Delayed femoral artery injury caused by heterotopic ossification: a rare case report and review of the literature

TL;DR

A rare case of delayed femoral artery injury caused by heterotopic ossification is reported, highlighting the risks of vascular complications during HO excision.

Contribution

This case report adds to the limited literature on arterial injury caused by HO following fractures.

Findings

A 56-year-old male presented with femoral artery injury and hematoma 10 years after a femoral shaft fracture complicated by HO.

Surgical excision of HO was limited due to the artery being encased in the mass, leading to partial removal.

The patient recovered well post-surgery with full mobility restored after one year.

Abstract

Arterial injury caused by heterotopic ossification (HO) following fractures is rarely reported, yet it can have catastrophic consequences. This case report presents a unique instance of femoral artery injury and hematoma organization, occurring a decade after intramedullary nail fixation for a femoral shaft fracture complicated by HO.

A 56-year-old male presented with right femoral artery injury and organized hematoma, a decade after suffering bilateral femoral shaft fractures with mild head injury in a traffic accident. He had received intramedullary nailing for the right femoral shaft fracture and plate fixation for the left side in a local hospital. Physical examination revealed two firm, palpable masses with clear boundaries, limited mobility, and no tenderness. Peripheral arterial pulses were intact. Radiography demonstrated satisfactory fracture healing, while a continuous high-density shadow was evident along the inner and posterior aspect of the right thigh. Computed tomography angiography identified a large mixed-density mass (16.8 × 14.8 × 20.7 cm) on the right thigh’s medial side, featuring central calcification and multiple internal calcifications. The right deep femoral artery coursed within this mass, with a smaller lesion noted on the posterior thigh. Surgical consultation with a vascular surgeon led to planned intervention. The smaller mass was completely excised, but the larger one partially, as it encased the femoral artery. The inability to remove all HO was due to excessive bleeding. Postoperatively, the patient experienced no complications, and one-year follow-up revealed a favorable recovery with restoration of full right lower limb mobility.

This case underscores the potential gravity of vascular injury associated with heterotopic ossification. Surgeons should remain vigilant regarding the risk of vascular injury during HO excision.

Figures
