Peak Age of Information Analysis in Systems with Multiple Time-Correlated Traffic Streams

TL;DR

This paper studies how information freshness is affected in cellular systems with multiple competing traffic streams and different service rules.

Contribution

The study introduces a model for analyzing peak age of information in systems with batch arrivals and service using switched Poisson processes.

Findings

Mean peak age of information behavior varies with service disciplines, but optimal values are service-order insensitive.

Prioritizing one traffic flow can significantly degrade performance of other flows, even with low individual load.

The model can help design packet scheduling strategies for 4G/5G systems handling state update traffic.

Abstract

Nowadays, Internet of Things (IoT) is one of the most dynamically evolving services in the 5G ecosystem. In industrial IoT (IIoT), this service can be utilized to deliver state updates of various equipment to the remote control center for further coordination and maintenance. As a result, one of the critical metrics of interest for such a service is the Age of Information (AoI) and its upper bound—peak AoI (AoI)—characterizing the freshness of information about the state of the systems. In spite of significant attention, these metrics received over the last decade, only little is known regarding the PAoI performance of a single source (e.g., sensor) in the presence of competing traffic from other sources in queuing systems. On top of this, models with batch arrivals and batch services that can be effectively used to represent service performance in modern cellular systems such as 5G New Radio are lacking. In our study, we consider a cellular air interface representing it as a queuing system (QS) in discrete-time with batch arrivals and service and investigate performance of a single (tagged) source in presence of competing traffic from other sources having the same priority, where all the sources are modeled using the switched Poisson process (SPP) characterized by sophisticated correlational properties. We also investigated the impact of several service disciplines on the performance of the tagged source including first-come–first-served (FCFS), last-come–first-served (LCFS), random, and priority-based service. Our results illustrate that, although the qualitative behavior of the mean PAoI is different for different service disciplines, the optimal value of PAoI is insensitive to the choice of the service order. On top of this, we observed that introducing a priority in service to one of the flows may drastically affect the performance of other flows even when the overall load contribution of a single flow is rather limited. Our observations can be utilized to design packet scheduling strategies for 4G/5G cellular systems carrying traffic of state update applications.
