Contribution to the Chinese Intybia Pascoe, 1866 (Coleoptera, Melyridae, Malachiinae), with descriptions of two new species groups and one new species
Abstract
Genes, proteins, chemicals, diseases, species, mutations and cell lines named across the full text — each resolved to its canonical identifier and authoritative record.
Click any figure to enlarge with its caption.
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5| 1 | Elytra monochrome, without spot or stripe |
|
| – | Elytra not monochrome, with whitish, yellowish or orange spots or stripes |
|
| 2 | Thorax orange-red; elytra dark blue with metallic luster, with dense and coarse punctuation |
|
| – | Thorax black; elytra black, with or without metallic blue luster, without distinct. punctation |
|
| 3 | Elytra black with metallic blue luster, head with frons black; pronotum strongly constricted at base; body length more than 3.5 mm |
|
| – | Elytra black without metallic luster, head with frons yellow; pronotum gradually constricted to base; body length less than 2.5 mm |
|
| 4 | Thorax orange-red; elytra with two transverse orange stripes mixed with white, which are connected along the suture |
|
| – | Thorax black; elytra with one transverse stripe or three whitish spots |
|
| 5 | Elytra black without metallic luster, with three whitish spots, one at about anterior third and two subapical |
|
| – | Elytra black, sometimes with metallic luster, with one yellow to orange transverse stripe before middle, sometimes continuous across suture |
|
Peer Reviews
No public reviews on file for this paper yet. If you reviewed it on a platform where reviews are public (OpenReview, ICLR, NeurIPS, ICML), you can paste yours below so the community can read it here.
Videos
No videos yet. Explain this paper in a talk, walkthrough, or lecture? Add one.
Taxonomy
TopicsColeoptera Taxonomy and Distribution · Forest Insect Ecology and Management · Lepidoptera: Biology and Taxonomy
Introduction
The genus Intybia Pascoe, 1866 belongs to the tribe Apalochrini of malachiine Melyridae, which is represented by about 170 species from the Asiatic region, making it one of the most diverse genera within the tribe Apalochrini (Wittmer 1997; Plonski 2013; Tshernyshev 2016; Ikeda and Yoshitomi 2017). It is characterized by the following characters: antenna with scape and antennomere 3 dilated and modified in the male; fore leg with tarsus and tibia simple in the male, tarsal formula 5–5–5; and pronotum without bead along lateral or posterior margins. Initially, most species of Apalochrini were included in Laius Guérin-Méneville, 1830 (Macleay 1872; Blackburn 1888; Lea 1909). Champion (1921) treated Intybia as a subgenus of Laius, until Evers (1994) re-diagnosed Laius and recognized Intybia as an independent genus. This treatment was followed by most researchers, and subsequently, a considerable number of species were transferred from Laius to Intybia (Wittmer 1995, 1997, 1999; Yoshitomi and Lee 2010; Plonski 2013, 2014a, 2014b; Plonski and Geiser 2014). Plonski and Geiser (2014) and Plonski (2016) divided Intybia into 11 species groups mainly based on colouration. A new subgenus, Intybia (Protolaius) Tshernyshev, 2020 was described for several species of the Intybialombokana group based on male characters of the fore femora (Tshernyshev 2020). Tshernyshev (2015) established a new genus, Troglointybia Tshernyshev, 2015, for a few species of Intybia with a sculptured head; more species from Southeast Asia were transferred to this genus by Tshernyshev (2016). Plonski (2016) suggested eyestalks as the autapomorphy of Troglointybia and transferred most species back to Intybia, leaving only four species in Troglointybia.
Research on the genus Intybia is relatively abundant in some Asian regions, including Japan (Ikeda and Yoshitomi 2017; Asano 2021), Philippines (Plonski 2014b; Tshernyshev 2016), the Himalaya region (Tshernyshev 2015) and Indonesia (Wittmer 1995). In China, there are approximately 28 recorded species of the genus Intybia, most of which were described by Wittmer (1955, 1956, 1982, 1995, 1996, 1997) and Pic (1907, 1910, 1919, 1921, 1927). According to Plonski (2016), most species of Chinese Intybia can be assigned to five species groups: Intybiaguttata group, Intybiapelegrini group, Intybiapicta group, Intybiarubrithorax group and Intybiavenusta group. While Intybiaklapperichi (Hicker, 1949), Intybiaerectodentatus (Wittmer, 1982), Intybiaeversi (Hicker, 1949) and Intybiaconcha Asano, 2015 are not assignable to any species group described by Plonski (2016) based on specimens and original descriptions; thus, two new species groups are described here. One new species collected from Hainan Province, similar to Intybiaklapperichi and Intybiaerectodentatus, is also described.
