Exploring memory synchronization and performance considerations for FPGA platform using the high-abstracted OpenCL framework: Benchmarks development and analysis

TL;DR

This paper explores how memory access affects performance in FPGA computing using OpenCL benchmarks and proposes efficient implementation strategies.

Contribution

The study introduces eight OpenCL benchmarks for FPGAs and proposes a task-parallel model to reduce synchronization costs.

Findings

Memory access behaviors significantly impact performance in FPGA computing.

A task-parallel model effectively reduces the need for costly synchronization mechanisms.

Tailored implementations of primitives improve performance on FPGA platforms.

Abstract

A key benefit of the Open Computing Language (OpenCL) software framework is its capability to operate across diverse architectures. Field programmable gate arrays (FPGAs) are a high-speed computing architecture used for computation acceleration. This study investigates the impact of memory access time on overall performance in general FPGA computing environments through the creation of eight benchmarks within the OpenCL framework. The developed benchmarks capture a range of memory access behaviors, and they play a crucial role in assessing the performance of spinning and sleeping on FPGA-based architectures. The results obtained guide the formulation of new implementations and contribute to defining an abstraction of FPGAs. This abstraction is then utilized to create tailored implementations of primitives that are well-suited for this platform. While other research endeavors concentrate on creating benchmarks with the Compute Unified Device Architecture (CUDA) to scrutinize the memory systems across diverse GPU architectures and propose recommendations for future generations of GPU computation platforms, this study delves into the memory system analysis for the broader FPGA computing platform. It achieves this by employing the highly abstracted OpenCL framework, exploring various data workload characteristics, and experimentally delineating the appropriate implementation of primitives that can seamlessly integrate into a design tailored for the FPGA computing platform. Additionally, the results underscore the efficacy of employing a task-parallel model to mitigate the need for high-cost synchronization mechanisms in designs constructed on general FPGA computing platforms.

Figures
