An in-medium chiral power counting for nuclear matter and some applications

TL;DR

This paper develops a systematic chiral power counting method for nuclear matter, incorporating non-perturbative resummations, and applies it to calculate properties like the equation of state, with implications for neutron star physics.

Contribution

It introduces a novel in-medium chiral power counting framework combined with non-perturbative techniques for nuclear matter calculations.

Findings

Accurate calculation of pion self-energy and decay constants in nuclear matter.

Reproduction of realistic nuclear matter equations of state without fine tuning.

Constraints on neutron star properties consistent with gravitational wave observations.

Abstract

We review on a chiral power counting for in-medium chiral perturbation theory with nucleons and pions as explicit degrees of freedom coupled to external sources. It allows for a systematic expansion including both local and pion-mediated inter-nucleon interactions. One can identify from this power counting classes of non-perturbative diagrams that require resummation. A non-perturbative method based on Unitary Chiral Perturbation Theory was also developed for performing those resummations. This power counting and non-perturbative techniques were firstly applied to calculate the pion self-energy, the pion-decay constants and the quark condensate in nuclear matter up-to-and-including next-to-leading order (NLO) contributions. The cancellation of the contributions at NLO to the pion self-energy and decay constants from in-medium nucleon-nucleon (NN) interactions was derived. Some NLO NN contributions survive for the quark condensate due to the quark-mass dependence of the pion mass. Next, we discuss the calculation of the energy density in the nuclear medium by employing the in-medium NN scattering amplitudes. For symmetric and neutron matter it reproduces in good agreement, and without fine tuning, calculations from realistic NN potentials with a model for the three-nucleon interaction. These results are applied to derive the equation of state (EOS) for neutron stars and obtain an upper limit for a neutron mass slightly above 2 solar masses. Our results also fulfill other constraints from the detection of the gravitational waves in the event GW170817, like the upper bound on the maximal mass of a neutron star and the allowed interval for the radius of a 1.4-solar-mass neutron star. The knowledge of the neutron-matter EOS is also employed to give an upper bound of the gravitational constant within the strong gravitational field of a 2 solar-mass neutron star.

Figures

Equations

$${\mathcal{L}}_{\chi }={\mathcal{L}}_{\pi \pi }+{\mathcal{L}}_{\bar{\psi }\psi }+{\mathcal{L}}_{\bar{\psi }\bar{\psi }\psi \psi }+\dots$$

$${\mathcal{L}}_{\bar{\psi }\psi }$$

$$D^{-1}={\left[I-D_0^{-1}A\right]}^{-1}{D}_0^{-1}.$$

$$\Gamma$$

$$i{D}_0^{-1}(p_j)$$

$$i{D}_0^{-1}$$

$$\nu =4L_H+4L_{\pi }-2I_{\pi }+\sum _{i=1}^{V_{\rho }}\left[\sum _j{d}_j-2m_i\right]+\sum _{i=1}^{V_{\pi }}{\delta }_i+\sum _{i=1}^{V_{\rho }}3.$$

$$L_{\pi }+L_H=I_{\pi }+I_H-V_{\rho }-V_{\pi }+1.$$

$$2I_H+2I_{\pi }+E_{\pi }=\sum _{i=1}^V{v}_i+\sum _{i=1}^{V_{\pi }}{n}_i,$$

$$4L_H+4L_{\pi }-2I_{\pi }=4I_H+2I_{\pi }-4V_{\rho }-4V_{\pi }+4.$$

$$4L_H+4L_{\pi }-2I_{\pi }=2I_H-E_{\pi }+\sum _{i=1}^V{v}_i+\sum _{i=1}^{V_{\pi }}{n}_i-4V_{\rho }-4V_{\pi }+4.$$

$$\nu =2I_H-E_{\pi }+4-4V_{\pi }+\sum _{i=1}^{V_{\pi }}({\delta }_i+n_i)+\sum _{i=1}^V(d_i+v_i)-2\varkappa -V_{\rho }.$$

$$\nu$$

$${\delta }_i+n_i-4\ge 0,$$

$$d_i+{\omega }_i+v_i-2\ge 0,$$

$$\frac{{\varphi }^a}{f^{a-2}}\frac{p^b}{{\Lambda }^{b-2}}.$$

$$\rho \frac{{\varphi }^a}{f^a}\frac{p^b}{{\Lambda }^{b-1}},$$

$$\frac{\rho }{f^2\Lambda }=\mathcal{O}\left(\frac{p^3}{\Lambda (\upsilon \pi f{)}^2}\right),$$

$$\rho \frac{{\varphi }^a}{f^a}\frac{2m{p}^{b-1}}{{\Lambda }^{b-1}}.$$

$$\frac{2m\rho }{f^2\Lambda p}\sim \frac{2m\xi }{(\upsilon \pi f{)}^2}\frac{\xi }{\Lambda }.$$

$${\Lambda }_{\mathrm{low}}\simeq \frac{(\upsilon \pi f{)}^2}{2m}\ll \upsilon \pi f.$$

$${\mathcal{L}}_{NN}^{(0)}=-\frac{1}{2}{C}_S(\overline{N}N)(\overline{N}N)-\frac{1}{2}{C}_T(\overline{N}\vec{\sigma }N)(\overline{N}\vec{\sigma }N),$$

$$T_{NN}^c$$

$$-C_T\left({\vec{\sigma }}_{s_3{s}_1}\cdot {\vec{\sigma }}_{s_4{s}_2}{\delta }_{i_3{i}_1}{\delta }_{i_4{i}_2}-{\vec{\sigma }}_{s_3{s}_2}\cdot {\vec{\sigma }}_{s_4{s}_1}{\delta }_{i_3{i}_2}{\delta }_{i_4{i}_1}\right).$$

$$T_{NN}^c{(}^1{S}_0)$$

$$T_{NN}^c{(}^3{S}_1)$$

$$T_{NN}^{1\pi }=\frac{g_A^2}{4f^2}\left[\frac{({\vec{\tau }}_{i_3{i}_1}\cdot {\vec{\tau }}_{i_4{i}_2})(\vec{\sigma }\cdot \mathbf{q}{)}_{s_3{s}_1}(\vec{\sigma }\cdot \mathbf{q}{)}_{s_4{s}_2}}{{\mathbf{q}}^2+m_{\pi }^2-iϵ}-\frac{({\vec{\tau }}_{i_4{i}_1}\cdot {\vec{\tau }}_{i_3{i}_2})(\vec{\sigma }\cdot {\mathbf{q}}^{\prime }{)}_{s_4{s}_1}(\vec{\sigma }\cdot {\mathbf{q}}^{\prime }{)}_{s_3{s}_2}}{{{\mathbf{q}}^{\prime }}^2+m_{\pi }^2-iϵ}\right],$$

$$T_{NN}^{1\pi }(S=0,I=0)$$

$$T_{NN}^{1\pi }(S=0,I=1)$$

$$||B_{\sigma_{f}\sigma_{i}}||=\left(\begin{array}[]{l|lll}&-1&0&+1\\ \hline\cr-1&q_{3}^{2}&-\sqrt{2}(q_{1}+iq_{2})q_{3}&(q_{1}+iq_{2})^{2}\\ 0&-\sqrt{2}(q_{1}-iq_{2})q_{3}&q_{1}^{2}+q_{2}^{2}-q_{3}^{2}&\sqrt{2}(q_{1}+iq_{2})q_{3}\\ +1&(q_{1}-iq_{2})^{2}&\sqrt{2}(q_{1}-iq_{2})q_{3}&q_{3}^{2}\end{array}\right)$$

$$T_{NN;{\sigma }_f{\sigma }_i}^{1\pi }(S=1,I=0)$$

Full text

Keywords: chiral power counting, non-perturbative calculations, nuclear matter, neutron stars, gravitational waves

1. 1 Introduction

2. 2 Chiral Power Counting

3. 3 Nucleon-nucleon interactions

4. 3.1 Vacuum $NN$ interactions

5. 3.2 In-medium $NN$ interactions

6. 4 Nuclear-matter energy density

7. 5 Application of the EOS to neutron stars

8. 6 The in-medium temporal pion-decay constant, the quark condensate and the pion self energy

9. 7 Conclusions

10. A The one-pion exchange nucleon-nucleon partial waves

11. B Calculation of the $L_{10}^{I_{3}}$ function

12. B.1 Free part, $L_{10,f}$

13. B.2 One-medium insertion, $L_{10,m}$

14. B.3 Two medium insertions, $L_{10,d}$

15. References

1 Introduction

Nuclear physics treats typically systems of many nucleons. One of the long standing issues in nuclear physics is the calculation of atomic nuclei and nuclear-matter properties from microscopic internucleon forces in a systematic and controlled way. In recent decades Effective Field Theory (EFT) has proven to be an important tool to accomplish that goal. It is based on a power counting that establishes a hierarchy between the infinite amount of contributions, so that a finite number of mechanisms have to be considered for an order given. In this way, a controlled expansion results that allows to estimate the expected error due to the truncation of the series. In this work we employ Chiral Perturbation Theory (ChPT) [1, 2, 3] to nuclear systems, with the nucleons and the pions being the degrees of freedom. ChPT has also the virtue of being connected with QCD, since it shares the same symmetries and breaking of them.

In Ref.[4] many-body field theory was derived from quantum field theory by considering nuclear matter as a continuous set of free nucleons filling a Fermi sea at asymptotic times. The generating functional of ChPT in the presence of external sources was deduced, similarly as in the pion and pion-nucleon sectors [5, 6]. These results were applied in Ref.[7] to study ChPT in nuclear matter but including only perturbative nucleon interactions due to pion exchanges. Thus, the contact (short-range) nucleon-nucleon (and multi-nucleon) interactions were neglected. Other works along these lines are Refs. [8, 9], which work out the next-to-leading order (NLO) in-medium corrections to some pion properties by applying the many-body formalism derived in Ref. [4] and following the perturbative power counting of Ref. [7]. As in the latter reference, the detailed analysis of a pion state in the nuclear medium within this formalism allows Ref. [8] to single out the essential role played by the pion wave-function renormalization in defining the in-medium pion coupling constants. Furthermore, as first derived in Ref. [7], the in-medium pion wave-function renormalization gives account of the so-called missing $S$-wave repulsion [10, 11].

