Milky Way Halo Vibrations and Incommensurate Stream Velocities

TL;DR

This paper investigates the oscillations of Milky Way-like dark matter halos and their impact on stellar stream velocities, providing insights into dark matter properties through simulation and observational comparisons.

Contribution

It introduces an n-body simulation of a Milky Way-like halo to analyze halo oscillations and their effects on stellar stream velocities, linking these to dark matter characteristics.

Findings

Stellar streams exhibit exponential distribution of perpendicular velocities (~10-20 km/s).

Halo quadrupole fluctuations can explain observed tangential velocities.

Velocity measurements can constrain dark matter self-interaction cross-section.

Abstract

Collisionless dark matter galactic halos are expected to exhibit damped oscillations as a result of ongoing late time accretion. An n-body model of the cosmological assembly of a Milky Way-like halo is used to quantify the time dependence of its gravitational field. The simulation contains stellar streams whose incommensurate perpendicular velocities are found to have an approximately exponential distribution with a scale of 10-20\kms, depending on how the stars are selected, comparable to those reported for the Orphan stream. The fluctuations in the quadrupole moment of the dark matter halo are sufficient to largely explain the tangential velocities. If velocity measurements of a larger sample of Milky Way streams finds (or does not find) the expected distribution of transverse velocities it will lead to limits on the cross-section of self-interacting dark matter, in which kinetic viscosity can damp the oscillations more rapidly than the mixing processes of collisionless dark matter alone.

Figures

Equations

$${\varphi }_2(r^{\prime })=-G{m}_p\sum _{ij}\sum _m\left[\frac{3}{2r^5}{a}_i{a}_j{r}_i{r}_j-\frac{a^2}{2r^3}\right].$$

$$\Delta v(t,r)=\frac{3}{2}r{\int }_{t_0}^t[Q_1(t^{\prime },r)-⟨Q_1(r)⟩]d{t}^{\prime },$$

Full text

1. INTRODUCTION

The gravitational force from the Milky Way’s halo is conventionally and conveniently approximated as a static potential (Navarro et al., 1997; Bovy, 2015). However, the late time accretion of mass and the motions of satellites means that the halo potential is time variable at a level which can be important for some aspects of orbital motion although it does not necessarily threaten the static approximation for other purposes. The DR2 data release (Gaia Collaboration et al., 2018) of the Gaia mission (Gaia Collaboration et al., 2016) has provided some intriguing new insight into the non-stationary aspects of the galactic potential. Within a few kiloparsecs of the sun the motion of stars led Carrillo et al. (2018) to reach the conclusion that the stellar distribution around the sun is “wobbly”, with both bending and breathing modes present, with a velocity amplitude in the range 5-10  km s*-1* kpc*-1*. Spiral waves, the galactic bar and bending waves dominate the time dependent component potential in the region near the sun (Darling & Widrow, 2019) so it is unclear what ongoing potential variations are present in the dark matter halo.

The stars that gravitational tides pull away from dynamically evaporating globular clusters and low mass dwarf galaxies create long thin streams of stars. The narrow range in velocities of the stars means that streams are sensitive indicators of the galactic potential along the path of the stream. The stream path, and the underlying orbits of its constituent stars, has been extensively studied in a range of realistic potentials with powerful methods that can be adapted to almost any frozen potential (Dehnen et al., 2004; Choi et al., 2007; Binney, 2008; Eyre & Binney, 2009; Sanders & Binney, 2013; Amorisco, 2015; Buist, & Helmi, 2015; Fardal et al., 2015; Buist, & Helmi, 2017). Although systematic offsets between the path of the stream and the orbits of its stars are expected, the offsets of the stream velocities from the path of the stream are comparable to the range that the progenitor system introduces at the outset, typically a few  km s*-1* for globular clusters and low mass dwarf galaxies. The stars of the Orphan stream have been found to have systematic and coherent velocities of tens of  km s*-1* (Koposov et al., 2019) transverse to the stream path. That is, the velocities are incommensurate with a fixed stream path. The data suggest that the Milky Way halo potential must have a significant time dependence although orbital precession in a non-spherical halo will be a contributing factor. Erkal et al. (2019) shows that a model of a static halo with the approaching Large Magellanic Cloud can successfully reproduce the available data.

