Cograph Editing: Merging Modules is equivalent to Editing P4's

TL;DR

This paper establishes a new approach to cograph editing by linking it to module merging operations, providing exact algorithms, FPT results, and efficient heuristics for solving the NP-hard problem.

Contribution

It introduces a novel equivalence between editing P4s and merging modules, along with exact and heuristic algorithms for cograph editing.

Findings

Optimal module-preserving edit sets always exist.

The approach leads to an exact algorithm for cograph editing.

Heuristics with polynomial time complexity are proposed.

Abstract

The modular decomposition of a graph $G=(V,E)$ does not contain prime modules if and only if $G$ is a cograph, that is, if no quadruple of vertices induces a simple connected path $P_4$. The cograph editing problem consists in inserting into and deleting from $G$ a set $F$ of edges so that $H=(V,E\Delta F)$ is a cograph and $|F|$ is minimum. This NP-hard combinatorial optimization problem has recently found applications, e.g., in the context of phylogenetics. Efficient heuristics are hence of practical importance. The simple characterization of cographs in terms of their modular decomposition suggests that instead of editing $G$ one could operate directly on the modular decomposition. We show here that editing the induced $P_4$s is equivalent to resolving prime modules by means of a suitable defined merge operation on the submodules. Moreover, we characterize so-called module-preserving edit sets and demonstrate that optimal pairwise sequences of module-preserving edit sets exist for every non-cograph. This eventually leads to an exact algorithm for the cograph editing problem as well as fixed-parameter tractable (FPT) results when cograph editing is parameterized by the so-called modular-width. In addition, we provide two heuristics with time complexity $O(|V|^3)$, resp., $O(|V|^2)$.

Figures

Equations

$$F[M]:=\{\{x,y\}\in F\mid x,y\in M\}.$$

$$F_{H^{\prime}}(\mathbin{\mathchoice{\ooalign{$\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}$}}{\ooalign{$\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}$}}{\ooalign{$\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}$}}{\ooalign{$\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}$}}}_{i=1}^{k}M_{i}\to M)\coloneqq\{\{x,v\}\in F\ \mid\ x\in M,v\in V(H^{\prime})\setminus M\}$$

$$F=\bigcup_{M^{\star}\in\mathcal{M}}\left(F_{H[P_{M^{\star}}]}(\mathbin{\mathchoice{\ooalign{$\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}$}}{\ooalign{$\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}$}}{\ooalign{$\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}$}}{\ooalign{$\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}$}}}_{M_{i}\in\mathcal{C}(M^{\star})}M_{i}\to M^{\star})\right).$$

$$F=\mathop{\vphantom{\bigcup}\mathchoice{\ooalign{$\displaystyle\bigcup$\cr\raise-9.4445pt\hbox{\scalebox{2.0}{$\displaystyle\cdot$}}}}{\ooalign{$\textstyle\bigcup$\cr\raise-9.4445pt\hbox{\scalebox{2.0}{$\textstyle\cdot$}}}}{\ooalign{$\scriptstyle\bigcup$\cr\raise-6.61116pt\hbox{\scalebox{2.0}{$\scriptstyle\cdot$}}}}{\ooalign{$\scriptscriptstyle\bigcup$\cr\raise-4.72224pt\hbox{\scalebox{2.0}{$\scriptscriptstyle\cdot$}}}}}_{i=1}^{n}\sigma_{M^{\star}_{i}}\text{ and, thus, }|F|=\sum_{i=1}^{n}|\sigma_{M^{\star}_{i}}|\,.$$

$$G_j[M_i^{\star }]=H[M_i^{\star }].$$

$$\begin{gathered} \mathcal{X}(M^{\star }):=\{{\tilde{M}}_i\in {\mathbb{P}}_{\max }(H[M^{\star }])\mid \exists {\hat{M}}_j\in \mathcal{C}(M^{\star })\text{ s.t. }{\hat{M}}_j\subseteq {\tilde{M}}_i\} \\ \cup \{{\hat{M}}_j\in \mathcal{C}(M^{\star })\mid \exists {\tilde{M}}_i\in {\mathbb{P}}_{\max }(H[M^{\star }])\text{ s.t. }{\tilde{M}}_i\subseteq {\hat{M}}_j\}. \end{gathered}$$

$$\mathcal{N}(\mathcal{M})=\{N_1^{\star }=M_1^{\star }(1),\dots ,N_m^{\star }=M_n^{\star }(l_n)\}$$

$$F_{M_i^{\star }(j)}:=\{\{x,v\}\in F\mid x\in M_i^{\star }(j),v\in P_{M_i^{\star }}\setminus M_i^{\star }(j)\}.$$

$${\theta }_l=\{\begin{array}{ll}\varnothing & \text{mbox},if{N}_l^{\star }\text{ is a module of }{G}_{l-1}^{\prime }\\ F_{N_l^{\star }}\setminus {\bigcup }_{k=1}^{l-1}{\theta }_k& \text{mbox},otherwise.\end{array}$$

Full text

**Keywords: ** Cograph Editing, Modular Decomposition, Module Merge, Prime Modules, $P_{4}$

1 Introduction

Cographs are of particular interest in computer science because many combinatorial optimization problems that are NP-complete for arbitrary graphs become polynomial-time solvable on cographs [8, 4, 20]. This makes them an attractive starting point for constructing heuristics that are exact on cographs and yield approximate solutions on other graphs. In this context it is of considerable practical interest to determine “how close” an input graph is to a cograph.

