Redescription of the Neotropical genus Agathomerus (Coleoptera, Megalopodidae, Megalopodinae) and description of three new species from Mexico
Abstract
Genes, proteins, chemicals, diseases, species, mutations and cell lines named across the full text — each resolved to its canonical identifier and authoritative record.
Click any figure to enlarge with its caption.
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5Peer Reviews
No public reviews on file for this paper yet. If you reviewed it on a platform where reviews are public (OpenReview, ICLR, NeurIPS, ICML), you can paste yours below so the community can read it here.
Videos
No videos yet. Explain this paper in a talk, walkthrough, or lecture? Add one.
Taxonomy
TopicsColeoptera Taxonomy and Distribution · Scarabaeidae Beetle Taxonomy and Biogeography · Forest Insect Ecology and Management
Introduction
Three genera and 33 species of Megalopodidae are recorded from Mexico (Rodríguez-Mirón 2018; Ordóñez-Reséndiz and López-Pérez 2021); before this work, the genus Agathomerus Lacordaire, 1845 comprised 55 species (Appendix 1), ten of which are recorded in Mexico (Rodríguez-Mirón 2018; Rodríguez‐Mirón et al. 2021). Agathomerus is one of the most diverse genera of Megalopodidae and is distributed from Mexico to Argentina (Rodríguez-Mirón 2018), which follows the typical Neotropical distribution pattern within the Mexican Transition Zone (Halffter 1964, 2003; Halffter and Morrone 2017; Rodríguez-Mirón et al. 2021).
Agathomerus contains the species previously described in Megalopus Fabricius that lack costate elytra and a medial conical tubercle on the metaventrite. Monrós (1947) recognized a high degree of polymorphism among the antennae in the genus; he also mentioned that certain species contained in Agathomerus should be in different genera. Monrós (1947) established five subgenera (Mesagathomerus Monrós, Agathomeroides Monrós, Eugathomerus Monrós and Trichagathomerus Monrós) which comprise the species distributed in Argentina. These subgenera were formed mainly based on antennal shape and length, pronotal shape, and density, type and distribution of pubescence. Pic (1947) created the subgenus Longathomerus Pic, but without indicating diagnostic characters.
Rodríguez-Mirón et al. (2021) performed a phylogenetic analysis of Megalopodidae where Agathomerus was recovered as a polyphyletic group. Agathomerusbivittatus Lacordaire, 1845 was recovered as a sister group of a large part of the tribe Megalopodini. In the same study, A.fasiatus (Dalman, 1823) was found to be closely related to Barticariacyanipes (Clark, 1866) and was consequently transferred to the genus Barticaria Jacoby & Clavareau while some species found in Mexico were shown to be related to Mastostethus Lacordaire. The type species, A.pulcher Lacordaire, 1845, was nested within a clade formed by species of different subgenera, leading to their synonymization under Agathomerus s. str.
This work aims to redefine the genus Agathomerus and illustrate its diagnostic characters. Additionally, three new species of Agathomerus are described.
Material and methods
The specimens examined were obtained on loan from different collections: National Museum of Natural History, Smithsonian Institution, Washington, DC, USA (NMNH, Alexander Konstantinov); Muséum national d’Histoire naturelle, Paris, France (MNHN, Antoine Mantilleri), Natural History Museum, London, UK (NHMUK, Michael Geiser); American Museum of Natural History, New York, USA (AMNH, Lee Herman); Essig Museum of Entomology, University of California, Berkeley, CA, USA (EMEC, Peter T. Oboyski), Colección Coleopterológica de la Facultad de Estudios Superiores Zaragoza, UNAM, Mexico City, Mexico (CCFES-Z, Ma. Magdalena Ordóñez Reséndiz) and Colección Nacional de Insectos Instituto de Biología, Universidad Nacional Autónoma de México, Mexico City, Mexico (CNIN, Santiago Zaragoza Caballero).
Terms for anatomy and male genitalia structures follow Ehara (1954); terms for female genitalia follow Suzuki (1988), Matsumura and Suzuki (2008) and Rodríguez-Mirón et al. (2017). Genitalia were dissected and the tissue was macerated with 10% KOH for 10 minutes. The specimens were examined and measured using a Carl Zeiss Stemi 508 stereomicroscope. Images were taken with an AxiocamMRC5 camera attached to a Zeiss Axio Zoom V16 microscope with a Plan NeoFluar Z objective and 1×10.25 FWD 56 eyepiece at the Laboratorio de Microscopía y Fotografía de la Biodiversidad II, Instituto de Biología, UNAM, and by using a Canon EOS M6 Mark camera, Laowa FX 65 mm f/2.8 2x macro lens and a StackShot macro-rail. Multi-focus images were combined with Zerene Stacker software.