Material and methods
Intybia specimens involved in this study are deposited in the following institutions: IZGAS–Institute of Zoology, Guangdong Academy of Sciences, Guangzhou, China; ZFMK–Zoologisches Forschungsmuseum Alexander Koenig, Bonn, Germany.
Specimens for dissections were cleared in a 10% solution of KOH for about 10 h at room temperature. The abdomen with the aedeagus was transferred to a cavity slide using fine forceps and the aedeagus was separated from the abdomen using a hooked, fine dissecting needle. Specimens were mounted on cards with white emulsion glue. Genitalia and terminal abdominal segments are preserved in genitalia vials with glycerol.
The habitus images were captured using a Canon 7D DSLR camera, Canon MP–E 65 mm macro lens and Mitutoyo 5× objective lens, mounted on a WeMacro Focus Stacking Rail, with Helicon Remote 3.9.10 and WeMacro software for focus stacking. Male genitalia were photographed using a Zeiss AxioCam HRc digital camera mounted on a Zeiss AX10 compound microscope with the Axio Vision SE64 4.8 software. Layered images of the male genitalia were stacked in Helicon Focus software and edited in Photoshop CC 2022.
The morphological terms used in this paper follow Lawrence and Ślipiński (2013). Measurements were made as follows: body length—from the apical edge of the clypeus to the apex of the elytra; pronotal length—median line from the anterior margin to the posterior margin; pronotal width—maximum width of the pronotum; elytral length—from the base of the scutellum to the elytral apex along the suture; elytral width—maximum width across the elytra.
Taxonomy
Melyridae Leach, 1815
Malachiinae Fleming, 1821
Intybiaklapperichi group
Diagnosis. Body size small (less than 2.5 mm). Head black with anterior area yellow, pronotum and elytra entirely black; antenna with basal three segments yellow, antennomeres 4–11 brownish to dark brown; legs yellow with basal 4/5 of femora brown to black (Figs 1A, D, 3A, B). Vestiture of short whitish setae. Dorsal surface without distinct punctuation. Antennomere 3 suboval, with projection along inner edge (Figs 1C, 3D). Pronotum transverse, slightly constricted at base.
Intybiahainanensis sp. nov., holotype A habitus, dorsal view B head, dorsal view C basal antennoeres, dorsal view D habitus, ventral view. Scale bars: 1 mm (A, B).
**Included species.**Intybiaerectodentatus (Wittmer, 1982), Intybiahainanensis Wang & Liu, sp. nov., Intybiaklapperichi (Hicker, 1949).
Distribution. Only known from China: Fujian, Guangdong, Hainan, Taiwan.
Intybia
hainanensis
Taxon classificationAnimaliaColeopteraMelyridae
Wang & Liu sp. nov.
191E314D-1C59-5BFF-8E30-99C9B66BB1D5
https://zoobank.org/C25966F5-97F1-4B7F-9278-6A67E63296B0
Type material.
Holotype: China • ♂; Hainan, Ledong, Jianfengling; 18.731273°N, 108.873082°E; 17 Mar. 2021; Yuchen Zhao leg; IZGAS. Paratype: • 1 ♂; same data as for holotype.
Diagnosis.
This species is similar to Intybiaerectodentatus (Wittmer, 1982) and Intybiaklapperichi (Hicker, 1949) in body shape and colouration. It can be easily recognized by the shape of antennomere 3 (Fig. 1C), whose inner protrusion is pointed apically (blunt in the other two species).
Description.