Let us stress that, as it is well known since the seminal papers of Weinberg [2, 3], the nucleon propagators do not always count as $1/p$, being $p$ a typical low momentum much smaller than the chiral scale of the expansion. It is often the case that the nucleon propagators scale as the inverse of a nucleon kinetic energy, $m/p^{2}$ (with $m$ the physical nucleon mass), so that they are much larger than assumed. This, of course, invalidates the straightforward application of the pion-nucleon power counting in vacuum. These issues were overcome in Ref. [12] where an in-medium power counting that takes into account contact, as well pion-mediated nucleon interactions, together with the possible infrared enhancements from the in-medium nucleon propagators was developed.

The in-medium power counting of Ref. [12] has been applied in the literature to several problems of interest, like the in-medium pion self-energy and the energy per nucleon of nuclear matter [13], the in-medium quark condensate and the pion-decay constants [14]. The resulting equation of state (EOS) for pure neutron matter of Ref. [13] was used in Ref. [15] to calculate the upper bound of a neutron star mass, which turned out to be above two solar masses, as required by the recent detection in Ref. [16] of a two-solar mass neutron star. We also notice here that it follows from the EOS of Ref. [13] that the radius of a neutron star of $1.4$ solar masses should be around 12.6 km [15], well inside the interval of values allowed by the analysis of Ref. [17] based on the GW170817 event detected by the LIGO and Virgo Collaborations [18] and on the existence of the two-solar mass neutron star detected in Ref. [16]. We review on these results here.

After this introduction, we rederive in Sec. 2 the chiral power counting in the nuclear medium of Ref. [12] that takes into account multi-nucleon local interactions, pion exchanges and the possible infrared enhancement of nucleon propagators. We then discuss the vacuum and in-medium nucleon-nucleon ($NN$) interactions used for the calculations up to NLO of in-medium ChPT, Sec. 3. This theory is then applied to calculate the EOS of nuclear matter in Secs. 4 and 5, which is used to the study of neutron-star properties, and then connecting with the GW170817 observations as well. An important point to characterize the state of nuclear matter is to study sufficient and/or necessary conditions for the breaking of chiral symmetry. In this respect a discussion on the results of Refs. [7, 12, 13, 14] on the temporal pion decay constant $f_{t}$ (corresponding to the coupling of the pion to the temporal component of the axial current) and the quark condensate is given in Sec. 6. An experimental important source of information for constraining the different approaches to nuclear physics is the spectrum of pionic atoms. Although the latter tend to constrain mostly the region of low densities in the nucleus, and it is not very sensitive to in-medium $NN$ interactions (as we explain below), it is also true that a controlled extrapolation (whenever is possible) of sound theories to higher densities could be of importance for the study of neutron stars. Some concluding remarks are gathered in Sec. 7.

2 Chiral Power Counting

In Ref.[4] the effective chiral Lagrangian for pions is determined in the nuclear medium in presence of external sources. For that the Fermi seas of protons and neutrons are integrated out making use of functional techniques. A similar approach is followed in Ref.[6] for the case of only one nucleon. If we write a general chiral Lagrangian density in terms of an increasing number of baryon fields $\psi(x)$ as

[TABLE]

Ref.[4] only retains ${\cal L}_{\pi\pi}$ and ${\cal L}_{\bar{\psi}\psi}$, with the latter written as

[TABLE]

in terms of the differential operator $D(x)$. This operator is decomposed as $D(x)=D_{0}(x)-A(x)$, where $D_{0}(x)=i\gamma^{\mu}\partial_{\mu}-m$ is the Dirac operator for the free motion of the nucleons and $-A(x)$ is the interacting part. In the derivations of Ref. [7], $D^{-1}$ is expressed as

[TABLE]

Also Ref.[4] established the concept of an in-medium generalized vertex (IGV). The latter results by connecting several vacuum operators $\Gamma$, defined as

[TABLE]

by real nucleons in the Fermi sea. Notice that the vacuum operator $\Gamma$ is non-local in general, as it arises by connecting vacuum interacting local vertices $A(x)$ through the free baryon propagator $D_{0}^{-1}$. Namely, we have the geometric series expansion for $\Gamma$ as, $\Gamma=A+AD_{0}^{-1}A+\ldots$ cf. Fig. 1. An IGV is schematically shown in Fig. 2 where the thick arc segment indicates the insertion of a Fermi sea. At least one is necessary because otherwise we would have a vacuum closed nucleon loop which is not explicitly taken into account in a low-energy effective field theory.#1#1#1Its effects are included in the renormalization of the vacuum ChPT calculations. On the other hand, the filled larger circles in Fig. 2 indicate a bilinear baryon vertex from ${\cal L}_{\bar{\psi}\psi}$ ,$-iA$, while the dots refer to the insertion of any number of them. In this figure the thin segments correspond to fermionic propagators, either to vacuum ones, $iD_{0}^{-1}$, or to Fermi-sea insertions. Within the relativistic formalism of Ref. [4] we can state the following Feynman rules for evaluating the in-medium diagrams. For an IGV with $n$ Fermi-sea insertions we have the combinatoric factor $(-1)^{n+1}/n$, and for each Fermi sea there is the factor $(2\pi)\delta(p^{2}-m^{2})\theta(p^{0})(p\!\!\!/+m)\theta(\xi-|{\mathbf{p}}|)$, where $p$ is the four-momentum flowing through the thick line, $\xi$ is a Fermi momentum and $\theta(x)$ is the standard Heaviside function. A factor $-iA$ accompanies any vacuum vertex and for the vacuum propagators of baryons we have $iD_{0}^{-1}=i(p\!\!\!/+m)/(p^{2}-m^{2}+i\epsilon)$, $\epsilon\to 0^{+}$. In addition, one also could have pion lines as external or internal particles connecting different bilinear vertices. In this respect an IGV behaves analogously to a local vertex in ${\cal L}_{\pi\pi}$.

Based on these results Ref.[7] derived a chiral power counting in the nuclear medium for pion-mediated interactions. In this reference ${\cal L}_{\bar{\psi}\psi}$ is replaced by ${\cal L}_{\pi N}$, which is the bilinear Lagrangian in the nucleon fields containing pions and external sources. For illustration we plot in Fig. 3 several Feynman diagrams involving different number of IGVs and Fermi-sea insertions in each of them. From left to right, the first two diagrams are of Hartree type and the last one is a Fock diagram. They are possible diagrams in the evaluation of the energy density in nuclear matter, cf. Sec. 4. The first two diagrams contain two IGVs, and the last diagram has only one IGV. The solid line in the second diagram with a slash is a free baryon propagator, while the rest of nucleon lines are Fermi-sea insertions. The dashed lines correspond to pion exchanges. More examples of in-medium diagrams are discussed below in the actual applications considered explicitly.

In relation with the infrared enhancements of nucleon propagators discussed by Weinberg [2, 3] for the vacuum propagation of two o more nucleon states, Ref.[7] stressed that within a nuclear environment even a single nucleon propagator could have such enhancements, driving to the so-called non-standard chiral counting. To see this, note that a soft momentum $Q$, related to pions or external sources, can be associated to any of the bilinear vertices. This, together with the Dirac delta function of four-momentum conservation, implies that the momenta running along the nucleon propagators in Fig. 2 just differ from each other by quantities of ${\cal O}(Q)$. Denoting by $k$ the on-shell four-momenta associated with one Fermi-sea insertion in the in-medium generalized vertex, the four-momentum running through the $j_{th}$ nucleon propagator can be written as $p_{j}=k+Q_{j}$. In this way,

[TABLE]

and $E({\mathbf{k}})={\mathbf{k}}^{2}/2m$.

Two different situations occur depending on the value of $Q_{j}^{0}$. If $Q_{j}^{0}={\cal O}(p)$ one has the standard counting so that the chiral expansion of the propagator in Eq. (5) is

[TABLE]

Thus, $iD_{0}^{-1}$ counts as a quantity of ${\cal O}(p^{-1})$. But it could also occur that $Q_{j}^{0}$ is ${\cal O}(E({\mathbf{k}}))$, that is, of the order of a kinetic nucleon energy in the nuclear medium or even lower, indeed it might even vanish [7]. The dominant term in Eq. (5) is then

[TABLE]

and the nucleon propagator should be counted as ${\cal O}(p^{-2})$, instead of the previous ${\cal O}(p^{-1})$. This is referred as the non-standard case in Ref.[7]. It is well known that this situation occurs already in vacuum when considering the two-nucleon reducible diagrams in $NN$ scattering. To face this problem Ref.[2] advocates for solving non-perturbatively a Lippmann-Schwinger equation with the $NN$ potential given by the two-nucleon irreducible diagrams. The case of nucleon reducible diagrams also occurs in the nuclear medium where there are an infinite number of nucleons provided by the Fermi seas.

The Ref. [12] extended the results of Refs.[4, 7] in a twofold way. i) Chiral Lagrangians with an arbitrary number of baryon fields (bilinear, quartic, etc) were considered. First only bilinear vertices like in Refs.[4, 7] are taken into account, but the exchanges of heavy meson fields of any type are allowed in addition to pion exchanges. The former should be considered as merely auxiliary fields that allow one to find a tractable representation of the multi-nucleon interactions that result when the masses of the heavy mesons tend to infinity. This is similar to the Hubbard-Stratonovich transformation. ii) The non-standard counting is taken from the start and any nucleon propagator is counted as ${\cal O}(p^{-2})$. In this way, no diagram, whose chiral order is actually lower than expected if the nucleon propagators were counted assuming the standard rules, is lost. This was a step forward in the literature.

The in-medium chiral power counting deduced in Ref. [12] proceeds in the following manner. Let us denote by $H$ the heavy mesons responsible, because of their exchanges between bilinear vertices in the limit of infinite mass, of the contact multi-nucleon interactions, $NN$, $NNN$, etc. From the counting point of view there is a clear similarity between the interactions driven by the exchanges of $H$ and $\pi$ fields as both emerge from bilinear vertices. The large mass of the former is responsible of the local character of the induced interactions. A heavy meson propagator is counted as $p^{0}$.

The chiral order of a given diagram is represented by $\nu$ and it is given by

[TABLE]

Here, $V_{\rho}$ is the number of IGVs, $m_{i}$ is the number of nucleon propagators in the $i_{th}$ IGV minus one, which is the one corresponding to the needed Fermi-sea insertion for every in-medium generalized vertex (and that gives rise to the last term in the previous equation). In addition, $d_{i}$ is the chiral order of the $i_{th}$ vertex bilinear in the baryon fields, $\delta_{i}$ is the chiral order of a vertex without baryons (only pions and external sources) and $V_{\pi}$ is the number of the latter ones. As usual, $L_{\pi}$ is the number of pion loops and $I_{\pi}$ is the number of internal pion lines. Finally, $L_{H}$ is the number of loops due to the internal $H$ lines.