Results
Megalopodidae Latreille, 1802
Megalopodinae Latreille, 1802
Megalopodini Latreille, 1802
Megalopodina Latreille, 1802
Agathomerus
Taxon classificationAnimaliaColeopteraMegalopodidae
Genus
Lacordaire, 1845
86286066-79A1-5D6C-B23F-CCC872ADEC98
Type species.
Agathomeruspulcher Lacordaire, 1845, designated by Jacoby and Clavareau (1905).
Differential diagnosis.
Agathomerus differs from the other genera of Megalopodina by the spatulate shape of the spiculum gastrale; in the other genera it is forked or straight. Moreover, it is also distinguished by the following character states: mesoscutum apex emarginate, metatarsomeres I–III conical, metatarsomeres V longer than I–III and, usually, tergite II with three sclerotized portions. Whereas in Plesioagathomerus Monrós, Mastostethus and Homalopterus Perty the mesoscutum apex is rounded, metatarsomeres I–III are subcylindrical, metatarsomeres V are as long as I–III (except in Homalopterus where they are variable); in Plesioagathomerus and Homalopterus tergite II has two sclerotized portions and in Mastostethus tergite II is uniformly sclerotized.
In addition, Agathomerus differs from Mastostethus by the generally longer antennae and convex metaventrite. In Mastostethus the antennae are short and the metaventrite has a conical tubercle medially. It is distinguished from Homalopterus by the mandible with a lateral groove, last labial palpomeres fusiform, elytra without costae and long parameres. In Homalopterus the mandibles lack a lateral groove, the last labial palpomeres are bullet-shaped, the elytra is costate and the parameres are short. Agathomerus can be separated from Plesioagathomerus by the abdominal process projected between the metacoxae and by the long empodium. In Plesioagathomerus, the abdominal process is short and not projected between metacoxae, and the empodium is short.
Agathomerus differs from Pseudohomalopterus by the meso- and metaventral processes not joined in lateral view and the emarginate ventral apex of tarsomeres V. In Pseudohomalopterus, the meso- and metaventral processes are joined (as in Mastostethus), and the ventral apex of tarsomeres V is emarginated and notched. Agathomerus is easily distinguished from Barticaria, Bothromegalopus Monrós, and Megalopus by the elongate and robust shape of the body and the subparallel external edges of the elytra. Whereas in Barticaria, the body is compact and subcylindrical; in Megalopus and Bothromegalopus, the elytra are raised behind the scutellum, the elytral suture is depressed, and the body narrows towards the apex (as in Pseudohomalopterus).
Redescription.
Head. Constricted behind eyes; frontal surface along eye margins with ocellate punctures (Figs 1F, 2I); frons variable, impunctate, glabrous. Interocular space usually transverse. Antennae variable in length and shape, usually reaching anterior edge of elytra (Fig. 1A), with 11 antennomeres; scapes subconical; antennomeres II globose; III shorter than scape; V–X articulated laterally; XI usually ovoid; scape and II–IV with scattered setae; setae on V–XI short and dense. Eyes prominent and notched (Figs 1F, 2I). Frontoclypeal groove conspicuous. Clypeus trapezoidal, punctate; surface of disc with erect pubescence, posterior region with a transverse, translucent band; labrum oblong, surface of disc sparsely pubescent, edge densely so. Mandibles triangular, not toothed; external side with groove, punctate, and with procumbent setae. Maxillary palps with 4 palpomeres, I subcylindrical, II clavate, III shorter than II and IV, IV subconical or bullet-shaped. Ligula bilobed. Labial palps with 3 palpomeres, I subcylindrical and very short, II clavate and longer than III, III fusiform and longer than I. Mentum bilobed. Gula trapezoidal, punctate.
AgathomeruspulcherA dorsal view B lateral view C elytral punctation D metaepisternum E mesoventral and metaventral process F frontal view G mesoscutum H pronotum I coxa J dorsal abdomen view K claws L protarsomeres M metatarsomeres N middle lobe O tegmen P spermatheca.