An independent motivation recently arose in biology, more precisely in molecular phylogenetics [35, 37, 14, 36, 47, 21]. In particular, orthology, a key concept in evolutionary biology in phylogenetics, is intimately tied to cographs [35]. Two genes in a pair of related species are said to be orthologous if their last common ancestor was a speciation event. The orthology relation on a set of genes forms a cograph [30], see [31] for a detailed discussion and [33, 47, 21, 22, 23] for generalizations of these concepts. This relation can be estimated directly from biological sequence data, albeit in a necessarily noisy form. Correcting such an initial estimate to the nearest cograph thus has recently become a computational problem of considerable practical interest in computational biology [35]. However, the (decision version of the) problem to edit a given graph with a minimum number of edits into a cograph is NP-complete [38, 39, 34, 32].

As noted already in [7], the input for several combinatorial optimization problems, such as exam scheduling or several variants of clustering problems, is naturally expected to have few induced paths on four vertices ($P_{4}$s). Since graphs without an induced $P_{4}$ are exactly the cographs, available cograph editing algorithms focus on efficiently removing $P_{4}$s, see e.g. [38, 39, 25, 24, 16, 53]. The FPT-algorithm introduced in [38, 39] takes as input a graph that is first edited to a so-called $P_{4}$-sparse graph and then to a cograph. The basic strategy is to destroy the $P_{4}$s in the subgraphs by branching into six cases that eventually leads to an $O(4.612^{k}|V|^{9/2})$-time algorithm, where $k$ is the number of required edits. Algorithms that compute the kernel of the (parameterized) cograph editing problem [25, 24] as well as the exact $O(3^{|V|}|V|)$-time algorithm [53] use the modular-decomposition tree as a guide to locate the forbidden $P_{4}$s using the fact that these are associated with prime modules. Nevertheless, the basic operation in all of these algorithms is still the direct destruction of the $P_{4}$s.

Cographs are recursively defined as follows: $K_{1}$ is a cograph, the disjoint union of cographs is a cograph, and the join of cographs is a cograph. This recursive definition associates a vertex labeled tree, the cotree, with each cograph, where a vertex label “0” denotes a disjoint union, while “1” indicates the join of the children is formed. It has been shown in [7] that each cograph has a unique cotree and conversely, every tree whose interior vertices are labeled alternatingly defined a unique cograph. A simple recognition algorithm starts with an input graph $G$. If $G$ is connected, then a node labeled “1” is inserted into the tree, the complement graph $\overline{G}$ is formed and the algorithm proceeds recursively on the connected components of $\overline{G}$. If $G$ is not connected, the tree-node is labeled “0”, and the algorithm recurses on the components of $G$. If both $G$ and $\overline{G}$ are connected, then $G$ is not a cograph, and the algorithm terminates with a negative answer. A natural heuristic for cograph editing proceeds by finding a minimal cut in $G$ or $\overline{G}$, removes the cut-edges and proceeds with the modified graph. This idea is pursued in [14, 15].

A very different heuristic for cograph modification was recently proposed by Crespelle [11]. It corrects the neighborhood of each vertex separately. More precisely, an inclusion-minimal cograph editing $H_{k}$ of the induced subgraph $G_{k}:=G[\{x_{1},\dots x_{k}\}]$ is computed from the correction $H_{i-1}$ of $G_{i-1}$ in such a way that only edges involving $x_{i}$ are inserted or deleted. It has the useful property that in each step the number of inserted or deleted edges is minimum, and it inserts or deletes no more than $|E(G)|$ edges in total. It is based on a general property of single-vertex augmentations in hereditary graph classes that are stable under the addition of universal vertices and isolated vertices, see e.g. [48]. A key advantage is that it has linear time complexity, i.e., $O(|V|+|E|)$.

Cotrees are a special case of the much more general modular decomposition tree, which is well-defined for every graph and conveys detailed information about its structure in a hierarchical manner [19]. A subset $M\subseteq V$ is called a module of a graph $G=(V,E)$, if all members of $M$ share the same neighbors in $V\setminus M$. A prime module is a module that is characterized by the property that both, the induced subgraph $G[M]$ and its complement $\overline{G[M]}$, are connected subgraphs of $G$. Cographs play a particular role in this context as their modular decompositions are of a special form: they are characterized by the absence of prime modules. In particular, the cotree of a cograph coincides with its modular decomposition tree [19]. It is natural to ask, therefore, whether the modular decomposition tree can be manipulated in a such a way that all prime modules of a given graph are converted into “series” or “parallel” modules for which either $G[M]$ and or $\overline{G[M]}$ is disconnected. This is equivalent to converting $G$ into a cograph $G^{*}$. Every minimum edit set clearly is inclusion-minimal. However, not every minimum edit set – and in particular not every inclusion-minimal edit set – respects the module structure of $G$. Fig. 1 below shows a pertinent example. In contrast to the editing approach of [11], we pursue an approach that is modul-preserving in the sense that each module of $G$ is also a module of the edited graph $G^{*}$. We argue that this property is desirable in the context of orthology detection, because the corrected modular decomposition tree, i.e., the cotree of $G^{*}$ has a direct interpretation as event-labeled gene tree [30, 35].

