Virtual reconstruction of the Canis arnensis type (Canidae, Mammalia) from the Upper Valdarno Basin (Italy, Early Pleistocene)

TL;DR

Scientists used a new virtual method to reconstruct a deformed fossil of an ancient dog species to better understand its features.

Contribution

The study introduces Target Deformation, a novel virtual restoration protocol for correcting taphonomic deformation in fossils.

Findings

Target Deformation successfully restored the deformed lectotype skull of Canis arnensis.

The retrodeformed cranium clustered within the morphometric variability of C. arnensis.

The method proved effective in overcoming preservation issues for taxonomically significant traits.

Abstract

Taphonomic deformation, whether it be brittle or plastic, is possibly the most influential process hindering the correct understanding of fossil species morphology. This is especially true if the deformation affects type specimens or applies to or obscures taxonomically diagnostic or functionally significant traits. Target Deformation, a recently developed virtual manipulation protocol, was implemented to address this issue by applying landmark-guided restoration of the original, deformed fossils, using undeformed specimens (or parts thereof) of the same species as a reference. The enigmatic Early Pleistocene canid Canis arnensis provides a typical example of a fossil species in dire need of virtual restoration. Its lectotype specimen is heavily deformed and none of the few known skulls are well preserved, obscuring the recognition of its systematic and phylogenetic position. Our results indicate that the algorithm effectively countered the lectotype skull’s laterolateral compression and its concomitant rostrocaudal elongation. Morphometrically, comparison of the retrodeformed cranium (IGF 867_W) with other specimens of the same species, and to other fossil and extant canid material, confirms IGF 867_W consistently clusters within C. arnensis variability. Overall, the evidence presented here confirms that Target Deformation provides a powerful tool to better characterize complex taxa like C. arnensis, whose knowledge is severely affected by the state of preservation of its fossil material.

Figures