Type specimens and polymorphism among AgathomeruspulcherAA.batesi Baly, type specimen BA.superbus Pic, type specimen CA.bichito Monrós, type specimen D label of type specimen of A.batesiE label of type specimen of A.superbus Pic F label of type specimen of A.bichito Monrós GA.pulcher with elytral disc blue HA.pulcher with elytral disc orange I head orange of A.pulcher.
Thorax. Pronotum trapezoidal (Fig. 1H) or bell-shaped (Figs 3G, 4F, 5F), wider than long; base wider than the anterior margin, with anterolateral projections; surface convex, with a groove (either continuous or discontinuous) on the anterior part; posterior part wider than anterior, usually with posterolateral punctures and wide posterolateral projections; posterior edge beaded, as wide as base of elytra. Procoxal cavities closed, procoxae contiguous, conical, protruding; mesocoxae ovate, below level of mesothorax; metacoxae subquadrate, metaxoxal space narrow. Mesoscutum (Fig. 1G) with stridulatory files; apical region rounded or slightly emarginate. Scutellum subtriangular (Fig. 1G). Elytra with external edges parallel (Fig. 1A); surface slightly convex dorsally, punctate; humeri rounded, projecting anterolaterally. Mesanepisternum flat; meso- and metaventral processes not joined (Fig. 1E). Metaepisternum with anterior part concave (Fig. 1D). Leg pairs progressively longer posteriorly; pro- and mesofemur elongate; metafemur robust, elongate, male with or without ventral projections; metatrochanters truncate; tibiae with a row of denticles dorsally; apophysis long and rounded, apex with 2 spurs; pro- and mesotarsomeres I–III subconical (Fig. 1L); metatarsomeres I–III subcylindrical (Fig. 1M); on each leg tarsomeres IV reduced in size; tarsomeres V curved, dorsal edge mucronate, ventral edge emarginate, metatarsomere V longer than I–III combined; claws bifid; empodia long, with more than three setae (Fig. 1K).
Agathomerusmagdalenae sp. nov. A dorsal view B lateral view C middle lobe D spermatheca E tegmen F head in frontal view G pronotum H metaepisternum.
Agathomerussantiagoi sp. nov. A dorsal view B lateral view C middle lobe D tegmen E frontal view F pronotum G metaepisternum.
Agathomerusespinosaorganistai sp. nov. A dorsal view B lateral view C middle lobe D tegmen E frontal view F pronotum G metaepisternum.
Abdomen. Last spiracle smaller than others (Fig. 1J); pygidium subtriangular (Fig. 1J), apically sparsely punctate and sparsely pubescent; sternite I with anterior edge beaded, abdominal process projected anteriorly between metacoxae; in females, last abdominal ventrite concave apically and, on internal surface, short projection into abdominal cavity.
Male genitalia. Aedeagus: dorsal portion of median lobe membranous; struts and lateral margins of median lobe sclerotized (Fig. 1N); struts articulated with edge of aedeagus. Parameres long, fused (Fig. 1O); tegmen ring lanceolate; roof short (Fig. 1O).
Female genitalia. Spermatheca complex (Fig. 1P); proximal part of spermathecal capsule boomerang-shaped, apex with velum; terminal portion of spermathecal capsule elongate. Sternite VIII bifurcate, apex and base trilobate. Spiculum gastrale straight.
Agathomerus
pulcher
Taxon classificationAnimaliaColeopteraMegalopodidae
Lacordaire
74DE65A7-A471-5AD8-8797-67E430CCD308
Agathomerus pulcher
Lacordaire 1845: 675. Agathomerus batesi Baly, 1859: 199 syn. nov. Agathomerus superbus Pic, 1916: 20 syn. nov. Agathomerus bichito Monrós, 1945: 144 syn. nov. Megalopus injunctus Pic, 1938: 16.
Type material examined.
**Holotype.**Agathomerusbatesi Baly (designated here) (Fig. 2A, D). ♀, pinned. Original label: “Agathomerusbatesi Baly, Lga // type” (NHMUK). **Syntype.**Agathomerussuperbus Pic (designated here) (Fig. 2B, E). Sex?, Glued on cardboard. Original label: “Agathomerus // superfus pic // TYPE // Type // Chachamayo, Pérou, Coll. Le Moult// illegible” (MNHN). **Holotype.**Agathomerusbichito Monrós (Fig. 2C, F). ♀, Glued on cardboard. Original label: “Argentina, Salta, Urundel, Feb., 944, Coll. Monrós // Agathomeruspulcher ssp., bichito mihi, F. Monrós det. 1948 // Holotipo de A.bichito, Monrós // Type NO. 65228, U.S.N.M. // F. Monrós Collection, 1959 // USNMENT, QR 00911326” (NMNH).
