancer cells. When standard-depth sequencing was performed, significant numbers of genes and pathways that were associated with these changes disappeared. Qualitative differences in some pathways were also found. These results suggest that deep spatial sequencing may help to uncover previously unidentified mechanisms of liver cancer development.
