Assessment of the Anterior Loop and Pattern of Entry of Mental Nerve Into the Mental Foramen: A Radiographic Study of Panoramic Images

TL;DR

This study uses panoramic radiographs to analyze the mental nerve's entry pattern into the mental foramen and the presence of an anterior loop to aid in dental implant planning.

Contribution

The study provides new radiographic data on the prevalence of mental nerve patterns and the anterior loop in a large sample of panoramic images.

Findings

The straight pattern of mental nerve entry was most common (67.5%).

The anterior loop pattern was observed in 18.8% of cases.

There was a significant association between the side of the mandible and loop pattern.

Abstract

Introduction: The precise location of the mental foramina is an essential landmark in planning the position of dental implants in the anterior mandible. Injury to inferior alveolar nerve during anterior mandibular implant surgery causes altered sensation which greatly affects patient satisfaction.

Methods: In this study, we assessed the prevalence of anterior loop of mental nerve and the pattern of entry of mental nerve into the mental foramen. Three hundred panoramic radiographs (600 hemimandibles) obtained from records maintained in the Department of Oral Medicine and Radiology were randomly selected for the study. The radiographs were evaluated by two independent observers for the pattern of entry of mental nerve into the mental foramen on either side of the mandible and for the presence or absence of anterior loop of mental nerve.

Results: The most prevalent pattern of mental nerve observed was Straight pattern which totals to 67.5% followed by Anterior loop pattern (18.8%) and then the Perpendicular pattern (13.7%). There was no significant association between the gender and subtypes of looping pattern on the left and right side and a highly significant association between the side of the mandible and loop pattern was observed by Chi square test.

Conclusion: The Anterior loop pattern of mental nerve has been found in 18.8% of the population suggesting to accurate planning with three-dimensional imaging techniques to avoid injury to mental nerve during dental implant placement and other surgical procedure involving the interforaminal region of the mandible.

Figures