Dark matter at the current epoch is often assumed to have a sufficiently low cross-section for interaction with itself and other particles that it is effectively collisionless. Particle dark matter at the current epoch almost certainly has a small but finite cross-section for interaction which could help with the problem of cores of dark matter halos in dwarf galaxies (Spergel & Steinhardt, 2000). However the past presence of gas in dwarf cores complicates their interpretation (Harvey et al., 2018; Read et al., 2019). Locations which have plausibly never had much baryonic influence, such as the halo of the Milky Way galaxy are likely a cleaner environment to study the properties of dark matter. Self-interacting dark matter has collisions that will help reduce potential fluctuations in a dark halo and the induced transverse velocities.

The purpose of this paper is to assess the level of potential fluctuations that arise from the vibrations or ringing of a Milky Way-like dark halo due to ongoing late time mass accretion and how that affects the orbits of stellar streams. The approach is to use an n-body model of the build-up of a Milky Way model which contains globular clusters which are undergoing dynamical evaporation to produce stellar streams that are directly comparable to the density, sizes and kinematic aspects of observed streams. A set of identical n-body experiments containing self-interacting dark matter help quantify the damping of the halo vibrations as the collisional cross-section is increased.

2. Simulation with Streams

The simulation here is the same as used in Carlberg (2019) to create a dominant Milky Way-like halo from LCDM initial conditions. The simulation begins at redshift 4.56, reconstituting the halo catalog of the VL2 simulation (Madau et al., 2008). The dark matter particles have masses of $4\times 10^{4}{\rm\,M_{\odot}}$ and softening of 200 pc. Added to the simulation is a dynamical population of globular clusters made of star particles of $5{\rm\,M_{\odot}}$, evolved with a softening length of 2 pc. The simulation does not include any gas particles, or, the buildup of a central disk galaxy, since neither is a significant concern for the stream population beyond about 30 kpc from the primary halo center. The outcome is a main galactic halo similar to the VL2 result with a low level of ongoing mass accretion. Pynbody (Pontzen et al., 2013) reports the instantaneous final shape of the halo in homeoidal density shells to have ($b/a$, $c/a$) values of (0.96, 0.80) and (0.94, 0.76) at 28 and 41 kpc, respectively. At the final moment of the simulation the Amiga Halo Finder (Knollmann, & Knebe, 2009) finds the most massive sub-halo within 100 kpc has 2.2% of the mass of the $2.38\times 10^{12}{\rm\,M_{\odot}}$ main halo at a distance of 68 kpc from its center. The dark matter particles and all the star particles for one stream are shown in Figure 1.

The star clusters are inserted into the simulation in the initial conditions. Their masses are drawn from a power law cluster mass distribution over the range $2\times 10^{6}{\rm\,M_{\odot}}$ to $5\times 10^{4}{\rm\,M_{\odot}}$. In total, 710 clusters are inserted into the sub-halos more massive than $4\times 10^{8}{\rm\,M_{\odot}}$. The clusters lose mass as a result of internal two body relaxation and tidal fields to produce long, thin tidal streams that have roughly the same properties as star streams found in the Milky Way. The streams are identified in the distance range of 15 to 60 kpc from the center, which leads to 18 streams less than 1.2° wide on the sky. The clusters begin losing mass in their natal dark matter sub-halo then merges into the growing dominant halo where the clusters orbit freely to produce the thin streams.

To analyze the properties of the stream, the stars from a cluster are rotated into a frame where the progenitor cluster is located at the coordinate center on the sky, with the cluster moving to the left along the equator. Figure 2 shows one stream which has properties roughly comparable to those of the Orphan stream (Belokurov et al., 2007; Newberg et al., 2010; Koposov et al., 2019), with the notable difference that the progenitor cluster is still present. This stream is one of the 18 thin streams identified in the 15 to 60 kpc range. Of those, 3 have large and systematic velocities perpendicular to the nominal orbital plane, comparable to those in Figure 2.