Male. Length 2.0–2.1 mm. Head yellow, with areas behind middle of eyes black on dorsal surface, frons with darker median spot (Fig. 1B); ventral surface with gular area more? or brownish. Mandibles yellow with black apex, maxillary palps and labial palps brownish. Antennae with antennomeres 1–4 yellow, remaining 7 segments brown. Pronotum and elytra black. Legs yellow with basal 4/5 of femora and apex of trochanters dark brown to black. Prosternum dark brown, mesoventrite and metaventrite black; abdominal ventrites dark brown with medial areas of ventrite 2–5 yellow (Fig. 1A, D). Vestiture of short yellowish setae.
Head widest across eyes, nearly as wide as pronotum; dorsal surface flat, covered with dense short setae, clypeus divided into sclerotized postclypeus and membranous anteclypeus; frons weakly depressed, slightly constricted in front of eyes. Eyes relatively large and laterally protruding. Antenna with 11 segments; scape subtriangular, elongated with slightly enlarged apex; antennomere 3 enlarged and suboval, inner edge with inwardly twisted projections; antennomeres 4–11 covered with short white setae. Labrum transverse, dorsal surface convex. Mandibles bidentate apically, slightly blunt, inner margin straight. Maxillary palps with 4 segments, last segment enlarged and obliquely truncated; labial palps 3 with segments, segment 1 very short, segment 3 conical.
Prothorax transverse; pronotum about 0.7 times as long as wide, widest at about basal third, distinctly constricted at base (Fig. 1A); anterior margin rounded and posterior margin nearly straight. Surface covered with short white setae. Prosternum short, protrochantins exposed. Procoxal cavities transverse and nearly contiguous, posteriorly open; procoxae enlarged and distinct protruding. Scutellum transverse with posterior margin slightly rounded.
Elytra about 1.4 times as long as wide, pear-shaped, widest at about anterior third; humeri rounded and slightly elevated. Surface covered with short white setae. Mesoventrite and metaventrite covered with white setae. Mesoventrite short and subtriangular; mesocoxal cavities large, contiguous at middle, laterally open to mesepimeron; mesocoxae subtriangular, apex slightly swollen, distinctly projecting. Metaventrite enlarged; discrimen distinct, not extending to center, lateral areas with punctures; metanepisternum broad, narrowed posteriorly. Metacoxae transverse, subtriangular, sharply narrowed beside trochanter.
Legs (Fig. 1C) slender, femora slightly enlarged at middle, covered with dense short setae; tibiae slender, with denser setae than femora, which is even denser on inner surface of fore tibiae. Tarsal formula 5–5–5; tarsomeres 3 and 4 slightly shorter than tarsomeres 1 and 2; tarsomere 5 longest, with pair of symmetrical small claws and membranous appendages.
Abdomen with 6 freely movable ventrites; ventrite 1 divided by metacoxae; ventrites 2–4 subequal in length and gradually decreasing in width. Ventrites 2–6 covered with white to light yellow setae on both sides, with longer setae on the last 2 ventrites. Tergite VIII (Fig. 2C) with apical margin broadly rounded, covered with sparse setae; sternite VIII (Fig. 2B) weakly connected at middle. Aedeagus (Fig. 2A) slender, narrowly rounded apically; endophallus with longitudinal sclerite about half as long as penis, curved near base, subapical area with numerous spinules.
Intybiahainanensis sp. nov., paratype (A–C) and Intybiaklapperichi (Hicker, 1949) (D–F) A, F aedeagus, dorsal view B, D sternite VIII C, E tergite VIII.
Female. Unknown.
Etymology.
The species name is derived from the province Hainan, where the type specimens were collected.
Distribution.
Hainan.
Intybia
klapperichi
Taxon classificationAnimaliaColeopteraMelyridae
(Hicker, 1949)
849C6871-92A3-560D-AEEB-007277B6C377
Material examined.
Holotype: China • ♂; Fujian, Kwangtseh; 1 Sept. 1937; J. Klapperich leg.; ZFMK-COL-1000188.
Other materials.
China • 2 ♂, 4 ♀; Guangdong, Shaoguan City, Ruyuan, Nanling National Forest Park; 24.88487°N, 113.03585°E; 9 May 2023; Zhenhua Liu, Yuqi Wang and Liye Wei leg.; net sweeping; IZGAS.
