Computed tomographic evaluation of the proximity of needles placed for perineural anesthesia of the palmar digital nerves to synovial structures in the foot: an ex vivo study

TL;DR

This study uses CT scans to assess the risk of needle placement near synovial structures during palmar digital nerve blocks in cadaver limbs.

Contribution

The study introduces a novel ex vivo method to evaluate synovial penetration risk during palmar digital nerve blocks using CT imaging.

Findings

Synovial penetration occurred in 3% of needle placements, primarily affecting the navicular bursa and distal interphalangeal joint.

Needle tip distances to synovial structures were significantly reduced after distension and with distal needle placements.

Proximal needle placements showed closer proximity to the digital flexor tendon sheath.

Abstract

Potential synovial penetration following palmar digital nerve blocks has not been investigated.

To evaluate the proximity of needles placed for palmar digital nerve blocks to nearby synovial structures using computed tomography (CT).

Descriptive observational study.

In 18 cadaver forelimbs, sequential injection of the navicular bursa (NB), distal interphalangeal joint (DIPJ) and digital flexor tendon sheath (DFTS) was performed using 3, 5 and 10 mL diluted radiodense contrast medium, respectively. After each synovial injection, 25 gage needles were placed over the palmar digital nerves at the proximal aspect of the ungular cartilages (distal injections) and 1 cm further proximally (proximal injections), and CT examination was performed. Subsequently, needles were removed, and the synovial structures further distended with the same volume as for the first injection. Perineural needle placement and image acquisition were repeated. The distance between the needle tip and adjacent synovial structures was measured (mm) in reconstructed images. Results were analyzed in separate general linear mixed models, to determine the effect of needle position and synovial distension on the distance from the tip of the needle to the NB, DFTS and DIPJ.

Synovial penetration was confirmed following 12/420 (3%) needle placements (NB n = 5, 1 after proximal and 4 after distal injections; DIPJ n = 2, DFTS n = 2, NB or DIPJ n = 3, all after distal injections). The mean distance from the needle tip to the NB and DIPJ was significantly smaller after the second distension (NB: p = 0.025; DIPJ: p < 0.001) and with the distal needle placements (NB: p < 0.001; DIPJ: p < 0.001). For the DFTS, the distance from the needle tip was significantly smaller with the proximal needle placements (p = 0.001).

Ex-vivo study.

There is a small risk of synovial penetration when performing palmar digital nerve blocks, especially when distension of adjacent synovial structures is present.

Figures
