Identifying collaborators in large codebases

TL;DR

This paper presents a method to analyze developer collaboration patterns in large codebases by embedding and clustering commit activity, programming languages, and code topics, revealing hidden interactions and organizational insights.

Contribution

It introduces a novel approach combining embedding and clustering techniques to uncover organic collaboration structures in large-scale software projects.

Findings

Successfully reconstructed the engineering organization structure

Revealed hidden coding collaborations

Justified technical decisions within the organization

Abstract

The way developers collaborate inside and particularly across teams often escapes management's attention, despite a formal organization with designated teams being defined. Observability of the actual, organically formed engineering structure provides decision makers invaluable additional tools to manage their talent pool. To identify existing inter and intra-team interactions - and suggest relevant opportunities for suitable collaborations - this paper studies contributors' commit activity, usage of programming languages, and code identifier topics by embedding and clustering them. We evaluate our findings collaborating with the GitLab organization, analyzing 117 of their open source projects. We show that we are able to restore their engineering organization in broad strokes, and also reveal hidden coding collaborations as well as justify in-house technical decisions.

Figures

Tables

Table 1. Table 1: Teams of topic contributors.

Frontend	Config Management	Gollum (wiki)
Verify FE	Monitor BE	Product Management
Core	Plan BE	Support Department
Manage FE	Core Alumni	Core Alumni
Create FE	Create BE	Core
Monitor FE	Distribution BE
Serverless FE
Frontend

Full text

To identify existing inter and intra-team interactions—and suggest relevant opportunities for suitable collaborations—this paper studies contributors’ commit activity, usage of programming languages, and code identifier topics by embedding and clustering them. We evaluate our findings collaborating with the GitLab organization, analyzing 117 of their open source projects. We show that we are able to restore their engineering organization in broad strokes, and also reveal hidden coding collaborations as well as justify in-house technical decisions.

1 Introduction

Many organizations undergo rapid digital transformation nowadays. In such a setting, a common challenge is the understanding of software development dynamics. Horizontal relations between development teams are typically obscure and unobvious at a glance. Yet understanding them is important to manage organizational structure, plan hiring, and prioritize work.

This paper introduces complementary methods to analyze contributors to open source projects. We study several orthogonal contributor features to obtain an overview of existing collaborations and evaluate our methods on the GitLab organization, a large software company with over 500 employees and 110 projects with more than 2,000 external contributors as of 2019. The considered features include the alignment of commit time series, the developer experience reflected in contributed lines of code (LoC), and topic models related to code naturalness (Allamanis et al., 2017). We harness dimensionality reduction and clustering for visualization.

2 Related Work

Some researchers have already explored developer collaboration and recommendation through analysis of the coding activities. For example, Montandon et al. (2019) made use of supervised machine learning classifiers to identify experts in three popular JavaScript libraries. However, that approach depends on manually labeled classes, so it may be difficult to generalize. Along the same line, Greene & Fischer (2016) have developed a tool to extract and visualize developers’ skills by using both keywords from the project’s README file and commit messages combined with their portfolio metadata, which they collected from third-party Community Question Answering websites. Hauff & Gousios (2015) had a different objective to directly match developers to relevant jobs by comparing their embeddings. Those embeddings were generated from the query describing the job and the README file of the project, but they do not leverage the source code itself. Regarding the topic modeling technique, it has been applied on source code identifiers by Markovtsev & Kant (2017), but without analyzing individual contributions or focusing on potential coding collaborations.

Differing from these, we detect collaborators by working with fine-grained information from every commit: we analyze every file in the repository’s history.

3 Methodology

This section presents a combination of three complementary developer analyses, and each clarifies a particular aspect of developers’ characteristics.

3.1 Data Processing

To gain the quantitative insight into source code required by further analyses, we employ Hercules111https://github.com/src-d/hercules and Gitbase222https://github.com/src-d/gitbase—tools that allow efficient and rapid mining of Git repositories. We gather the number of contributed lines per programming language per developer, the ownership information about each file (who edited each line the last), and the commit dates. We also extract the identifiers from each file and store their frequencies. There is the need for matching Git signatures to contributors. Therefore we aggregate all co-occurring emails and names to a single identity by finding connected components in the corresponding undirected co-occurrence graph. We have to exclude signature stubs such as gitlab@localhost. The help of GitLab API is intentionally avoided for versatility reasons.

3.2 Commit Time Series

The first analysis is grounded on aligning developers’ commits time series. People who work in a team tend to create commits at correlated times, because they often work on related, mutually dependent features. The relative commit frequency depends on the shared team planning, notably the deadlines. We found empirically that the absolute values of the time series are less important than the distribution shape.

