Apical Acute Myocardial Infarction Due to Occluded Posterior Descending Branch of Right Coronary Artery Concomitant With Short Left Anterior Descending Artery: Multi-imaging Modality Assessment

TL;DR

A rare case of apical heart attack was caused by a blocked artery in the right coronary system, not the left as typically assumed.

Contribution

This case highlights the importance of multi-imaging modality assessment in diagnosing atypical coronary artery anatomy.

Findings

LV apex wall motion abnormality was due to a blocked posterior descending branch of the RCA.

Left coronary angiography showed no significant disease despite apical dysfunction.

Cardiac CT and MRI confirmed the anatomical and functional link between the RCA branch and the LV apex.

Abstract

Regional wall motion abnormality in the left ventricular (LV) apex detected on transthoracic echocardiography is commonly interpreted as the presence of a distal left anterior descending (LAD) artery lesion in clinical practice. Herein, we reported a rare case of apical acute myocardial infarction (AMI) caused by an occluded posterior descending branch of the right coronary artery (RCA), in which the correspondence between coronary arterial anatomy and supplied LV apex was evaluated by multi-imaging modalities.

Despite the presence of regional wall motion abnormality in the LV apex, left coronary angiography showed no significant coronary artery diseases. It was of note that LAD terminated before the LV apex. Right coronary angiography showed total occlusion of the posterior descending branch. Cardiac computed tomography (CT) clearly demonstrated that the spontaneously recanalized posterior descending branch extended toward the LV apex. Cardiac magnetic resonance imaging (MRI) clearly revealed regional wall motion abnormality corresponding to myocardial edema in the LV apex. Cardiac CT and MRI were powerful tools in clarifying the correspondence between coronary arterial anatomy and supplied LV apex. Clinicians should be aware that localized apical AMI can occur under the condition of occluded posterior descending branch of RCA concomitant with short LAD.

Figures