Let us note that associated with the bilinear vertices in an IGV one has four-momentum conservation delta functions that can be used to fix the momentum of each of the baryon lines joining them, except one for the running momentum due to the Fermi-sea insertion. Of course, this cannot be fixed because one four-momentum delta function has to do with the conservation of the total four-momentum. This is the reason why we referred above only to loops attached to meson lines and not to baryon ones. We then have the following expression for the total number of loops associated with running meson momenta,

[TABLE]

There is also a well-known expression relating the total number of meson lines (both internal as external) with the number of meson lines attached to the different vertices. It reads,

[TABLE]

where $V$ is the total number of bilinear vertices, $v_{i}$ is the number of meson lines attached to the $i_{th}$ bilinear vertex, $n_{i}$ is the number of pions in the $i_{th}$ meson vertex and $E_{\pi}$ is the number of external pion lines. Taking into account Eq. (9) one has for the first three terms of Eq. (8),

[TABLE]

Now considering Eq. (10) in the right hand side of this equation, it becomes

[TABLE]

Substituting the previous line in Eq. (8),

[TABLE]

with $\varkappa=\sum_{i=1}^{V_{\rho}}m_{i}$. We now employ that $V_{\rho}+\varkappa=V$, and $2I_{H}=\sum_{i=1}^{V}\omega_{i}$, where $\omega_{i}$ is the number of heavy meson internal lines for the $i_{th}$ bilinear vertex. Then, we arrive to our final equations,

[TABLE]

Note the very important property that $\nu$ is bounded from below for any Feynman diagram with a given number of external pion lines and sources. For the first sum in the right hand side of Eq. (14) one has that

[TABLE]

as $\delta_{i}=2n$ ($n\in\mathbb{N}\backslash\{0\}$) and $n_{i}\geq 2$, except possibly for a finite number of vertices in a Feynman diagram that could contain less than two pion lines with $\delta_{i}=2$. Similarly

[TABLE]

since for pion-nucleon vertices $d_{i}\geq 1$ and $v_{i}\geq 1$, except for the finite number of vertices in a given Feynman diagram which would not have pion lines but only external sources from ${\cal L}_{\pi N}$ with $d_{i}=1$. For the bilinear vertices mediated by heavy lines this is also the case because $\omega_{i}\geq 1$, $v_{i}\geq\omega_{i}$, though here $d_{i}\geq 0$. Let us stress that the vertices that would not fulfill Eqs. (15) and (16) are finite in number because one always has external sources attached to them, whose number is finite. For the evaluation of the correlation function of $n$ external sources they could contribute at most a negative chiral power of $-2n$, taking the most disfavorable case in which every external source is attached to a different pure mesonic vertex with $\delta_{i}=2$ and $n_{i}=0$. It is specially important to note that adding a new IGV to a connected diagram increases the counting at least by one unit because of the last term $V_{\rho}$ in Eq. (14).

The number $\nu$ given in Eq. (14) represents a lower bound for the actual chiral power of a diagram, let us call this by $\mu$, and then $\mu\geq\nu$. The reason why $\mu$ might be different from $\nu$ is because the nucleon propagators are counted always as ${\cal O}(p^{-2})$, while for some diagrams there could be baryon propagators following the standard counting. The point of Eq. (14) is that it allows to ensure that no other contributions to those already considered would have a lower chiral order. As a result, it can handle systematically the anomalous chiral counting introduce above.

From Eq. (14) it is clear that one can augment the number of lines in a diagram without increasing the power counting by:

Adding pion lines attached to the lowest-order meson vertices, $\delta_{i}=n_{i}=2$. 2. 2.

Adding pion lines attached to the lowest-order meson-baryon vertices, $d_{i}=v_{i}=1$. 3. 3.

Adding heavy meson lines attached to the lowest-order bilinear vertices, $d_{i}=0$, $w_{i}=1$.

There is no way to decrease the chiral order for a given process. We apply Eq. (14) by increasing step by step $V_{\rho}$ up to the order pursued. For each $V_{\rho}$ then we look for those diagrams that do not further increase the order according to the previous list. Some of these diagrams are indeed of higher order and one can refrain from calculating them by establishing which of the baryon propagators scale as ${\cal O}(p^{-1})$. In this way, the actual chiral order of the diagrams is determined and one can select those diagrams that correspond to the precision required.

Let us now elaborate on the important scales appearing in the low-momentum calculations in nuclear matter. Taking into account that a term in a Lagrangian density has dimensions $[p^{4}]$, we have that the pure meson vertices with $a$ pion fields $\phi$ and $b$ derivatives (every of them gives rise to a soft momentum factor of order $p$), contributes with a monomial that scales as

[TABLE]

where $f$ is the pion weak decay constant in the chiral limit and $\Lambda$ is a generic hard scale that does not vanish in the chiral limit. In addition, we also have the IGVs that behave as effective vertices connected by meson lines. Each of them contains at least one three-momentum integration up to a Fermi momentum of at least one Fermi-sea insertion, so that instead of Eq. (17) we have contributions that scale typically as

[TABLE]

with $\rho$ the nuclear matter density. One expects a suppression of a chiral power 3 for the in-medium contributions because of the $\rho$ factor. Indeed, by directly taking the quotient of Eqs. (18) and (17) we have

[TABLE]

with $\upsilon$ a number of ${\cal O}(1)$. This equation implies that compared with the vacuum scale the in-medium one is expected to be somewhat reduced by the numerical factors from the expression of $\rho$. Taking literally the left hand side of Eq. (19) (although ${\cal O}(1)$ numerical factors could float), one has that while in vacuum the loop scale is $4\pi f$ (see e.g. chapter 5.9 of Ref. [19]), it would be $3\pi f$ for pure neutron matter and $3\pi f/2$ for symmetric nuclear matter. We have taken into account that $\rho=\xi^{3}/3\pi^{2}$ in the former case and $\rho=2\xi^{3}/3\pi^{2}$ in the latter. Thus, in the nuclear medium the expansion scale $\Lambda_{\xi}$ is expected to be given by $\Lambda_{\xi}=\upsilon\pi f$, and it is not really larger than the mass of the $\rho(770)$ resonance, as $4\pi f$ is. In this way, for symmetric nuclear matter at the saturation density with $\xi\simeq 2m_{\pi}$ we expect corrections to our results of ${\cal O}(2m_{\pi}/\Lambda_{\xi})\simeq 0.3$.

The presence of the anomalous counting makes that instead of $p^{-1}$ associated with a baryon propagator in the IGV one has $(p^{2}/2m)^{-1}$. To fix ideas, let us assume that we have one of such enhanced baryon propagators. Then, instead of Eq. (18) we would have

[TABLE]

Taking the quotient of this equation with Eq. (17) for the vacuum contributions, we have now the suppression factor

[TABLE]

In this equation the last term on the right hand side is the same one as in the standard case, but now the in-medium scale in the first factor is much reduced. Let us denote the latter by $\Lambda_{\rm low}$, which is then given by

[TABLE]

In many instances the factor $2m$ in the denominator is multiplied by the nucleon axial coupling squared, $g_{A}^{2}\simeq 1.7$, from the one pion exchange. Therefore, one has that $\Lambda_{\rm low}$ compared to $\upsilon\pi f$ is reduced typically by a factor around 2–4.

Due to the smallness of $\Lambda_{\rm low}$ it is essential for systematic calculations in the nuclear medium to derive an in-medium power counting. This is the most important point of the power counting developed in Ref. [12] and summarized here, driving to Eq. (14). Despite the importance of this fact our research is the only one within the many groups applying ChPT to the nuclear medium that proceeds strictly according to an in-medium power counting that takes into account the infrared enhancements of the baryon propagators. Typically, the approaches followed in the literature, e.g. Refs. [20, 21, 22] and references therein, are based on a straightforward application of the vacuum chiral power counting to in-medium calculations. The goal in those calculations is to apply perturbation theory to determine different magnitudes or to calculate input quantities that are used within more or less sophisticated many-body methods.

3 Nucleon-nucleon interactions

The inclusion of the $NN$ interactions for the calculation of different nuclear-matter properties takes place at NLO, because they require at least $V_{\rho}=2$. As a result, for the NLO calculations it is only necessary to work them out at the lowest chiral order or ${\cal O}(p^{0})$. The $NN$ interactions were approximated in Refs. [13, 14] by employing a handy approach based on Unitary Chiral Perturbation Theory (UChPT), whose main facets are reviewed here [23, 13]. Of course, it is desirable, as future advances in the field, to include the $NN$ interactions in the powerful novel non-perturbative theory based on the application of the exact calculation of the discontinuity along the left-hand cut (LHC) of a $NN$ partial-wave amplitude and then applying the exact $N/D$ method [24].

3.1 Vacuum $NN$ interactions

For the two-nucleon irreducible diagrams we follow the standard chiral counting [2, 3]. Accordingly, the lowest order amplitudes, which count as ${\cal O}(p^{0}$), are given by the quartic nucleon Lagrangian, without quark masses or derivatives, and by the one-pion exchange (OPE) expressed in terms of the lowest order pion-nucleon coupling $\frac{ig_{A}}{2f}\vec{\sigma}\cdot{\mathbf{q}}\,\vec{\tau}\cdot\vec{\pi}$. Here $\sigma_{i}$ and $\tau_{i}$ are the Pauli matrices in the spin and isospin spaces, in this order. The ${\cal O}(p^{0})$ lowest order four nucleon Lagrangian is [3]

[TABLE]

which only contributes to the S-wave nucleon-nucleon scattering. The resulting scattering amplitude from the previous Lagrangian for the process $N_{s_{1},i_{1}}({\mathbf{p}}_{1})N_{s_{2},i_{2}}({\mathbf{p}}_{2})\to N_{s_{3},i_{3}}({\mathbf{p}}_{3})N_{s_{4},i_{4}}({\mathbf{p}}_{4})$, where $s_{m}$ and $i_{m}$ are spin and isospin labels, is

[TABLE]

Because of the selection rule $S+\ell+I=$odd (with $S$ and $I$ the total spin and isospin of the system and $\ell$ its orbital angular momentum), that holds for any possible $NN$ partial wave due to the Fermi statistics, the only partial waves from Eq. (24) are

[TABLE]

In addition, one also has the OPE amplitudes, depicted in Fig. 4, which are given by

[TABLE]

with ${\mathbf{q}}={\mathbf{p}}_{3}-{\mathbf{p}}_{1}$ and ${\mathbf{q}}^{\prime}={\mathbf{p}}_{4}-{\mathbf{p}}_{1}$. For the singlet case ($S=0$) and $I=0,~{}1$ one has,

[TABLE]

For the triplet case ($S=1$) a $3\times 3$ matrix results with labels given by the third component of the total spin, $\sigma_{f}$, $\sigma_{i}$, with the subscripts $f$ (rows) and $i$ (columns) referring to the final and initial third components, respectively:

[TABLE]

The Cartesian coordinates of ${\mathbf{q}}$ are indicated as subscripts. The isoscalar and isovector amplitudes are, in this order,

[TABLE]

Considering the Eqs. (27) and (29), one can calculate the corresponding $NN$ OPE partial-wave amplitudes. Since the OPE scattering amplitudes in these equations are already given in terms of $NN$ states with definite spin and isospin, this calculation simplifies to

[TABLE]

where we use the notation $(m_{1}m_{2}m_{3}|j_{1}j_{2}j_{3})$ for the Clebsch-Gordan coefficients of the composition of two angular momenta $j_{1}$ and $j_{2}$ to give $j_{3}$, with third components $m_{i}$, and the $Y_{\ell}^{m}({\mathbf{p}})$ are the spherical harmonics. In practical evaluations we keep all the partial waves up to and including $\ell=3$. Explicit expressions for the resulting OPE $NN$ partial waves $N_{JI}^{1\pi}(\bar{\ell},\ell,S)$ are given in Appendix A.