Other material examined.
♂, pinned. Original label: “Perou Chanchamayo, Ch O Schunke // F. Monrós ES Collection, 1959”, (NMNH). ♀. Original label: Pucallpa, Loreto, Peru, Nov. 9, 1946, alt 600 ft (NY). ♂. Original label: “Amazones, Tarapote, M. de Mathan, 4^e^trimestre 1885 // Museum Paris Coll. M Pic”, (MNHN). ♀. Original label: “Amazonas, Brazil, Benjamin Constant, Rio Javary, March 1942 // August Rabaut Collector (AMNH); ♀. Same data as preceding “Feb. 15-Mar.15, 1942” (AMNH). ♀, pinned, with genitalia in a separate microvial. Original label: “Peru” // Agathomeruspulcher Lac. Det. A.S. Konstantinov, 2014” (NMNH). ♀, pinned. Original label: “Prov. del Sara, Cent. Bolivia, 450 m, 1909, J. Steinbach // F. Monrós Collection, 1959” (NMNH). ♂, pinned, with genitalia in a separate microvial. Original label: “R.A. Salta Pocitos, I852, Coll. A. Martínez”, (NMNH). ♂, pinned. Original label: “Rurreaabaque Rio Beni Bólivia, W M Mann // F. Monrós Collection, 1959” (NMNH). ♀, pinned. Original label: “Peru: Dpt. Cuzco, Prov. Quispicanchis, Quincemil, 6-11-X-1976, Robert Gordon” (NMNH). ♂/♀, pinned, with genitalia in a separate microvial. Original label: “S^1a^. Paulo d Olivenca, M. de Mathan, Juin Juillet 1883” (MNHN). ♂, pinned. Original label: “Pérou, Moyobamba, M. de Mathan, 1888” (MNHN). ♂, pinned, with genitalia in a separate microvial. Original label: “Pérou Tarapoto, Mai à Aout, 1886, M. de Mathan” (MNHN). ♀, pinned. Original label: “Bolivie, Prov. Cochabamba, P. Germain, 1889” (MNHN). ♀. Original label: “Bolij // Jacoby Coll 1909-28a” (NHMUK).
Diagnosis.
Agathomeruspulcher differs from other species by the following combination of character states: interocular region (Figs 1F, 2I) with a group of fine punctures and erect pubescence; metatrochanter with one tooth (Fig. 1I) ; elytra with two types of punctures (Fig. 1C), anterior region and apex coarsely and sparsely punctate, and posterior region partially and finely punctate.
Redescription.
Length 10–12 mm, width 3.8–4.8 mm. Head (Fig. 1F, I) black or yellow; mouthparts yellow; antennae bicolored, antennomeres I–IV black, V–XI black and yellow or last three yellow; pronotum yellowish orange, disc sometimes blue or purple (Figs 1H, 2G). Elytra (Figs 1A, B, 2A–C, G, H) yellow or orange with iridescent blue or purple stripes of variable shape and length, one near base and one subapical. Prosternum yellow, meso- and metathorax black or yellow; coxae generally yellow. Femora mostly yellow, with black maculae dorsally. Abdomen black, with black pubescence.
Head (Figs 1F, 2I). Occiput sparsely punctate or impunctate, interocular region with group of fine points and erect pubescence; ocular canthi surface concave; antennal awning short, not prolonged onto canthi; antennae long (Fig. 1A, B), last four antennomeres surpassing posterior edge of pronotum. Scape as long as antennomere III, II twice as long as III, III 1.2 times longer than V, IV as long as V, V as long as wide, V–X wider than long; XI bullet-shaped; last maxillary palpomeres subconical, apex blunt.