Diagnosis.
It can be distinguished from the other two species within the species group by shape of antennomere 3 (Fig. 3D), with inner protrusion blunt apically and bent toward posterior (inner protrusion pointed apically in Intybiahainanensis and bent toward anterior in Intybiaerectodentatus).
Intybiaklapperichi (Hicker, 1949) A male habitus, dorsal view B male habitus, ventral view C female habitus, dorsal view D male antenna, dorsal view E head, dorsal view F holotype, labels G holotype, dorsal view. Scale bars: 1 mm (A–C, G).
Redescription.
Male. Length 2.0–2.4 mm. Head yellow, with areas behind middle of eyes black on dorsal surface (Fig. 1A, G), frons with median area darker (Fig. 3E); ventral surface with gular area dark brown. Mandibles yellow with black apex; maxillary palps and labial palps dark brown. Antennae with scape and antennomere 3 light yellow, antennomeres 4–11 brown to black (Fig. 3D). Pronotum and elytra black. Legs with coxae, trochanters and femora mostly black; apex of tarsi, middle areas of middle and hind tibiae brownish to dark brown; remaining part of tibiae and tarsi, joints of coxae and trochanters yellow (Fig. 3B). Prosternum, mesoventrite and metaventrite black; abdominal ventrites black with medial areas yellow to orange. Vestiture of dense white setae.
Head widest across eyes, nearly as wide as pronotum; dorsal surface flat, covered with short setae; clypeus divided into sclerotized postclypeus and membranous anteclypeus; frons slightly constricted in front of eyes. Eyes large and laterally protruding. Antenna with 11 segments; scape elongated and subtriangular; antennomere 3 suboval, inner margin with a hammer-shaped projection twisting towards posterior (Fig. 3D); antennomeres 4–11 densely covered with setae. Labrum transverse, anterior margin strongly arched. Maxillary palps with 4 segments, last segment enlarged and obliquely truncate; labial palps with 3 segments, terminal segment conical.
Prothorax transverse; pronotum about 0.7 times as long as wide, widest at about half; margins smooth, without distinct angles; anterior margin evenly arched, posterior margin nearly straight. Surface densely covered with white short setae. Prosternum short, protrochantin exposed. Procoxal cavities transverse and contiguous at middle; procoxae enlarged, subtriangular. Scutellum subtrapezoid, posterior margin nearly truncated.
Elytra about 1.4 times as long as wide, widest at about anterior third, lateral margins slightly curved; humeri slightly elevated. Surface densely covered with white setae, longer than those on pronotum, punctation indistinct. Mesoventrite transverse and subtriangular; mesocoxal cavities contiguous at middle, laterally open to mesepimeron; mesocoxae enlarged and subtriangular, distinctly projecting, trochantins exposed. Metaventrite transverse, slightly swollen, metanepisternum broad at base, narrowed posteriorly. Metacoxae transverse, subtriangular, sharply narrowed beside trochanter.
Legs (Fig. 3B) slender, femora slightly enlarged at middle, covered with dense short setae; tibiae slender, with denser setae than femora, which is even denser on inner surface of fore tibiae. Tarsal formula 5–5–5, terminal tarsomere with pair of symmetrical small claws and membranous appendages.
Abdomen with 6 freely movable ventrites. Ventrites with long setae on the sides, longer setae on ventrites 4–6. Tergite VIII with posterior margin emarginate (Fig. 2E), covered with sparse setae, denser along apical margin; sternite VIII narrowly weakly connected at middle (Fig. 2D). Aedeagus (Fig. 2F) slender, apex narrowly rounded; endophallus with longitudinal sclerite, about half as long as penis; subapical area with numerous spinules.
Female. Similar to male in body shape and colouration (Fig. 3C), but with head entirely black. Antenna with scape only slightly dilated apically; antennomere 3 simple, rectangular. Fore tarsi distinctly longer than those in male.
Distribution.
Fujian, Guangdong.