The sum of the local contributions, Eq. (25), and the OPE partial-wave amplitudes, Eq. (30), is represented diagrammatically in the following by the exchange of a wiggly line as in Fig. 5.

As it is well known, Weinberg argued [2, 3] that due to the large nucleon mass one has to resum the two-nucleon reducible diagrams, as it is schematically depicted in Fig. 6. Indeed, this is also required by applying the power counting of Eq. (14), cf. points 2 and 3 for increasing the number of internal lines in a Feynman graph without increasing the chiral order. For these diagrams the nucleon propagators follow the non-standard counting and each of them is ${\cal O}(p^{-2})$. The two nucleon propagators altogether are ${\cal O}(p^{-4})$, which are multiplied by the ${\cal O}(p^{4})$ contribution from the measure of the loop integral, and then an ${\cal O}(p^{0})$ contribution results. Thus, it does not rise the chiral order when the wiggly lines are evaluated at lowest order, ${\cal O}(p^{0})$, and the series of diagrams in Fig. 6 must be resummed. The resummation of the two-nucleon reducible diagrams makes the resulting amplitude to fulfill unitarity. For this resummation, Refs. [12, 13] follow the techniques of UChPT [25, 26, 27, 28], which allow to resum the right hand cut (RHC) or unitarity cut partial wave by partial wave. UChPT has also been applied with great success in meson-meson [25, 28, 29, 30, 31, 32] and meson-baryon scattering [33, 26, 34, 35, 36, 37], among many other references. For the study of the $NN$ interactions UChPT was already applied in Ref. [23].

The master equation for UChPT is the same independently of whether we have fermions, mesons or both in the scattering process and can be written as [26]

[TABLE]

where we have used a matrix notation valid also for coupled channels mixing different orbital angular momenta, $\bar{\ell}$ and $\ell$. In the previous equation $g(p^{2})$ is the unitarity loop function drawn in Fig. 7. For $NN$ scattering with non-relativistic kinematics the function $g(p^{2})$ reads

[TABLE]

with $g_{0}$ the value of $g(p^{2})$ at threshold, $p^{2}=0$. In the case of coupled partial waves, $g(p^{2})$ is actually a diagonal matrix that corresponds to the product of the right hand side of Eq. (32) with the $2\times 2$ identity matrix.

The Eq. (31) results by performing a once subtracted dispersion relation of the inverse of a partial-wave amplitude. The latter fulfills, because of unitarity,

[TABLE]

in the CM frame and above the elastic threshold. A dispersion relation along the physical energy axis from threshold up to infinity is written. One subtraction is needed because $p=\sqrt{2mE}$, with $E$ the kinetic energy of one nucleon in the CM. As a result of this dispersion relation one ends up with a once-subtracted dispersive representation of $g(p^{2})$ which reads

[TABLE]

where $\kappa^{2}<0$ and then $g(\kappa^{2})$ is real because there is an imaginary part only above threshold. This integral can be done explicitly with the result,

[TABLE]

This function corresponds to the divergent integral

[TABLE]

In terms of a three-momentum cut-off $\Lambda$ the function $g(p^{2})$ in the previous equation becomes

[TABLE]

Comparing with Eq. (35) it follows that

[TABLE]

The LHC contributions to $T_{JI}(\bar{\ell},\ell,S)^{-1}$ are parameterized by the inverse of the matrix $N_{JI}(\bar{\ell},\ell,S)$, that has only LHC. For clarification, notice that we can write Eq. (31) equivalently as $T_{JI}(\bar{\ell},\ell,S)=\left[N_{JI}(\bar{\ell},\ell,S)^{-1}+g(p^{2})\right]^{-1}$.

Next, $N_{JI}(\bar{\ell},\ell,S)$ is determined by matching with the perturbative result in an expansion in powers of $g(p^{2})$ of Eq. (31) up to the same number of two-nucleon reducible loops (so that the resulting $N_{JI}$ has no LHC by construction). The aforementioned expansion corresponds to the geometric series

[TABLE]

Together with this expansion one also has the standard chiral one (in which a unitarity loop function $g(p^{2})$ counts as ${\cal O}(p)$, because of the factor $p$ in Eq. (35), despite it is multiplied by the large nucleon mass). In this way, for determining $N_{JI}^{(n)}$ one has to match the ${\cal O}(p^{n})$ ChPT calculation of a $NN$ partial wave with at most $n$ two-nucleon reducible loops with Eq. (39), where $N_{JI}$ is also expanded up to the considered order

[TABLE]

Here, the chiral order is indicated by the superscript. Thus, at lowest order $N_{JI}^{(0)}(\bar{\ell},\ell,S)$ is given by the calculation in ChPT at ${\cal O}(p^{0})$ without any two-nucleon reducible loop (the first diagram in Fig. 6 from left to right). At ${\cal O}(p)$ the new contribution is the two-nucleon reducible part of the second diagram in the same figure, that for a given partial wave is denoted by $L^{(1)}_{JI}(\bar{\ell},\ell,S)$. It corresponds to the reducible part of the first iteration of the one-pion exchange plus local vertices. Writing $N_{JI}=N_{JI}^{(0)}+N_{JI}^{(1)}+{\cal O}(p^{2})$, and matching Eq. (39) up to order $g$ with the sum of the first two diagrams in Fig. 6 one has

[TABLE]

with the result

[TABLE]

Notice that in the expansion of Eq. (39) each factor of the kernel $N_{JI}(\bar{\ell},\ell,S)$ multiplies the loop function $g$ with its value on-shell. This is why in Eq. (41) we have $-N_{JI}^{(0)}\cdot g\cdot N_{JI}^{(0)}$ for the first order in $g$. This result is then subtracted to the function $L^{(1)}_{JI}$ in Eq.(42) (which guarantees the absence of LHC in $N_{JI}$). The difference is incorporated in the interaction kernel $N_{JI}(\bar{\ell},\ell,S)$, that can be improved order by order.

At ${\cal O}(p^{2})$ new contributions arise which require the calculation of the irreducible part of the box diagram in Fig. 6 and the reducible part of the second iteration of the wiggly line, last diagram of Fig. 6. In addition there are also chiral counterterms from the NLO quartic nucleon Lagrangian and two-nucleon irreducible pion loops [38, 39, 40]. If we denote all these new contributions by $L_{JI}^{(2)}(\bar{\ell},\ell,S)$, projected in the corresponding partial wave, one ends with

[TABLE]

That is, we are subtracting to $L_{JI}^{(2)}$ the two-nucleon reducible contributions obtained from Eq. (39) up to ${\cal O}(p^{2})$, in the UChPT expansion of the interaction kernel $N_{JI}(\bar{\ell},\ell,S)$.

The resulting $N_{JI}$, Eq. (40), is then substituted in the non-perturbative Eq. (31) giving the full partial-wave amplitudes $T_{JI}(\bar{\ell},\ell,S)$. One should also stress that Eq. (31) is an algebraic one, which simplifies tremendously the numerical burden for in-medium calculations.

An important point is that $N_{JI}$ obeys a non-linear integral equation as derived in Ref. [13]. Its discontinuity along the LHC is given by

[TABLE]

This result can be used to write down a once-subtracted dispersion relation for $N_{JI}$,

[TABLE]

more subtractions can also be taken. Since $N_{JI}$ was fixed above by matching with a chiral expansion, the LHC is treated perturbatively. Therefore, the most convenient and consistent choice for $g_{0}$ is such that the function $g(p^{2})$ has a zero in the low-energy part of the LHC for $p\simeq i\,m_{\pi}$. In this way, the iteration of the LHC contribution from Eq. (45) is expected to have the smallest impact at low energies. This implies from Eq. (35) that within our approach the expected value for $g_{0}$ is negative and around

[TABLE]

We now concentrate on fixing the constants $C_{S}$ and $C_{T}$ from the local quartic nucleon Lagrangian, Eq. (23). These constants and $g_{0}$ are the only free parameters that enter in the evaluation of the $NN$ scattering amplitudes from Eq. (31) up to ${\cal O}(p)$. The counterterms $C_{S}$ and $C_{T}$ are fixed by considering the S-wave $NN$ scattering lengths $a_{t}$ and $a_{s}$ for the triplet and singlet S-waves, respectively. At ${\cal O}(p^{0})$ we have

[TABLE]

where LO stands for leading order. Note that the OPE amplitudes, Eq. (26), vanish at the $NN$ threshold because they depend quadratically on the nucleon three-momentum. For the partial-wave amplitudes#2#2#2For general considerations the already introduced notation $T_{JI}(\bar{\ell},\ell,S)$ is employed. Specific partial waves are denoted by the standard spectroscopic notation $T(^{2S+1}\ell_{J})$. ${}^{1}S_{0}$ and ${}^{3}S_{1}$ at threshold one has from Eq. (47),

[TABLE]

The term $-(C_{S}-3C_{T})$ for $N_{01}$ is a factor 2 smaller than $T_{NN}^{c}(^{1}S_{0})$ in Eq. (25), and similarly also for the triplet case, because $N_{JI}$ is given by the direct term. The resulting expressions for the scattering lengths from Eq. (48) are

[TABLE]

So that

[TABLE]

One of the characteristics of $NN$ scattering are the large absolute values of the S-wave scattering lengths $a_{s}=(-23.758\pm 0.04)$ fm and $a_{t}=(5.424\pm 0.004)$ fm. For typical values of $\Lambda$, $\Lambda\gg|1/a_{s}|$, $1/a_{t}$, and then $|C_{S}|\simeq 2\pi^{2}/m\Lambda\gg|C_{T}|={\cal O}(\pi^{3}/a_{t}/m\Lambda^{2})$. Because of the introduction of the subtractions constant $g_{0}$, the low-energy counterterms $C_{S}$ and $C_{T}$ do not diverge for $a_{s}$, $a_{t}\to\infty$. In this way, $\Lambda$ is a new scale that adds to the inverse of the scattering lengths so that their sum, the one that appears for determining the values of $C_{S}$ and $C_{T}$, Eq. (50), has a natural size. Thus, this procedure gives rise to values of the chiral counterterms $C_{S}$ and $C_{T}$ that are consistent with their ascribed ${\cal O}(p^{0})$ scaling.