Thorax. Pronotum (Fig. 1H) broader than long, subrectangular, base wider than anterior margin, disc convex, sparsely and shallowly punctate (as on head), anterior portion with clearly defined groove, anterior angles coarsely punctate, lateral margins weakly rounded and glabrous, posterior portion of disc with lateral depressions, posterior margin bisinuate and edged by ridge, posterior lateral angles prominent and with apex rounded. Scutellum (Fig. 1G) flush with elytral surface, coarsely punctate, subtriangular, apex rounded; elytra (Fig. 1A) laterally subparallel, epipleura with rounded edge; humeri rounded, projecting anterolaterally; disc convex, surface with two types of punctures (Fig. 1C), anterior region and apex coarsely and sparsely punctate, and posterior region partially and finely punctate. Metaepisternum (Fig. 1D) with anterior portion coarsely punctate and pubescent, rest impunctate and glabrous; metaventrite convex, shallowly punctate and pubescent; metatrochanter with one tooth (Fig. 1I); pro- and mesofemur slender and elongate, metafemur robust and reniform (Fig. 1B); tibiae curved; metatibiae strongly curved, surface with four faces; dorsal face convex, with longitudinal carina, ventral face glabrous except pubescent on apical region.
Abdomen. Tergite I with two sclerotized regions, tergite II with three sclerotized regions (Fig. 1J); pygidium with apex rounded (Fig. 1J); last abdominal ventrite sparsely punctate, with decumbent pubescence, apex subtruncate. Aedeagus with median lobe (Fig. 1N) strongly sclerotized, narrowing medially, apical region concave, with apex apiculate and deflected. Tegmen (Fig. 1O) slightly sclerotized; parameres with apex pubescent, emarginate and with rounded medial notch; tegmen ring lanceolate, roof slender, 0.8 times shorter than parameres.
Female. Femora fusiform, tibiae swollen near apex; last abdominal ventrite with apex emarginate, pygidium with apex rounded. Spermatheca (Fig. 1P) hook-shaped, proximal part of spermathecal capsule with velum short, hook-shaped, terminal portion coiled and notably long, cecum rounded.
Distribution.
Argentina, Bolivia, Brazil, Mexico, and Peru (Rodríguez-Mirón 2018).
Remarks.
The color pattern in Agathomeruspulcher exhibits a high degree of polymorphism (Fig. 2), and because of its wide distribution, specimens from different regions were considered to belong to different species.
After reviewing the specimens from Francisco Monrós’ collection deposited in the NMNH, GRM observed label annotations that Monrós considered A.bichito and A.pulcher as synonyms. On the other hand, he considered other specimens as different subspecies because of the variation in their coloration. However, these observations were never published.
The type specimen of Agathomeruspulcher was collected in Mexico (Lacordaire, 1845), although the exact locality is not specified; for many years this species was considered restricted to this country. However, after the present study, A.pulcher is now considered a species with a wide distribution, from Mexico to Argentina. It should be noted that after reviewing main collections from different countries, no specimens of A.pulcher from Mexico were found, which calls into question its presence in this country.
Agathomerus
magdalenae
sp. nov.
Taxon classificationAnimaliaColeopteraMegalopodidae
D238A924-63A5-5842-8914-B1B9CB5924AD
https://zoobank.org/62DDE802-6E42-4839-B714-C7106D0A0C7B
Type material examined.
Holotype. Mexico • 1♂; Chiapas, Aguacero; 6 June 1987; W. B. Warner leg; pinned, with genitalia in a separate microvial; CNIN. Paratypes. MEXICO • 1♀; Same data as holotype; CCFEZ-Z. • 1 ♀; Guerrero, Taxco A., Santiago Temixco; 18°28'46"N, 99°37'50.1"W; alt. 1251 m; 23 May 2008; S. López leg.; 15:55; SBC; CCFEZ-Z • 1♂; Oaxaca, Candelaria Loxicha, Portillo del Rayo; 24 May 1990; A. C. Deloya; Bosque tropical y cafetal; CCFEZ-Z.
Diagnosis.
Agathomerusmagdalenae sp. nov. is similar to santiagoi sp. nov. and it is distinguished by the following combination of character states: ocular canthi surface convex, scapes longer than antennomeres III, II twice as long as III, pronotum (Fig. 3G) with a continuous groove on anterior portion, scutellum rounded at apex, metaepisternum (Fig. 3H) with anterior region impunctate and glabrous, rest coarsely punctate and pubescent; metatibiae ventrally flat, parameres (Fig. 3E) with rounded apex, and roof robust. In A.santiagoi sp. nov. the ocular canthi surface is concave, scapes are as long as antennomeres III, II half as long as III, pronotum with anterior groove interrupted medially (Fig. 4F), scutellum slightly emarginate at apex, metaepisternum (Fig. 4G) uniformly punctate and pubescent, metatibiae ventrally concave, parameres (Fig. 4D) with a cleft at apex, and slender roof.