Figure 3 quantifies the distribution of velocities perpendicular to the velocity vector of the star cluster for stars in the distance range 15-60 kpc from the center from all streams. That is, all streams that qualify as thin and at least 20° long with stars in the selected radial range are plotted. The red distribution is for stars within the thin stream and the black distribution is for all stars both at least 6° from the progenitor clusters. The location of the two sets of stars on the sky are shown in Figure 2 in the lower left panel. Approximating the velocity distribution in the 10-50  km s*-1* range as $\exp{(-v/v_{s})}$, then $v_{s}$ is approximately 10  km s*-1* for the thin stream. The total distribution of stream stars is hard to find in imaging data but easier in kinematic data has a much more extended velocity distribution. Creating the same plot as Figure 3 at any time up to 4 Gyr earlier shows essentially the same distribution. That is, significant incommensurate velocities perpendicular to the stream path on the sky are always present at late times.

3. Analysis of Stream Velocities

The streams in the simulation have a range of velocities perpendicular to the stream direction, some comparable to those in the Orphan Stream. The question is what aspects of the gravitational potential give rise to those velocities. The simulation does not have a large satellite comparable to the LMC at late times. The late time accretion is fairly modest with the mass inside 100 kpc rising about 1% from 7 to 13.4 Gyr, with the mass inside 25 kpc constant with 0.7% variance. In a non-spherical halo the stream will precess, leading to velocities offset from the path of the stream. At 30 kpc a precession period of, say, 6 Gyr, leads to velocities offset from the stream, peaking at 30  km s*-1*, typically about 20  km s*-1*, peak perpendicular to the stream.

A straightforward procedure to measure large scale fluctuations in the gravitational potential is to calculate the quadrupole potential as a function of radius. Because the vertical velocities vary slowly with longitude around the orbit, with one or two maxima in latitude, moments higher than the quadrupole are ignored. The quadrupole potential is calculated as,

[TABLE]

The $ij$ sum is over coordinate directions and the $m$ sum is over the positions of all particles of mass $m_{p}$. The $m$ sum is over the $a$ coordinates for $a<r^{\prime}$ with $r=r^{\prime}$, and over $r$ coordinates for $r>r^{\prime}$, with $a=r^{\prime}$. Note that only the first term generates non-radial forces. The coordinate center is defined as the location of the highest particle density. To analyze the time variability of the potential the eigenvalues and eigenvectors of the quadrupole potential matrix are found. The orientation of the largest eigenvector at the last moment (current epoch) of the simulation defines the reference direction. Figure 4 plots the dot product of the reference with the same vector at earlier times, finding that the orientation of the major axis varies about 10-15° at the three radii considered. There was a significant accretion event that began around 8 Gyr, but in the last 3 Gyr the halo axis has been only slowly and systematically varying. The major axis of the halo wobbles, but not a lot. The dot product of the eigenvector associated with the third largest eigenvalue with itself shows the orientation of the quadrupole at 25 kpc drifts at a linear rate of about 10° over the last 3 Gyr, but is otherwise remarkably constant.

The gravitational acceleration monopole has a mean of $2300({\,\hbox{km\,s}^{-1}})^{2}$/kpc with a variance of $17({\,\hbox{km\,s}^{-1}})^{2}$/kpc over the 9.2 to 13.4 Gyr interval at a radius 25 kpc. The monopole acceleration is radial and cannot create transverse velocities, although once present, non-radial velocities will vary as stars with the radial excursions of an orbit.

At fixed $r$ the maximum perpendicular acceleration is $a_{z}={3\over 2}Q_{1}r$, where $Q_{1}$ is the largest eigenvalue of the quadrupole. Values of $Q_{1}r$ (without the ${3\over 2}$) are plotted in Figure 5. At 25 kpc the quadrupole term $Q_{1}r$ has a mean and variance of $448$ and $24({\,\hbox{km\,s}^{-1}})^{2}$/kpc, respectively, with a range from $305-538({\,\hbox{km\,s}^{-1}})^{2}$/kpc over the 7.3 Gyr interval analyzed. To estimate the scale of the velocities that can be induced perpendicular to an orbit the time variable component of the acceleration normal to the plane is integrated over time,

[TABLE]

where $\langle Q_{1}(r)\rangle$ is the average of the eigenvalue over the time interval. The fluctuating velocity change integral, Equation 2, leads to the values shown in Figure 6, demonstrating that the time variations of the quadrupole potential can create transverse velocities of 10-20  km s*-1*. Such velocities would rise and fall with inward and outward excursions of the orbit. The dipole term has a mean and variance of $23$ and $14({\,\hbox{km\,s}^{-1}})^{2}$/kpc, respectively and is not dynamically very important, as expected deep in a halo.