Indeed, taking into account that: i) Eq. (50) is the same as in the pionless $NN$ EFT, because the pion-exchange contribution to $N_{JI}^{(0)}$ vanishes at threshold. ii) Naive dimensional analysis implies that $C_{S},\,C_{T}\sim 4\pi/mQ$, with $Q$ the expansion scale for the pionless EFT because of i). It follows then that $\Lambda$ should be comparable to $Q$ so that $\Lambda\sim Q={\cal O}(m_{\pi})$. Note also that the order of $C_{S}$ in Eq. (50) is fixed by the product $m\Lambda$, which is ${\cal O}(p^{0})$ for $\Lambda={\cal O}(p)$ because of the largeness of the nucleon mass. This is completely analogous to having counted before the loop function $g(p^{2})$ as ${\cal O}(p^{0})$ because of the factor $mp$ in Eq. (35). Let us also recall that, from the consistency requirement of treating perturbatively the LHC within our approach, the estimate $\Lambda\sim m_{\pi}$ is required by our previous estimate of $g_{0}$ in Eq. (46). One has to stress that only local terms and OPE contributions enter in the calculation of $N^{(0)}_{JI}(\bar{\ell},\ell,S)$. This is certainly too simplistic in order to accurately describe the $NN$ phase shifts, although it might be sensible for capturing the bulk properties in nuclear matter, as explicit applications show [13, 15].

3.2 In-medium $NN$ interactions

The nucleon propagator in nuclear matter, $G(k)_{i_{3}}$, contains both the free and the in-medium contributions [41],

[TABLE]

In this equation the subscript $i_{3}$ refers to the third component of isospin of the nucleon, so that, $i_{3}=+1/2$ corresponds to the proton and $-1/2$ to the neutron, and the symbol $\xi_{i_{3}}$ is the Fermi momentum of the Fermi sea for the corresponding nucleon. Equivalently, we also use $\xi_{p}=\xi_{+1/2}$ and $\xi_{n}=\xi_{-1/2}$ for the proton and neutron Fermi momenta. We consider that isospin symmetry is conserved so that all the nucleon and pion masses are equal. The Eq. (51) can also be written equivalently as

[TABLE]

The first (second) term on the right hand side of this equation is known as the particle (hole) part of the nucleon propagator. One can gather in a matrix notation the proton and neutron propagators as

[TABLE]

or in the equivalent manner

[TABLE]

When calculating a loop function in the nuclear medium Ref. [13] uses the notation $L_{ij}$, where $i$ indicates the number of two-nucleon states in the diagram (0 or 1) and $j$ the number of pion exchanges (0, 1 or 2). In addition, one also uses $L_{ij,f}$, $L_{ij,m}$ and $L_{ij,d}$, with the subscripts $m$ and $d$ indicating one or two Fermi-sea insertions from the nucleon propagators in the medium, respectively. The subscript $f$ refers to the “free” part and therefore it does not involve any Fermi-sea insertion. The labels $f$, $m$ and $d$ originate because the nucleon propagator in the nuclear medium contains both a free and an in-medium part, the last proportional to the Dirac delta function in Eq. (51). In this notation $g(p^{2})=L_{10,f}$ and its in-medium counterpart is $L_{10}$. These functions are calculated in the Appendix B.

We use the same Eq. (31) but now the function $g(p^{2})$ is substituted by $L_{10}$. The same process as previously discussed is then used to fix $N_{JI}$ in the medium. At lowest order they can be easily obtained from our previous result in the vacuum since the only modification without increasing the chiral order is by using the corresponding nucleon propagator in the medium, which is directly accomplished by replacing $g(p^{2})$ by $L_{10}$. Note that any further in-medium contribution requires to increase $V_{\rho}$ by at least one unit, which then increases, at a minimum, the chiral order one more unit, cf. Eq. (14). The modification of the meson propagators (both for heavy mesons or pions) by the inclusion of an IGV increases the chiral order by two units at least. However, the modification of the enhanced nucleon propagators with one IGV only increases the order by one more unit and these contributions must be kept when calculating the $NN$ scattering amplitudes at NLO. The difference stems from the fact that a lowest-order modification of a meson propagator requires the inclusion of an IGV with two meson lines which, according to Eq. (14), increases the power counting by two units. However, for the baryonic line we would have only one unit of increase because the introduction of the extra IGV.

Then, Eq.(31) for the $NN$ partial-wave in the nuclear medium becomes

[TABLE]

and $N_{JI}^{I_{3}}=N_{JI}^{(0)}$ at LO. We have included the superscript $I_{3}$ in Eq. (54), which corresponds to the third component of the total isospin of the two nucleons involved in the scattering process. This is due to the fact that in the nuclear medium the Fermi momenta of the neutrons and protons might be different. In this way, $L_{10,m}$ and $L_{10,d}$ depend on weather one has two protons, neutrons or a proton and a neutron as intermediate states. As a result, a $NN$ partial wave in the nuclear medium depends on the total charge of the intermediate state. Of course, this is not the case for the $NN$ interactions in vacuum where they only depend on the total isospin, but not on its third component. Let us also stress that the absolute value of the total isospin of the $NN$ state, $I$, is a good quantum number and does not mix because of the $NN$ interactions. The function $L_{10}$ conserves $I$, because it is symmetric under the exchange of the two nucleons, though it depends on the charge (or third component of the total isospin) of the intermediate state. This is a general rule, all the $I_{3}=0$ operators are symmetric under the exchange $p\leftrightarrow n$, so that they do not mix isospin representations with different exchange symmetry properties.

4 Nuclear-matter energy density

In this section we consider the energy per nucleon in nuclear matter, ${\cal E}/\rho$, with ${\cal E}$ corresponding to the energy density. For this case we have to apply Eq. (14) without external legs, and the contributions up to NLO are depicted in Fig. 8. From left to right and top to bottom in this figure, the three types of contributions are denoted as ${\cal E}_{1}$, ${\cal E}_{2}$ and ${\cal E}_{3}$, in this order, and are evaluated in Ref. [13]. The LO diagram (1) counts as ${\cal O}(p^{5})$ and the NLO ones, (2) and (3),#3#3#3As a rule, a set of diagrams indicated in a figure as $(i.j)$, with different $j$, are denoted collectively as $(i)$. as ${\cal O}(p^{6})$.

The LO term corresponds to the kinetic energy of the nucleons and it is suppressed because it is a recoil correction and has a large nucleon mass in the denominator. Its expression is [13]

[TABLE]

where we have indicate by $\rho_{p}$ and $\rho_{n}$ the proton and neutron densities, respectively. They are related to the Fermi momenta of the nucleons by

[TABLE]

with $i=1$ referring to proton and $i=2$ to neutron.

For the second contribution ${\cal E}_{2}$, one has the integration over the Fermi seas of the in-medium nucleon self-energy due to a pion loop. The contribution for the second diagram in Fig. 8 with an in-medium part in the baryon propagator underneath the pion propagator (dashed line) is not considered in (2) because it is accounted for by the diagram (3.2), by the contribution involving only one pion line in the $NN$ interaction. In this way Ref. [13] derives the following expression for ${\cal E}_{2}$,

[TABLE]

where $\Sigma_{f}^{\pi}$ is the free part of the pion one-loop self-energy of the nucleon. Its expression is a well-known result in Heavy-Baryon ChPT [42], which is also calculated in Ref. [13], and given by

[TABLE]

where $\omega$ is the energy of the nucleon (discounted its vacuum rest mass) and $b=m_{\pi}^{2}-\omega^{2}-i\epsilon$. In the previous expression the value of the self-energy at $\omega=0$ is subtracted since we employ the physical nucleon mass $m$.

The calculation of the diagrams (3.1) and (3.2) of Fig. 8 requires the evaluation of the self-interacting expression

[TABLE]

One has in this equation the symmetry factor 1/2 and the sum over the spin ($\sigma_{i}$) and isospin ($\alpha_{i}$) labels. At the end of the calculation one should take the limit $\eta\to 0^{+}$. The convergent factors ($e^{i\eta k_{i}^{0}}$) are introduced so that every pure vacuum contribution (without any in-medium insertion) is eliminated by construction in the calculation [41]. This follows because the free part of a baryon propagator, Eq. (52), has only a cut for negative values of the imaginary part. In this way, by closing the energy loop integrations along the upper half-plane, thanks to the convergent factors, one avoids the purely vacuum contributions.

It is convenient to employ CM and relative momentum variables, $a$ and $p$, respectively, defined by

[TABLE]

We also introduced the variable $A$ (instead of $a^{0}$) as the difference

[TABLE]

Notice that $A={\mathbf{p}}^{2}$ in the CM frame.