Description.
Length 10.8–11.6 mm, width 4.7–5.0 mm. Body (Fig. 2A, B) with pubescence yellow; occiput, front, antennae, clypeus, labrum and mandibles black, rest of head, thorax, apical region of femora and abdomen orange; pronotal disc, basal region of femora, tibiae and tarsi black; elytra mostly dark blue, anterior lateral margin and apices yellow.
Head (Fig. 3F). Occiput and interocular region coarsely and sparsely punctate, with long pubescence; ocular canthi surface sparsely convex; antennal awning short, not prolonged onto canthi; antennae barely surpassing posterior edge of pronotum; scapes 1.1 times longer than antennomeres III, II twice as long as III, III 1.5 times longer than V, IV shorter than V, V as long as wide, VI–X wider than long; last maxillary palpomeres subconical, apex blunt.
Thorax. Pronotum bell-shaped (Fig. 3A, G), pronotal disc convex, with two depressions, coarsely and sparsely punctate, (though less coarse than on head), with erect pubescence, anterior groove interrupted medially, anterior angles coarsely punctate, lateral margins rounded and densely pubescent, posterior region with lateral depressions, posterior margin edge with ridge, posterior lateral angles prominent and rounded. Scutellum depressed with respect to elytral surface, subtriangular, emarginate at apex, coarsely punctate; elytra with external margins subparallel, epipleura with rounded edge; humeri rounded, projecting anterolaterally; disc convex, coarsely and sparsely punctate. Metaepisternum (Fig. 3H) mostly coarsely punctate and pubescent, anterior portion impunctate and glabrous; metaventrite convex, coarsely punctate and pubescent; pro- and mesofemur slender and elongate, metafemur robust and fusiform (Fig. 3B); tibiae with pubescence erect, dorsal surface with ocellate punctures and a longitudinal carinae, meso- and metatibiae curved, metatibiae ventrally glabrous, with two incomplete longitudinal carinae.
Abdomen. Tergites evenly sclerotized; pygidium apically sparsely punctate and sparsely pubescent, apex rounded; last abdominal ventrite sparsely punctate and pubescent; setae decumbent; surface concave apically; apical margin subtruncate.
Aedeagus. median lobe (Fig. 3C) narrowing medially, apical region subtriangular, apex rounded. Tegmen (Fig. 3E) sclerotize; parameres setose laterally, apex rounded and with long setae; tegmen ring oblong, roof robust, 1.5 times shorter than parameres.
Female. Pronotal disc without depression (Fig. 3G); femora slightly pyriform, tibiae subcylindrical, swollen near apex; meso- and metatibiae slightly curved. Pygidium with apex subtruncate; last abdominal ventrite with subtruncate apex. Spermatheca (Fig. 3D) boomerang-shaped, basal part of spermathecal capsule with velum highly developed. Stem with projection, terminal portion coiled and notably long.
Distribution.
Mexico: Chiapas, Guerrero, Oaxaca.
Etymology.
The new species is named after Ma. Magdalena Ordóñez Reséndiz, the degree advisor of the authors.
Agathomerus
santiagoi
sp. nov.
Taxon classificationAnimaliaColeopteraMegalopodidae
AB6FA32E-DF0A-5FE8-8981-73B35EA2756C
https://zoobank.org/552E61BA-A6C5-4B15-96CC-CEBBDCBA4C6A
Type material examined.
Holotype. Mexico • 1♂; Morelos, 2.5 km, 4 km O Huautla, Estacion CEAMISH; 18°27'671"N, 99°02'475"W; Alt. 940 m, 7–12 July 1996; A. Pérez leg.; ex vegetación; pinned, with genitalia in a separate microvial; CNIN.
Diagnosis.
Agathomerussantiagoi sp. nov. is similar to magdalenae sp. nov. and it is distinguished by the following combination of character states: ocular canthi surface concave, scapes as long as antennomeres III, II half as long as III, pronotum (Fig. 4F) with anterior groove interrupted medially, scutellum slightly emarginate at apex, metaepisternum (Fig. 4G) uniformly punctate and pubescent, metatibiae ventrally concave, parameres (Fig. 4D) emarginated at apex, and slender roof. In A.magdalenae sp. nov. the ocular canthi surface is convex, scapes are longer than antennomeres III, II twice as long as III, pronotum (Fig. 3G) with a continuous groove on anterior portion, scutellum rounded at apex, metaepisternum (Fig. 3H) with anterior region impunctate and glabrous, rest coarsely punctate and pubescent; metatibiae ventrally flat, parameres (Fig. 3E) with rounded apex, and robust roof.