Intybiaeversi species group
Diagnosis. Head, pronotum, scutellum and elytra black, elytra with metallic blue luster (Fig. 4A–C, F). Vestiture of dense short setae. Head with midcranial suture. Pronotum strongly constricted posteriorly, distinctly shorter than elytra at base. Elytra only with dense fine punctures at center, remaining areas nearly smooth. This species group resembles the Intybialombokana group (Plonski, 2015) in colouration, but can be easily distinguished by the simple vestiture, punctation on the elytra and shape of the pronotum.
Intybiaeversi (Hicker, 1949) A male habitus, dorsal view B male habitus, ventral view C female habitus, dorsal view D male antenna, dorsal view E holotype, labels F holotype, dorsal view. Scale bars: 1 mm (A–C, F).
Remarks.Tshernyshev (2020) established the subgenus Protolaius for Intybialombokana (Pic, 1910) and Intybiaschillhammeri (Wittmer, 1966) of the Intybialombokana group, mainly based on the excavate femora in the male, which is absent in Intybiaconcha.
**Included species.**Intybiaconcha Asano, 2015, Intybiaeversi (Hicker, 1949).
Distribution. Only known from China (Guangdong, Jiangsu, Shaanxi, Taiwan).
Intybia
eversi
Taxon classificationAnimaliaColeopteraMelyridae
(Hicker, 1949)
BC5FDEC7-CDF1-5BE8-B756-92D01308EA5B
Material examined.
Holotype: China • ♂; Fujian, Kwangtseh; 17 July 1937; J. Klapperich leg.; ZFMK-COL-1000176.
Other materials.
China • 1 ♂, 1 ♀; Zhejiang, Shaoxing City, Yuecheng District, Fusheng Town; 29.94070°N, 120.73935°E; 14 July 2020; Yuchen Zhao leg.; net sweeping; IZGAS; • 1 ♂; Hubei, Huanggang City, Macheng Aimenguan; 565 m; 31.3856863°N, 115.3231569°E; Fei Ye and Yuqi Wang leg.; IZGAS • 3 ♀; Guangdong, Shaoguan City, Nanling National Forest Park first peak; 24.91971°N, 112.974713°E; 1541 m; 24 Aug.–28 Sept. 2022; Wenfeng Li and Ruonan Zhang leg.; malaise trap; IZGAS.
Diagnosis.
This species can be distinguished by its scape with a dark stripe along the inner margin (Fig. 4D), head with a midcranial suture and fine punctations on the elytra. Compared to Intybiaconcha, antennomere 3 of this species has a smoother edge, presenting a more regular spindle shape, with the outer margin slightly blunter than the inner margin.
Redescription.
Male. Length 2.7–3.2 mm. Head black, with areas between antennal insertions and anteclypeus yellowish; labrum black at base, apical area yellow, maxillary palps with apex of terminal segment dark yellow. Antenna with basal 3 segments yellow, base of scape black, antennomere with dark stripe along anterior edge on dorsal surface; antennomere 4–11 brownish to dark brown (Fig. 4D). Pronotum black, elytra iridescent dark blue with metallic lustre. Legs deep brown to black with tarsi light brown. Ventral side black, with medial areas and posterior margins of abdominal ventrites 2–5 orange, ventrites 2 to 5 extending yellow regions laterally (Fig. 4B). Vestiture of short white setae.
Head widest across eyes, narrower than pronotum; dorsal surface flat, with distinct midcranial suture; frons slightly constricted in front of eyes; clypeus divided into sclerotized postclypeus and membranous anteclypeus. Eyes large and conspicuously prominent. Antenna with 11 segments; scape subtriangular, with apex distinctly dilated; antennomere 3 strongly transverse, with large transverse concavity, inner edge slightly pointed; antennomeres 4–11 covered with dense white short setae. Labrum transverse and large, nearly semicircular, apical margins strongly arched. Maxillary palps with 4 segments with terminal segment dilated and obliquely truncate; labial palps with 3 segments with terminal segments conical.
Pronotum slightly transverse, about 0.8 times as long as wide, widest at about basal third; lateral margins strongly constricted at base, anterior margin curved, posterior margin almost straight (Fig. 4A, F); disc convex dorsally, slightly depressed posteriorly. Surface nearly smooth, without distinct punctuation; densely covered with short setae. Prosternum short, protrochantins exposed. Procoxal cavities strongly transverse, contiguous at middle; procoxae enlarged and ventrally protruding. Scutellum subtrapezoidal, posterior margin truncate; surface covered with sparse short setae.