We employ in Eq. (59) the in-medium $NN$ scattering amplitudes as calculated at LO, for which the interaction kernel $N_{JI}^{I_{3}}(\bar{\ell},\ell,S)$ in Eq. (54) only depends on ${\mathbf{p}}^{2}$. The unitarity loop function $L_{10}^{I_{3}}$, cf. Appendix B, depends on $|\mathbf{a}|$ and $A$. As a result the integrand in Eq. (59) only depends on $p^{0}$ through the two explicit nucleon propagators, and this integration can be readily done with the resulting expression [13]

[TABLE]

We proceed next to perform the integration in the variable $A$ by closing the integration contour with a half circle in the upper half plane of the complex $A$ plane by taking advantage of the convergent factor $e^{iA\eta}$.#4#4#4Indeed, one does not really need to invoke the presence of this convergent factor because of the dependence on $A$ of $T^{\sigma_{1}\sigma_{2}}_{\alpha_{1}\alpha_{2}}({\mathbf{p}},\mathbf{a};A)$. As discussed above, the cuts due to the particle-particle contribution in the unitarity loop function give rise to a cut running parallel to the real axis but with slightly negative imaginary part. Therefore, only the hole-hole contribution in $L_{10}^{I_{3}}$ gives rise to a cut with slightly positive imaginary part but of finite extent (for more details see Eq. (B.3) and the discussions that follows there). The latter is represented in Fig. 9 by the dashed line, it extends from $A(\alpha)$ to $B(\alpha)$ with $\alpha=|\mathbf{a}|$, and it is given in Eq. (B.21). The integration contours $C_{I}$ and $C_{I^{\prime}}$ avoid this cut by running slightly above and below it. In order to perform the integration in $A$ we make use of the equalities

[TABLE]

Subtracting Eq. (64) to Eq. (63) we then have for the integration sought

[TABLE]

The difference of the $T$ matrices is not zero due to the contribution to the unitarity cut from the hole-hole part of $L_{10}$. From the partial-wave expansion of the $T$ matrix and the calculation of $L_{10}^{I_{3}}$ in Appendix B it results [13]

[TABLE]

The isospin index $I_{3}=\alpha_{1}+\alpha_{2}$, and for $I_{3}=0$ one should take just one of the two possible cases with $\alpha_{1}=-\alpha_{2}$, $|\alpha_{1}|=1/2$ for evaluating $L_{10}^{I_{3}}$. The symbol $\chi(S\ell I)$ is defined as

[TABLE]

An important technical point demonstrated in Ref. [13] is that ${\cal E}_{3}$ from Eq. (66) is purely real, despite it involves complex functions. We do not repeat here the general demonstration given in this reference, which is based on Pauli blocking, unitarity and the fact that $N_{JI}$ has no RHC (the latter stems only from $L_{10}$).

The LO UChPT calculation of $T_{JI}$ implies that the product

[TABLE]

which appears in the last integral of Eq. (66), tends to constant for ${\mathbf{p}}^{2}\to\infty$. As a result this integral is linearly divergent. The regularization undertaken in Ref. [13] consists of adding and subtracting the limiting value for $p^{2}\to\infty$ of the previous sum, denoted by $\Sigma_{\infty\ell}$. The integration of the difference $\Sigma_{p\ell}-\Sigma_{\infty\ell}$ is finite because it vanishes as $p^{-2}$ for $p^{2}\to\infty$. The remaining divergence is multiplied by the constant $\Sigma_{\infty\ell}$ and is of the same type as the one stemming from the unitarization of the $NN$ amplitudes, cf. Eq. (36), which is then regularized by including a constant $\widetilde{g}_{0}$. The resulting expression is [13]

[TABLE]

Therefore, we have two constants $\widetilde{g}_{0}$ and $g_{0}$. The latter comes from the $NN$ scattering amplitudes, with a value estimated in Eq. (46), and the former has appeared specifically in the calculation of the in-medium density energy. In principle both parameters should be the same. As a first exercise, let us vary $g_{0}=\widetilde{g}_{0}$ in order to improve the description of ${\cal E}/\rho$ (that is, the energy per nucleon) for the case of neutron matter, so that our results agree better with the magenta dotted line in the left panel of Fig. 10 that corresponds to the sophisticated many-body calculation of Ref. [43]. The latter employs realistic $NN$ interactions, and also includes a free parameter to mimic the three-nucleon ($3N$) interactions. The black dashed line in Fig. 10 is obtained by employing $g_{0}=\widetilde{g}_{0}=-0.62~{}m_{\pi}^{2}$, which closely reproduces the results of Ref. [43], even up to rather high densities. Note as well that this result is obtained with a value of $g_{0}$ which is still very close to its natural size of around $-0.55~{}m_{\pi}^{2}$, cf. Eq. (46).

However, if we employ the same value for $g_{0}=\widetilde{g}_{0}$ to evaluate ${\cal E}/\rho$ in the case of symmetric nuclear matter the resulting curve has the minimum at its right position, $\rho\simeq 0.16~{}$fm3, but the value of the energy per baryon is around $-42$ MeV, which is an over-binding by a factor 2.5. Therefore, in order to improve this fact we allow different values for $g_{0}$ and $\widetilde{g}_{0}$ so as to mimic higher order contributions (we already discussed at the end of Sec. 2 that, because of the size of $\Lambda_{\xi}$, we expect corrections of around 30% from higher order contributions at the nuclear matter saturation density). Once $g_{0}$ is fitted to provide a good reproduction of the properties of the minimum energy per baryon and saturation density in symmetric nuclear matter we then obtain a good reproduction of the results of Ref. [43] as well. We show by the two red solid lines in the right panel of Fig. 10 the results obtained by Ref. [13] with the values $(g_{0},\widetilde{g}_{0})=(-0.977,-0.512)~{}m_{\pi}^{2}$ and $(-0.967,-0.525)~{}m_{\pi}^{2}$, in this order from top to bottom in the figure. These curves run very close to the sophisticated and standard many-body calculation of Ref. [43]. Again the value for the subtraction constant $\widetilde{g}_{0}$ is very close to the expectation from Eq. (46), while that for $g_{0}$ is off by a factor less than 2 [which is still a number of ${\cal O}(1)$]. At the saturation point one has the minimum value for ${\cal E}/\rho$ with the results $-15.4$ and $-17.1$ MeV, respectively. The experimental value given by the cross corresponds to $-16\pm 1~{}$MeV. The densities for the minimum energy per baryon are $\rho=0.169$ and $\rho=0.168$ fm*-3*, respectively, compared to the empirical value $\rho=0.166\pm 0.019$ fm*-3*. It is clear that our results reproduce the saturation point and agree with the calculation of ref. [43] remarkably well.

Let us also clarify that the different curves in the two panels of Fig. 10 for the results of Ref. [13] are not intended to show the intrinsic uncertainty in the calculation. In the case of symmetric nuclear matter the two curves stem from the reproduction of the minimum value of ${\cal E}/\rho$ and the saturation density approximately within their error ranges. For the neutron matter case the two curves correspond to either keeping the constraint $g_{0}=\bar{g}_{0}$ or allow for different values (the red solid curve has ($g_{0},\widetilde{g}_{0})=(-0.62,-0.65)~{}m_{\pi}^{2}$). A close reproduction of the results of [43] for neutron matter requires that indeed these two scenarios are basically coincident.

The blue dashed line in Fig. 10 originates by the parameterization of the energy per baryon in symmetric nuclear matter as

[TABLE]

Interestingly, the parameters $\alpha$ and $\beta$ in the previous equation are fixed by adjusting the empirical position and minimum value of the nuclear matter saturation point. The dashed line runs very close to the solid lines determined in Ref. [13] and starts to deviate for densities above $\rho\simeq 0.25$ fm*-3*. The nuclear matter incompressibility is given by the double derivative

[TABLE]

with $\xi_{0}$ the Fermi momentum at the saturation point. From the parameterization in Eq. (70) one has $K=259~{}$MeV, with $\alpha$ and $\beta$ determined by using the values of the point with errorbars in the right panel of Fig. 10. This value is well inside the experimental determination $K=250\pm 25~{}$MeV [44]. The resulting nuclear matter incompressibility calculated from Eq. (69) is $K=254$ and $233~{}$MeV, for the upper and lower solid curves, respectively. These values are compatible with the experimental measurement.

5 Application of the EOS to neutron stars

As an application of the energy density ${\cal E}(\rho)$ calculated in Sec. 4, we consider the solution of the Tolman-Oppenheimer-Volkoff equation [45, 46] for the hydrostatic equilibrium of a cold non-rotating neutron star, as developed in Ref. [15]. We assume that the neutron star is composed purely of neutrons that interact between them by the strong and gravitational interactions. The latter is attractive and tends to bound the system to the smallest possible size, being eventually counterbalanced by the inter-neutron repulsion at short distances. This compensating mechanism is effective until a maximum mass of the star, above which the gravitation attraction could not be overcome by the strong interactions and the system would collapse into a black hole. As it is known since the work of Oppenheimer and Volkoff [46], a neutron gas with only gravitational interactions can support, because of the Pauli exclusion principle, a neutron star up to a maximum mass of around 0.7 solar masses ($M_{\odot}$). This is the simple, but fundamental, model of a degenerate cold Fermi gas of neutrons. In recent years, a neutron star with a mass of 1.97(4) $M_{\odot}$ was detected [16]. To fill the gap from 0.7 $M_{\odot}$ up to 2 $M_{\odot}$ an extra repulsion is needed beyond the Pauli exclusion principle. The latter implies that making the system more compact requires more energy, since one should end up having a bigger density and therefore a bigger Fermi momentum. Of course, the nuclear interactions provide extra and stronger repulsion that allows the increase of the maximum neutron-star mass up to around 2 $M_{\odot}$.

There are intriguing coincidences that make that this maximum neutron-star mass is only around a factor of 3 larger than the limit for a degenerate Fermi sea. This is triggered by the fact that the pion coupling between two nucleons in the realm of momenta probed in the neutron star (in turn given by the Newton gravitational constant $G$, $\hbar$, $c$ and the neutron mass $m$, as it is clear from the cold degenerate Fermi gas) is governed by the dimensionless combination of parameters $g_{A}^{2}m_{\pi}^{2}/f_{\pi}^{2}\simeq 3.5$, with $f_{\pi}$ the pion weak decay constant in vacuum. Another important scale is the mass of the neutron that suppresses the kinetic energy contribution to ${\cal E}$ and enhances the nuclear one, by giving rise to the relatively low scale $\Lambda_{\rm low}\sim\pi(4f_{\pi})^{2}/g_{A}^{2}m\simeq 2m_{\pi}$, despite that it does not involve any parameter vanishing in the chiral limit. This type of enhancement is typical of scattering between particles of heavy-mass compared to the typical three-momenta in the process.

