A Radiomic Approach for Evaluating Intra-Subgroup Heterogeneity in SHH and Group 4 Pediatric Medulloblastoma: A Preliminary Multi-Institutional Study

TL;DR

This study uses radiomics to better understand and predict outcomes for two types of pediatric brain tumors, helping to personalize treatment plans.

Contribution

A radiomic prognostic signature (mRRisk) is developed to refine risk stratification within SHH and Group 4 medulloblastoma subgroups.

Findings

The mRRisk signature showed significant differences between risk groups in SHH and Group 4 subgroups.

Radiomics features captured tumor characteristics better than traditional Chang stratification methods.

The approach could improve personalized treatment for medulloblastoma patients.

Abstract

Medulloblastoma (MB) is the most common malignant brain tumor in children and has a dismal prognosis. A challenge with MB is identifying patients who could be candidates for reduced doses of radiation therapy, but are still treated effectively, as well as those that need intensified doses. Recently, MB was classified into four molecular subgroups with distinct clinical outcomes (WNT, SHH, Group 3, and Group 4). Though two of these subgroups (SHH and Group 4) are known for their intermediate prognosis, wide disparities of outcomes have been reported within each of these subgroups. This work aims to develop a prognostic signature using radiomics (computationally derived tumor measurements), acquired on MRI scans, to risk-stratify patients within the SHH and Group 4 subgroups. Our signature includes two key attributes that capture aspects of the disease microenvironment. We believe that our signature will provide a better understanding of the disease’s heterogeneity and, hence, develop better personalized treatment plans.

Medulloblastoma (MB) is the most frequent malignant brain tumor in children with extensive heterogeneity that results in varied clinical outcomes. Recently, MB was categorized into four molecular subgroups, WNT, SHH, Group 3, and Group 4. While SHH and Group 4 are known for their intermediate prognosis, studies have reported wide disparities in patient outcomes within these subgroups. This study aims to create a radiomic prognostic signature, medulloblastoma radiomics risk (mRRisk), to identify the risk levels within the SHH and Group 4 subgroups, individually, for reliable risk stratification. Our hypothesis is that this signature can comprehensively capture tumor characteristics that enable the accurate identification of the risk level. In total, 70 MB studies (48 Group 4, and 22 SHH) were retrospectively curated from three institutions. For each subgroup, 232 hand-crafted features that capture the entropy, surface changes, and contour characteristics of the tumor were extracted. Features were concatenated and fed into regression models for risk stratification. Contrasted with Chang stratification that did not yield any significant differences within subgroups, significant differences were observed between two risk groups in Group 4 (p = 0.04, Concordance Index (CI) = 0.82) on the cystic core and non-enhancing tumor, and SHH (p = 0.03, CI = 0.74) on the enhancing tumor. Our results indicate that radiomics may serve as a prognostic tool for refining MB risk stratification, towards improved patient care.