Thus we extract how many commits were done by each developer per day, divide the values by the mean to normalize the resulting time series, and calculate the pairwise distance matrix using Fast Dynamic Time Warping (Salvador & Chan, 2007). Then we perform DBSCAN (Ester et al., 1996) clustering and run UMAP (McInnes et al., 2018) dimensionality reduction to visualize the clusters. Both mentioned algorithms operate on the explicit distance matrix.

3.3 Contributions by Programming Languages

The following way of grouping developers is based on the programming language, the amount and the nature of contributions (line additions, modifications, and deletions). Intuitively, these coarsely correlate with developer seniority and activity domains. Hence we exclude text markup files from the analysis. We reduce the influence of outliers by saturating all the values to the 95th percentile. Our distance metric is L2. We visualize the distribution by applying UMAP, which preserves the local topological relations that should be highlighted in our case. We calculate clusters in the embedding space using K-Means, and their number is determined by the elbow rule. Running K-Means in the original space produces worse results due to its high-dimensionality and sparsity.

3.4 Source Code Identifiers

To complement the commit activity and the programming language usage analyses, we leverage the content of developers’ contributions in order to assign them topics that are representative of their activity. We compute the representation for each code file based on its content as a bag of TF-IDF scores of its identifiers. We then represent each developer by aggregating the representations of the code files they edited with a sum weighted by the proportion of the owned lines in each file. Finally, we apply ARTM (Vorontsov et al., 2015) to find decorrelated, sparse topics fitted to those representations and label them manually having obtained their most likely and specific terms.

4 Results

We evaluate the three presented analyses on the codebase of the GitLab organization. That comprised 117 repositories, totaling 145 programming languages, 44,272 files and 12,895,956 lines of code in April 2019. Among the 2,956 contributors, we detected 210 current GitLab employees split in 37 teams (this is a lower bound given the algorithmic difficulties detailed in Section 3.1). A mapping from developers to teams is publicly available333https://gitlab.com/gitlab-com/www-gitlab-com/blob/master/data/team.yml.

Fig. 1a and Fig. 1b reveal the temporal commit coupling of the contributors. GitLab employees are sorted into two clusters among five; commit activity alignment proves to be a reliable way to tell GitLab employees from external contributors. However, the finer structure often does not respect the teams. For example, cluster #2 groups high frequency committers across the company, one of them being GitLab’s CEO.

On the other hand, clustering developers by their experience in programming languages— Fig. 1c and 1d—provides different insights. Fig. 1d demonstrates that people in the same team tend to have similar experience. All the clusters but #4 in Fig. 1c contain Ruby developers. Indeed, GitLab is driven by Ruby on Rails and being proficient in Ruby is essential for the company. Cluster #2 joins developers who code in both Go and Ruby, which agrees with the current partial conversion of the GitLab backend from Ruby on Rails to Go444https://about.gitlab.com/2018/10/29/why-we-use-rails-to-build-gitlab/. Fig. 1d suggests that the Gitaly, Create BE and Verify teams are particularly working on this, since their members are located together. Then, cluster #4 emphasizes the recent switch to Vue.js in the frontend, and the Dev UX team seems to be one of the team in charge of this. Cluster #4 clearly gathers all the frontend engineers who code in JavaScript, Vue.js framework, and write SCSS. Overall, the clusters match the typical Ruby on Rails relation between frontend and backend technologies.

Finally, to evaluate the quality of a code topic, we retrieve the teams of the contributors for whom the evaluated topic is the preponderant one. Results shown in Table 1 highlight that the topic modeling analysis strongly correlates with GitLab teams. Table 2 shows examples of manually created labels.

We also measure the agreement between topics and the clusters from Fig. 1a and 1c. On average, developers that have a given main topic are in 1.54 and 1.63 clusters for commit activity and experience clustering respectively (the expectations are 2.11 and 2.27 respectively for random clusters).

5 Conclusion

This paper demonstrated how to identify existing collaborations in an organization by exploring the topological structure of three feature spaces of a codebase: commit activity, usage of programming languages, and topics of source code identifiers. Clustering proved insightful: we observed a good match with existing development teams in the GitLab organization, and additionally found several product-oriented inter-organizational squads. We traced the partial transition from Ruby to Go in GitLab’s backends, which was indeed decided at the company level. Commit series alignment distinguished between external and internal contributors well.

Our future research directions include leveraging the commits to external repositories since developers usually contribute to several open source projects that do not belong to their company. Furthermore, it would be interesting to study how engineering teams have evolved as the company has grown. We believe that combining the recent advancements in machine learning with the expressive features can shed light on relevant coding collaboration opportunities.