The two basic equations that were used in the previous study of Ref. [15] for the application of the energy density derived in Ref. [13] to neutron stars in hydrostatic equilibrium are:

i) The thermodynamical expression giving the pressure $P$ as a function of the density $\rho$,

[TABLE]

This equation can be deduced by relating the energy density with the energy per unit mass $u$, ${\cal E}=u\rho m$, and then employing the equation $du=Pd\rho/(m\rho^{2})$, where we have taken into account that the mass density is $m\rho$.

ii) The Tolman-Oppenheimer-Volkoff equation

[TABLE]

where $r$ is the radial distance and $M(r)$ is the mass contained in a sphere of radius $r$. The knowledge of $P$ from Eq. (72), relating this magnitude with $\rho$, allows to solve the previous differential equation by giving an initial value to the pressure at $r=0$ and integrating up to the distance $r=R$ where it vanishes, being $R$ the radius of the star.

We show in the left panel of Fig. 11 the pressure as a function of the energy density. The EOS that follows from the calculation within the NLO in-medium ChPT of ${\cal E}(\rho)$ [13], and worked out in Ref. [15], is indicated by the red solid line, while the black dashed line corresponds to the cold degenerate Fermi-sea limit. In the figure the left side of the violet line is a region excluded because the sound velocity ($c_{s}^{2}=\partial P/\partial m\rho$) would be larger than the speed of light. Apart from this, since this constraint really refers to the slope of $P(m\rho)$ (notice that $m\rho\gg{\cal E}$), it also excludes the equations of state with a pressure raising too fast as a function of the energy density for large Fermi momentum. In addition, we have also shown two sets of dots that correspond to the results of Ref. [47]. Both of them include $2N$ interactions but, in addition, the red filled circles take into account $3N$ interactions while the black empty circles do not (more details are given in the many-body calculation of Ref. [48]). The $3N$ interactions make stiffer the resulting EOS.

Next, Ref. [15] obtained the mass-radius relation given by the red solid curve in the right panel of Fig. 11 from the solution of the Tolman-Oppenheimer-Volkoff equation with the EOS provided at NLO by in-medium ChPT [13]. It clearly allows for a neutron-star mass slightly above two solar masses, with a maximum of 2.15 $M_{\odot}$. The black dotted line is obtained by entering in a region that involves relatively high Fermi momenta, larger than 600 MeV, above which the chiral effective field theory is expected to break. Indeed, the NLO in-medium calculation of ${\cal E}(\rho)$ of Ref. [13] starts giving rise to a sound velocity larger than the speed of light for such large values of $\xi_{n}$. The allowed neutron-star mass then reaches the highest maximum value of 2.25 $M_{\odot}$.

We can also compare our prediction for the mass-radius relation in Fig. 11 with the most recent determinations from the event GW170817 observed by the LIGO and Virgo Collaborations [18]. Reference [49] has derived upper bounds for the maximum mass of a cold and spherical neutron star, $M_{\rm max}$, from the resulting kilonova observations associated to GW170817:

[TABLE]

The results obtained in Ref. [15] corresponding to the solid and dotted lines of Fig. 11, are in agreement with these upper bounds. The solid line, as explained above, does always involve Fermi momenta small enough so that $c_{s}<1$ in the whole process of solving the Tolman-Oppenheimer-Volkoff equation and it gives $M_{\rm max}=2.15~{}M_{\odot}$. Even the maximum value on the dotted line implies $M_{\rm max}=2.25~{}M_{\odot}$, which still is compatible with the values in Eq. (74).

Another constraint is put forward by Ref. [17], which concludes that the radius of a neutron star of mass $1.4\,M_{\odot}$, $R(1.4\,M_{\odot})$, should be between 9.9 and 13.6 km. Reference [17] obtains this range by taking into account: i) The existence of two solar-mass neutron stars. ii) The tidal deformability of a neutron star mass of $1.4~{}M_{\odot}$, $\Lambda(1.4M_{\odot})$, should be smaller than 800, as established by the LIGO and Virgo Collaborations in Ref. [18] from the GW170817 event. With this information, Ref. [17] constrains a rather generic family of equations of state that are matched at low and high densities with those derived by taking ingredients from chiral effective field theory [22] and the one from a N2LO perturbative QCD calculation for cold quark matter [50], in this order. From the red solid line in the right panel of Fig. 11 we have that $R(1.4\,M_{\odot})=12.3$ km, well inside the previous interval from Ref. [17]. Even if allowing for $\Lambda(1.4\,M_{\odot})<400$, as roughly suggested by the 50% of the contours in Fig. 5 of Ref. [18], the constraint $R(1.4\,M_{\odot})<12.5$ km can then be concluded [17], which is also fulfilled by our curve.

A main point of Ref. [15] is to use the knowledge of a sound EOS to put a constraint on the value of the Newton gravitational constant in an environment of strong gravitational field. The idea is that if $G$ increases for a given EOS, the system would become more compact due to the stronger gravitational attraction and, at some point, the maximum allowed mass for a neutron star would be smaller than the actual mass of 1.97(4) $M_{\odot}$ detected in Ref. [16]. It was found in Ref. [15] that, by employing the NLO in-medium ChPT calculation of ${\cal E}(\rho)$ from Ref. [13], this argumentation requires that $G$ cannot be more than 12% larger compared to its value on the surface of the Earth at the 95% confidence level in a 2 $M_{\odot}$ neutron star. As shown in the Fig. 5 of the same reference, the predicted gravitational acceleration in the star reaches a typical magnitude of $10^{13}~{}m/s^{2}$, therefore twelve orders of magnitude larger than the one on the surface of the Earth.

6 The in-medium temporal pion-decay constant, the quark condensate and the pion self energy

Two other important quantities to characterize the nuclear-matter state are the pion-decay constant, $f_{t}$, associated with the temporal component of the axial-vector current, and the quark condensate. These quantities were studied in Refs. [13] and [14] by applying in-medium ChPT up to NLO order. Before these works, Ref. [7] also considered the evaluation of these quantities, though non-perturbative $NN$ interactions were not included. However, as explained in Refs. [13], the latter contributions exactly cancel for the temporal-component coupling $f_{t}$ and the pion self-energy, so that the expressions obtained in Ref. [7] fully hold up to NLO. In the case of the in-medium quark condensate strong cancellations occur, though some NLO corrections to the result of Ref. [7] remain from the $NN$ interactions, as worked out in Ref. [14].

To be specific, let us consider the set of diagrams in Fig. 12 for the evaluation of the quark condensate up to ${\cal O}(p^{6})$ or NLO in the chiral counting of Eq. (14). The former is the expectation value of $m_{q}\langle\Omega|\bar{q}_{i}q_{j}|\Omega\rangle$, where $m_{q}$ is the mass of a certain quark flavor, and $|\Omega\rangle$ represents the interacting nuclear-matter state (which evolves from the pure Fermi seas of protons and neutrons at asymptotic times $t\to\pm\infty$ [4]). The diagrams (1)–(3) were already calculated in Ref. [7] and the ones at the bottom of the figure were discussed by Ref. [14]. The diagrams (4) and (5) arise from the quark mass dependence of the nucleon mass, while diagrams (6) do so from the quark mass dependence of the pion mass. It turns out that the set of diagrams (4) and (5) cancel each other. This is not only a characteristic of the quark condensate but also of the coupling $f_{t}$ to the temporal component of the axial-vector current [14] and of the pion self energy [12, 14]. In this way, the only remaining contribution involving the $NN$ interactions to the quark condensate are those from the diagrams (6), that involve only the long-range part of the $NN$ interactions from the OPE contribution in Fig. 5. It was also discussed in Ref. [14] that the Feynman-Hellmann theorem relating the value of the in-medium quark condensate and the derivative of the energy density of the nuclear medium with respect to the corresponding quark masses is fulfilled order by order.

A non-vanishing quark condensate is a sufficient condition for having chiral symmetry breaking, but it is not necessary. A sufficient and necessary condition for chiral symmetry breaking is that $f_{t}\neq 0$, because then $|\Omega\rangle$ is not invariant under chiral transformations [7]. As stated above, due to the mutual cancellation of the diagrams of types (4) and (5) in Fig. 12, the calculations of $f_{t}$ in Ref. [7, 14] and the in-medium pion self energy in Refs. [7, 13] hold up to NLO with the in-medium chiral counting of Eq. (14). It was found in Ref. [7] that $f_{t}$ decreases linearly with the density of the medium (because $V_{\rho}=1$ for the pertinent non-vanishing contributions), so that for symmetric nuclear matter the result found is

[TABLE]

with $\rho_{0}\simeq 0.16$ fm*-3*, the nuclear matter saturation density. This equation indicates a trend towards lower values of $f_{t}(\rho)$ as $\rho$ increases. Since $f_{t}(\rho)$ is an important quantity to unveil the chiral properties of the nuclear medium, a calculation at N2LO should be pursued. The linear relation in Eq. (75) would imply that $f_{t}$ becomes zero for $\rho\simeq 4\rho_{0}$, and therefore for a Fermi momentum of around 440 MeV, which is a priori too high for this equation being accurate.

Regarding the calculation of the pion self energy, $\Pi(p)$, this is an important problem as it is in tight correspondence to that of pionic atoms due to the relation between the pion self-energy and the pion-nucleus optical potential. The equivalent potential is given by $\Pi(p)/2\omega({\mathbf{p}})$ with $\omega({\mathbf{p}})=\sqrt{m_{\pi}^{2}+{\mathbf{p}}^{2}}$. For the first time in the literature, Ref. [7] explained the origin of the so-called $S$-wave missing repulsion in pionic atoms as an effect originating by the sensitive energy dependence of the pion self-energy around threshold, so that one should not use $\Pi(p^{0}=m_{\pi},{\mathbf{p}})$ but keeping the variability of the energy argument, namely, $\Pi(p)$.

This was shown by calculating the pion masses in the medium, which is defined in terms of the pion self-energy for $p^{0}=\widetilde{M}_{\pi}$ and ${\mathbf{p}}=0$, as the solution of the pion dispersion equation,

[TABLE]

Of course, for the case of asymmetric proton and neutron densities the pion masses are different depending on the pion charge. For the nucleus 207Pb deeply bound $\pi^{-}$ states have been detected [51, 52] with a shift in the effective in-medium $\pi^{-}$ mass of $\Delta M_{\pi^{-}}=23-27$ MeV [52] for the pion-nucleus optical potentials used (with $\Delta M_{\pi^{-}}=\widetilde{M}_{\pi^{-}}-M_{\pi^{-}})$. By solving the equation for the $\pi^{-}$ mass in such circumstances Ref. [7] obtains $\Delta M_{\pi^{-}}=18\pm 5$  MeV, which is already compatible with the previous values from Ref. [52].

