A Novel Method for Preparing Uniform Micro-Sized Dry Powder Formulations, Including Aggregation-Controlled VHH

TL;DR

A new method for making uniform antibody powders is developed, which could improve drug delivery and storage.

Contribution

A novel powderization technique using fine droplet drying is introduced for aggregation-controlled VHH formulations.

Findings

Higher flow temperatures during FDD increased VHH aggregation.

VHH powders retained binding activity and showed good inhalation properties.

About 30% of VHHs remained functional after the FDD process.

Abstract

Background: The preparation of antibodies in powder form without changing their physicochemical properties may enable their use in new drug delivery system therapies or non-refrigerated storage. The variable domain of heavy-chain antibodies (VHHs) is more suited for this purpose than that of conventional antibodies because of VHHs’ high thermal stability and ability to refold. Methods: In this report, the fine droplet drying (FDD) process was selected as the powderization technique because of its favorable features, such as mild drying conditions and the generation of uniform particle sizes. The aggregation, binding, particle, and in vitro inhalation properties of the prepared VHH powders (VHHps) were evaluated. Results: The amount of aggregated VHHs present in the VHHps depended on the flow temperature during the FDD process, with higher temperatures yielding a higher aggregation ratio. In contrast, no significant difference in binding activity was observed between each VHHp preparation and the native VHHs. However, this process degraded VHHs or inactivated their function, and ultimately, only about 30% of the original VHHs were functional, whereas the remaining VHHs that were not degraded showed little loss of functionality, even after storage at room temperature for more than two years. Analysis of the VHHp samples revealed that the particles were uniformly spherical with a single-micron size. The VHHps showed fine inhalation properties in the inhalation property test. Conclusions: These findings suggest that the FDD process affords various VHH powder formulations, including pharmaceutical formulations.

Figures