Description.
Length 11.6 mm, width 4.4 mm. Body (Fig. 4A, B) with pubescence yellow; head, thorax and abdomen orange; mandibles, antennae, protibiae and tarsi black; interocular region and clypeus with a black macula (Fig. 4E); labial and maxillary palpomeres yellow; pronotum with two black maculae (Fig. 4F); elytra yellow with black lateral stripe, elytral suture and humeri black.
Head (Fig. 4E). Occiput coarsely and sparsely punctate, interocular region sparsely punctate except setigerously punctate on midline, setae long; ocular canthi surface concave; antennal awning short, not prolonged onto canthi; antennae barely surpassing posterior edge of pronotum; scapes as long as antennomeres III, II half as long as III, III twice as long as V, IV as long as V, V as long as wide, VI–X wider than long; frontoclypeal groove arcuate; last labial palpomeres bullet-shaped, apex blunt; last maxillary palpomeres subconical, apex blunt.
Thorax. Pronotum (Fig. 4F) bell-shaped, pronotal disc convex, coarsely and sparsely punctate (punctures less coarse and sparser than on occiput), with anterior groove interrupted medially; anterior angles and lateral margins rounded and pubescent, posterior region with lateral depressions, posterior margin edged with a ridge, posterior lateral angles slightly projected; scutellum depressed with respect to elytral surface, subtriangular, apex weakly emarginate, coarsely punctate; elytra with external margins subparallel, epipleura with lateral edge rounded; humeri rounded, projecting anterolaterally; disc convex, coarsely and sparsely punctate. Metaepisternum (Fig. 4G) coarsely punctate and pubescent; metaventrite convex, coarsely punctate and pubescent; pro- and mesofemur elongate, metafemur robust and fusiform; tibiae with pubescence erect, dorsal surface with ocellate punctures and a longitudinal carinae, meso- and metatibiae curved, metatibiae ventrally glabrous with two crenate, longitudinal carinae.
Abdomen. Tergites evenly sclerotized; pygidium sparsely, setigerously punctate, apex rounded; last abdominal ventrite concave, sparsely, setigerously punctate, setae decumbent, apex truncate. Aedeagus: median lobe (Fig. 4C) narrowing towards apex, apical region subtriangular, apex blunt. Tegmen (Fig. 4D) sclerotized; parameres dorsally setose; setae long; apex emarginate; tegmen ring ovoid; roof half as long as parameres.
Distribution.
Mexico: Morelos.
Etymology.
The new species is named after Santiago Zaragoza Caballero, the PhD advisor of the authors.
Agathomerus
espinosaorganistai
sp. nov.
Taxon classificationAnimaliaColeopteraMegalopodidae
F7D7D3B3-9325-5165-995B-FCB74CF5C147
https://zoobank.org/60E626E1-E1C3-4498-AB63-DE1B19C0C5CA
Type material examined.
Holotype. Mexico • 1♂; Sinaloa, El Palmito, 8mi W; 24–64 July // UC Berkeley; EMEC; QR 729245; pinned, with genitalia in separate microvial; EMEC.
Diagnosis.
Agathomerusespinosaorganistai sp. nov. is similar to A.signatus (Klug) and it is distinguished by the following combination of character states: pronotum with anterior groove interrupted medially (Fig. 5F), scutellum with apex subtruncate, male metafemur fusiform and metatibiae curved (Fig. 5B) , and metaepisternum (Fig. 5G) with anterior region coarsely, setigerously punctate, rest impunctate and glabrous. In A.signatus the pronotum has a well-defined anterior groove, scutellum apex is rounded, male metafemur are kidney-shaped and strongly curved, and metaepisternum has anterior and posterior regions punctate and pubescent, with rest impunctate and glabrous.
Description.
Length 9.6 mm, width 4 mm. Body (Fig. 5A, B) with pubescence yellow; head, thorax and femora black; mouthparts, antennae, tibiae and tarsi brown; pronotum, elytra and metaventrite yellow; pronotal disc with an M-shaped macula (Fig. 5F); elytral humerus black with a black stripe extending near the elytral apex and two spots on each elytron.