This important conclusion indicates that in-medium ChPT accounts for most of the required shift in the $\pi^{-}$ mass at finite density from experiments on deeply bound pionic atoms [52]. The main contribution to this shift, around 16 MeV, results from the combination $1+4\hat{\rho}(c_{2}+c_{3}-g_{A}^{2}/8m_{N})/f^{2}$ that appears multiplying $\widetilde{M}_{\pi^{-}}^{2}$ in the $\pi^{-}$ dispersion relation

[TABLE]

where $\hat{\rho}=\frac{1}{2}(\rho_{p}+\rho_{n})$ and $\bar{\rho}=\frac{1}{2}(\rho_{p}-\rho_{n})$ . This factor corresponds to the wave-function renormalization of the in-medium pions in symmetric nuclear matter at threshold [7], which for $\rho=\rho_{0}$ is $\sim 0.5$. Additionally, the factor multiplying $M_{\pi^{-}}^{2}$ in Eq. (77) is around 0.5, such that, when divided by the wave-function renormalization constant, it is slightly greater than one and it further increases $\widetilde{M}_{\pi^{-}}$ by the extra amount of 2 MeV. The addition of both contributions account for the final 18 MeV in $\Delta M_{\pi^{-}}$, as referred above [7].

7 Conclusions

We have reviewed on the results obtained in Refs. [12, 13, 14] based on the approach developed in Ref. [4] and on a chiral power counting in the nuclear medium that combines pion-mediated [7] and short-range [13] internucleon interactions. The power counting is bounded from below and at a given order it requires to calculate a finite number of mechanisms, which typically implies the resummation of an infinite string of two-nucleon reducible diagrams with the leading multi-nucleon ChPT amplitudes. These resummations arise because this power counting takes into account from the onset the presence of enhanced nucleon propagators and it can also be applied to multi-nucleon forces. Non-perturbative techniques that perform these resummations both in scattering as well as in production processes are developed based on Unitary Chiral Perturbation Theory (UChPT), which is adapted now to the nuclear medium by implementing the new power counting.

Using this theory we have first discussed the non-perturbative leading order (LO) vacuum and in-medium nucleon-nucleon ($NN$) interactions. These were derived in Ref. [13] and applied to the calculation of the energy density for nuclear matter up to next-to-leading order (NLO). The energy per baryon obtained for neutron and symmetric nuclear matter is in good agreement with other sophisticated many-body calculation employing realistic $NN$ potentials and including an adjustable parameter for mimicking three-nucleon interactions [43].

The equation of state for neutron matter, $P(\rho)$, is derived from these results and applied to the study of the neutron-star properties in Ref. [15]. The mass-radius curve is in agreement with the recent observation of a neutron star with a mass near $2\,M_{\odot}$ and with other constraints from the GW170817 event observed by the LIGO and Virgo Collaborations [18]. We have reported here the agreement with the maximum mass of a neutron star and the radius for a neutron star with a mass of $1.4~{}M_{\odot}$. Reference [15] also makes the important point of determining an upper bond for the gravitational constant $G$ in a neutron star of 2 $M_{\odot}$, so that it cannot be more than 12% larger compared to its value on the surface of the Earth (despite the gravitational field intensity is around twelve orders of magnitudes larger).

We have also reviewed about the results of Refs. [14, 7] on the pion coupling $f_{t}$ to the temporal component of the axial-vector current and the in-medium quark condensate, and of Refs. [12, 13, 7] on the pion self-energy. The quark condensate and $f_{t}$ are important quantities to characterize the chiral symmetry breaking in nuclear matter. It is found that the non-linear corrections in density for $f_{t}$ and the pion self-energy, that would arise from the in-medium non-perturbative $NN$ interactions, vanish identically at NLO, while for the quark condensate they are small because strong cancellations occur. Finally, we have discussed the important conclusion of Ref. [7] that in-medium ChPT explains the missing $S$-wave repulsion of a $\pi^{-}$ in the nuclear medium, responsible for the rather large shift of the $\pi^{-}$ mass in Pb [52].

Contrary to other approaches extensively used in modern literature, the in-medium ChPT is based on a chiral power counting that takes into account the enhanced nucleon propagators in the medium. Furthermore, within this theory one does not invoke alien many-body techniques for complementing the chiral expansion, because the application of the chiral power counting leads to the corresponding non-perturbative resummations that should be performed.

Acknowledgements

This work is partially funded by the MINECO (Spain) and EU grant FPA2016-77313-P.

Appendices

Appendix A The one-pion exchange nucleon-nucleon partial waves

The one-pion exchange nucleon-nucleon partial waves $N_{JI}^{1\pi}(\bar{\ell},\ell,S)$ up to the $F-$wave that result from Eqs. (27)–(30) are (including the amplitudes that couple different $\ell$ and $\bar{\ell}$):

[TABLE]

Appendix B Calculation of the $L_{10}^{I_{3}}$ function

Employing the form of the nucleon propagator in Eq. (52), we have for the function $L_{10}^{I_{3}}$,

[TABLE]

where

[TABLE]

Only the contributions in Eq. (B.1) with the two poles in $k^{0}$ lying on opposite halves of the complex $k^{0}$ plane contribute. As a result,

[TABLE]

The first term is the particle-particle part and the last is the hole-hole one. Notice the different position of the cuts in $A$. While for the particle-particle case $A$ has a negative imaginary part, $-i\epsilon$, for the hole-hole part the cut takes values with positive imaginary part, $+i\epsilon$. The latter cut requires ${\mathbf{k}}^{2}=A$, but $|{\mathbf{k}}|$ is bounded so that the two $\theta$-functions are satisfied simultaneously. The requirements on $A$ are explicitly worked out in Eq. (B.21).

The actual calculation here of the function $L_{10}$ (for simplicity we drop the superscript $I_{3}$) is given by employing the equivalent form

[TABLE]

where we have used the expression for the nucleon propagator in Eq. (51). This integration corresponds to the loop in Fig. 13, where the four-momentum attached to each internal line is shown. The different contributions to $L_{10}$ are thus calculated according to the number of in-medium insertions in the nucleon propagators.

B.1 Free part, $L_{10,f}$

We perform first the $k^{0}$ integration by applying the Cauchy’s theorem,

[TABLE]

with

[TABLE]

and $\alpha=|\vec{\alpha}|$. One has to keep in mind in the following the $+i\epsilon$ prescription in the definition of $A$. In order to emphasize this, we write explicitly the combination $A+i\epsilon$ in many integrals, though the $+i\epsilon$ is already contained in $A$ according to Eq. (B.6).

The result in Eq. (B.5) corresponds to Eq. (37), as it should because $g(A)=L_{10,f}(A)$. Note that here we have used a somewhat different scheme of calculation starting from four dimensions and removing the temporal component by explicit integration, so that we end with Eq. (36) afterwards.

B.2 One-medium insertion, $L_{10,m}$

For the one-medium insertion, $L_{10,m}$ the $k^{0}$-integration is done by making use of the energy-conserving Dirac delta-function in the in-medium part of the nucleon propagator. We are then left with

[TABLE]

Let us concentrate on evaluating the integral,

[TABLE]

Here we have taken into account that the Heaviside function in the numerator implies the conditions,

[TABLE]

Despite the separation between the cases $\alpha\geq\xi_{1}$ and $\alpha<\xi_{1}$, both give rise to the same expression in Eq. (B.8). In terms of the function $\ell_{10,m}(\xi_{1},A,\alpha)$, Eq. (B.7), one has

[TABLE]

B.3 Two medium insertions, $L_{10,d}$

For the case with two medium insertions

[TABLE]

We take in the following that $\xi_{2}\geq\xi_{1}$. If the opposite were true one can use the same expressions that we derive below but with the exchange $\xi_{1}\leftrightarrow\xi_{2}$. This is clear after changing $\hat{{\mathbf{k}}}\to-\hat{{\mathbf{k}}}$ in the integral of Eq. (B.11).

The two step functions can be easily solved. Denoting by $\theta$ the angle between $\hat{{\mathbf{k}}}$ and $\vec{\alpha}$, they imply

[TABLE]

One has to require that $y_{1}\leq 1$ and that $y_{2}\geq-1$, otherwise $\cos\theta$ is out of the range $[-1,+1]$ from the conditions $(\ref{l10d.con})$. In addition, it is also necessary that $y_{2}\geq y_{1}$.

[TABLE]

For $\alpha\geq\xi_{1}$ in order that $(\alpha-\xi_{1})^{2}\leq A_{max}$, as the last of the three previous conditions requires, then

[TABLE]

Notice that because $\xi_{2}\geq\xi_{1}$ the previous upper bound is larger than $\xi_{1}$. From Eq. (B.14) it follows then that $\alpha-\xi_{2}\leq 0$. In addition it is always the case that $(\alpha+\xi_{2})^{2}\geq A_{max}$. On the other hand,

[TABLE]

For the final form of $L_{10,d}$ one also has to take into account the conditions,

[TABLE]

Gathering together the conditions in Eqs. (B.12)–(B.16) we have the following options,

[TABLE]

which is not possible because $\xi_{2}\geq\xi_{1}$.

[TABLE]

this only holds for $\alpha\leq\xi_{1}$. Then $\cos\theta\in[-1,+1]$ and $L_{10,d}=-i\,m\sqrt{A}/(2\pi)$.

[TABLE]

in which case, $\cos\theta\in[y_{1},+1]$ and $L_{10,d}=-im(\xi_{1}^{2}-(\sqrt{A}-\alpha)^{2})/(8\pi\alpha)$ . It follows that $\xi_{1}+\alpha\leq\xi_{2}-\alpha$ for $\alpha\leq(\xi_{2}-\xi_{1})/2$ and $\xi_{1}+\alpha\geq\xi_{2}-\alpha$ for $\alpha\geq(\xi_{2}-\xi_{1})/2$. In both cases $[{\rm min}(\xi_{1}+\alpha,\xi_{2}-\alpha)]^{2}\leq A_{max}$, as can be easily seen.

The last possibility is that

[TABLE]

For this case to hold, it is necessary that $\alpha\geq(\xi_{2}-\xi_{1})/2$. But then $A_{max}\leq(\xi_{1}+\alpha)^{2}$ so that the allowed upper limit for $\sqrt{A}$ is $\sqrt{A_{max}}$ not $\xi_{1}+\alpha$. In this case, $\cos\theta\in[y_{1},y_{2}]$ and $L_{10,d}=-i\,m(\xi_{1}^{2}+\xi_{2}^{2}-2A-2\alpha^{2})/(8\pi\alpha)$.

In summary,

[TABLE]