The conclusion is that the semi-coherent fluctuations of the quadrupole leads to accelerations that produce velocities sufficient to cause the observed perpendicular velocities of the streams. The variation can be characterized as a vibration or a strongly damped ringing oscillation.

4. Self-Interacting Dark Matter

Halo ringing is damped through the collisionless mixing of the accreted dark matter into the halo of the galaxy although significant substructure continues to circulate. If the dark matter self-interacts with a cross-section that leads to a mean free path, $\ell$, in the range of tens of kiloparsecs, then kinetic theory gives the kinematic viscosity as $\nu\simeq\sigma_{v}\ell$, where $\sigma_{v}$ is the one-dimensional velocity dispersion of the dark matter. Viscosity transports momentum and will increase damping, potentially to a level that would largely suppress the halo vibrations. Self-interacting dark matter (SIDM) simulations can quantify the importance of the effect.

Figure 7 shows the significance of the effect for a SIDM model with elastic collisions, as implemented in the Gadget3 code for a VL2 setup as before but with dark matter only and started at redshift 3. The cross-sections used are 0.1, 0.3 and 1.0 in units of ${\rm cm}^{2}{\rm gm}^{-1}$. At 0.1 ${\rm cm}^{2}{\rm gm}^{-1}$ the result is almost the same as collisionless dark matter. The effect of reduced force fluctuation amplitudes and hence reduced velocities is very clear, with the fluctuations becoming very much smaller than collisionless dark matter at a cross-section of 1.0. If dark matter did have this cross-section then the observed perpendicular velocities of the Orphan stream would be in fairly good accord with the static halo LMC model (Erkal et al., 2019). A simulation at a cross-section of 10 units is so heavily damped that the primary effects are to cause the halo to become nearly spherical with a substantial core.

If the Milky Way halo does not have the level of halo ringing expected for ongoing late time accretion it would provide a limit on the size of the dark matter self-interaction cross-section. Streams will provide increasingly good measurements on the shape of the halo, with current results finding that the disk-corrected shape of the halo in the stream region is spherical within about 5% (Bovy et al., 2016). Of course baryons and the development of a stellar disk also effect the shape of the halo (Bryan et al., 2013; Butsky et al., 2016; Chua et al., 2019) and the two together are even more complex (Despali et al., 2019). In general the effects diminish outwards as the orbital frequencies of the halo become lower than the regions where baryons are present reducing dynamical coupling. Gas and stars will also be able to help damp halo ringing although this is not yet quantified.

5. Discussion and Conclusions

The Orphan Stream is observed to have velocities incommensurate with the path of the stream. That is, there are significant transverse velocities. The implication is that the streams are in a time varying halo potential. This paper shows that ongoing late time accretion of dark matter sub-halos into the Milky Way-like galactic halo of the VL2 simulation leads to quadrupole potential fluctuations which can induce the transverse velocities in the 10-20 km s*-1* range that the star streams in the simulation are measured to have. One of the 18 streams present in the simulation is roughly at the distances of the Orphan stream and has density, length and roughly comparable transverse velocities. In this case the largest sub-halo within 100 kpc is 2.2% of the mass of the main halo and at 68 kpc.

Self-interacting dark matter damps halo vibrations. A set of SIDM simulations shows that the ringing is strongly suppressed for elastic SIDM at a cross-section of 1${\rm cm}^{2}{\rm gm}^{-1}$ and that at 10 ${\rm cm}^{2}{\rm gm}^{-1}$ the halo is forced to become nearly spherical. If it is shown that the velocities of other streams in the Milky Way halo are consistent with a near-spherical, static, halo and the LMC alone, it would provide indirect support for SIDM, although a more accurate overall model would need to account for the baryonic damping as well.

Positive criticism from an anonymous referee led to substantial improvements in the paper. This research was supported by NSERC of Canada. Computations were performed on the niagara supercomputer at the SciNet HPC Consortium. SciNet is funded by: the Canada Foundation for Innovation; the Government of Ontario; Ontario Research Fund - Research Excellence; and the University of Toronto.