Elytra about 1.2 times as long as wide, widest at about apical third, ovoid; humeri slightly elevated; surface covered with dense fine punctures at middle, remaining areas nearly smooth, covered with dense short setae. Mesoventrite elongated; mesocoxal cavities contiguous at middle, laterally open to mesepimeron; Mesocoxae large and triangular, ventrally protruding. Metaventrite slightly swollen, with short discrimen; metacoxae transverse, subtriangular, sharply narrowed beside trochanters.
Legs slender, femora slightly swollen, covered with white short setae; tibiae slender, with denser setae than femora, which is even denser on inner surface of fore tibiae. Tarsal formula 5–5–5, front tarsi distinctly shorter; terminal tarsomere with pair of symmetrical small claws and membranous appendages underneath.
Abdomen with 6 freely movable ventrites; ventrites 1–4 subequal in length, longer than apical 2 segments, ventrites 4–6 gradually narrowed to apex. Tergite VIII (Fig. 5C) subtrapezoid, with pair of moderately long and curved posterior struts, posterior margin triangularly emarginated; sternite VIII (Fig. 5D) transverse, weakly connected at middle. Aedeagus broad at middle (Fig. 5A), apex acute and curved (Fig. 5B); endophallus with 4 broad and curved sclerites at middle, and 4 small spine–shaped sclerites next to them, 3 at basal and 1 at apical, subapical area with a few thick spinules.
Intybiaeversi (Hicker, 1949), male genitalia A aedeagus, dorsal view B aedeagus, lateral view C tergite VIII D sternite VIII.
Female. Similar to male in body shape and colouration (Fig. 4C), but antenna with scape only slightly dilated apically, antennomere 3 simple and elongated, front tarsi longer.
Distribution.
Fujian, Guangdong.
Key to species groups of the genus Intybia Pascoe in China
On the basis of species group designations proposed by Plonski (2016), a key to species groups of Intybia in China is provided below:
**: **
Supplementary Material
XML Treatment for Intybia hainanensis
XML Treatment for Intybia klapperichi
XML Treatment for Intybia eversi
The reference list from the paper itself. Each links out to its DOI / PubMed record.
- 1Asano M (2015) Taxonomic notes on some malachiid beetles of Taiwan, with description of a new species of the genus Intybia Pascoe (Coleoptera: Malachiidae).Japanese Journal of Systematic Entomology 21(1): 77–82.
- 2Asano M (2021) Larval structures and bionomics of two species of the genus Intybia Pascoe (Coleoptera: Melyridae: Malachiinae).Coleopterists Bulletin 75(3): 617–628. 10.1649/0010-065X-75.3.617 · doi ↗
- 3Blackburn T (1888) Further notes on Australian Coleoptera with descriptions of new species.Transactions and Proceedings and Reports of the Royal Society of South Australia 10: 177–287.
- 4Champion GC (1921) Notes on various African and Asiatic species of Laius, Guérin, with an account at their accessory ♂-characters.Annals & Magazine of Natural History 9(7): 322–343. 10.1080/00222932108632526 [Coleoptera] · doi ↗
- 5Evers AMJ (1994) Zur Phylogenie von Laius Guér., Collops er. und der verwandten Gattungen.Entomologische Blätter 90(3): 169–181.
- 6Ikeda H Yoshitomi H (2017) Revision of the genus Intybia (Coleoptera, Malachiidae) from Japan.European Journal of Taxonomy 331(331): 1–31. 10.5852/ejt.2017.331 · doi ↗
- 7Lawrence JFŚlipiński A (2013) Australian Beetles. Vol. 1. Morphology, Classification and Keys. CSIRO Publishing, Collingwood, Victoria, [viii +] 561 pp. 10.1071/9780643097292 · doi ↗
- 8Lea AM (1909) Revision of the Australian and Tasmanian Malacodermidae.Transactions of the Royal Entomological Society of London 1(1–2): 45–251. 10.1111/j.1365-2311.1909.tb 02171.x · doi ↗