Head (Fig. 5E). Occiput sparsely and coarsely punctate, interocular region impunctate and glabrous; ocular canthi surface concave; antennal awning short, not prolonged onto canthi; antennae moderately long, last antennomeres surpassing posterior edge of pronotum; scapes 1.5 times longer than antennomeres III, II twice as long as III, III as long as V, IV shorter than V, V as long as wide, VI–X wider than long; frontoclypeal groove straight; last maxillary palpomeres subconical, apex truncate.
Thorax. Pronotum (Fig. 5F) broader than long, bell-shaped, base wider than anterior margin, pronotal disc convex, sparsely and finely punctate, with short erect pubescence, anterior portion with groove interrupted medially, anterior angles rounded, not projected, lateral margins weakly rounded, posterior margin edged with a ridge, posterior lateral angles weakly projected.
Scutellum depressed with respect to elytral surface, sparsely and coarsely punctate, subtriangular, apex subtruncate; elytra external margins subparallel, epipleura with lateral edge rounded; humeri rounded, projecting anterolaterally; disc convex, sparsely and coarsely punctate. Metaepisternum (Fig. 5G) with anterior portion coarsely punctate and pubescent, posterior portion impunctate and glabrous; metaventrite convex, sparsely punctate; pro- and mesofemur slender and elongate, metafemur swollen; tibiae with pubescence erect, surface convex and with a longitudinal carinae, meso- and metatibiae curved, metatibiae ventrally flat and glabrous with two crenate, longitudinal carinae.
Abdomen. Tergites evenly, weakly sclerotized; pygidium sparsely punctate and pubescent, apex truncate; last abdominal ventrite sparsely punctate, pubescent, setae decumbent, apical region with a transverse groove, apex truncate. Aedeagus: median lobe (Fig. 5C) subparallel medially, apex rounded. Tegmen (Fig. 5D) slender, sclerotized, parameres setose laterally, apex rounded, with long setae; tegmen ring oblong, roof 1.5 times shorter than parameres.
Distribution.
Mexico: Sinaloa.
Etymology.
The new species is named after David Nahum Espinosa-Organista, the Masters advisor of the first author. The specific epithet is a combination of the last names of Dr David Espinosa-Organista.
Supplementary Material
XML Treatment for Agathomerus
XML Treatment for Agathomerus pulcher
XML Treatment for Agathomerus magdalenae
XML Treatment for Agathomerus santiagoi
XML Treatment for Agathomerus espinosaorganistai
The reference list from the paper itself. Each links out to its DOI / PubMed record.
- 1Ehara S (1954) Comparative anatomy of male genitalia in some cerambycids. Journal of the Faculty of Science, Hokkaido University Ser.VI, Zoology 12: 61–115.
- 2Halffter G (1964) La entomofauna americana, ideas acerca de su origen y distribución.Folia Entomológica Mexicana 6: 1–108.
- 3Halffter G (2003) Biogeografía de la entomofauna de montaña de México y América Central. In: Morrone JJ Llorente-Bousquets J (Eds) Una perspectiva Latinoamericana de la Biogeografía.Facultad de Ciencias, UNAM, México, 87–97.
- 4Halffter G Morrone JJ (2017) An analytical review of Halffter’s Mexican transition zone, and its relevance for evolutionary biogeography, ecology and biogeographical regionalization.Zootaxa 4226: 1–46. 10.11646/zootaxa.4226.1.128187628 · doi ↗ · pubmed ↗
- 5Jacoby M.Clavareau H (1905) Fascicule 33: Coleoptera Phytophaga, Fam. Megalopidae, In: Wytsman PA (Ed.) Genera Insectorum. V. Verteneuil & L.Desmet, Bruxelles, 20 pp.
- 6Lacordaire T (1845) Monographie des Coleopteres Subpentameres de la famille des Phytophages. Tome 1.Muquardt, Bruxelles, 808 pp. 10.5962/bhl.title.48433 · doi ↗
- 7Matsumura Y Suzuki K (2008) Comparative morphology of internalreproductive systems in leaf beetles of the Donaciinae and Criocerinae (Coleoptera: Chrysomelidae) and its implication for the phylogeny.Zootaxa 1845: 1–32. 10.11646/zootaxa.1845.1.1 · doi ↗
- 8Monrós F (1947) Revisión de los Megalopidae argentinos (Col., Chrysomeloidea).Revista de la Sociedad Entomológica Argentina 13: 150–217.