An alternative way of looking at the connection between cographs and their modular decomposition trees is to interpret the destruction of all $P_{4}$s in a cograph editing algorithm as the resolution of all prime modules in the edited graph $G^{*}$. This simple observation suggests to edit the modules of $G$. The min-cut approach of [14] is one possibility to achieve this. Here, we consider the merging of modules instead. Every union $\bigcup_{i\in I}M_{i}$ of the connected components $M_{1}$, …, $M_{k}$ of the edited graph $G^{*}[M]$ or $\overline{G^{*}[M]}$ forms a module $G^{*}$, while $\bigcup_{i\in I}M_{i}$ was not a module in the graph $G$ before editing. In this situation, we say that “the modules $M_{i}$, $i\in I$ of $G$ are merged w.r.t. $G^{*}$”. Vertices within a module $\bigcup_{i\in I}M_{i}$ share the same neighbors in $V\setminus(\bigcup_{i\in I}M_{i})$. It is sufficient therefore to adjust the neighbors of certain submodules $M_{i}$ of $M$ to merge the $M_{i}$ in a way that resolves the prime module $M$ to obtain $G^{*}$. In this setting, it seems natural to edit the modular decomposition tree of a graph directly with the aim of converting it step-by-step into the closest modular decomposition tree of a cograph. To this end, one would like to break up individual prime modules by means of the module merge operation.

The key results of this contribution are that (1) every prime node $M$ can be resolved by a sequence of pairwise merges of modules that are children of $M$ in the modular decomposition tree, and (2) optimal cograph editing can be expressed as optimal pairwise module merging. To prove these statements, we start with an overview of important properties on cographs and the modular decomposition (Section 2 and 3). In Section 4, we then show that so-called module-preserving edit sets are characterized by resolving any prime node by module-merges. In particular, we show that any graph has an optimal edit set that can be entirely expressed by merging modules that are children of prime modules in the modular decomposition tree. Finally in Section 5, we summarize the results and show how they can be used for establishing efficient heuristics for the cograph editing problem. We provide an exact algorithm that allows to optimally edit a cograph via pairwise module-merges. As by-product, we obtain an FPT algorithm for the case that cograph editing is parameterized by the so-called modular-width [18, 1]. We finish this paper with a short discussion on how the latter method can be used to obtain a simple $O(|V|^{2})$-time heuristic.

2 Basic Definitions

We consider simple finite undirected graphs $G=(V,E)$ without loops. The complement $\overline{G}$ of a graph $G=(V,E)$ has vertex set $V$ and edge set $E(\overline{G})=\{xy\mid x,y\in V,x\neq y,xy\notin E\}$. The notation $G\bigtriangleup F$ is used to denote the graph $(V,E\bigtriangleup F)$, where $\bigtriangleup$ denotes the symmetric difference. The disjoint union G\mathbin{\mathchoice{\ooalign{\displaystyle\cup$\cr$\displaystyle\cdot}}{\ooalign{\textstyle\cup$\cr$\textstyle\cdot}}{\ooalign{\scriptstyle\cup$\cr$\scriptstyle\cdot}}{\ooalign{\scriptscriptstyle\cup$\cr$\scriptscriptstyle\cdot}}}H of two distinct graphs $G=(V,E)$ and $H=(W,F)$ is simply the graph (V\mathbin{\mathchoice{\ooalign{\displaystyle\cup$\cr$\displaystyle\cdot}}{\ooalign{\textstyle\cup$\cr$\textstyle\cdot}}{\ooalign{\scriptstyle\cup$\cr$\scriptstyle\cdot}}{\ooalign{\scriptscriptstyle\cup$\cr$\scriptscriptstyle\cdot}}}W,E\mathbin{\mathchoice{\ooalign{\displaystyle\cup$\cr$\displaystyle\cdot}}{\ooalign{\textstyle\cup$\cr$\textstyle\cdot}}{\ooalign{\scriptstyle\cup$\cr$\scriptstyle\cdot}}{\ooalign{\scriptscriptstyle\cup$\cr$\scriptscriptstyle\cdot}}}F). The join $G\oplus H$ of $G$ and $H$ is defined as the graph (V\mathbin{\mathchoice{\ooalign{\displaystyle\cup$\cr$\displaystyle\cdot}}{\ooalign{\textstyle\cup$\cr$\textstyle\cdot}}{\ooalign{\scriptstyle\cup$\cr$\scriptstyle\cdot}}{\ooalign{\scriptscriptstyle\cup$\cr$\scriptscriptstyle\cdot}}}W,E\mathbin{\mathchoice{\ooalign{\displaystyle\cup$\cr$\displaystyle\cdot}}{\ooalign{\textstyle\cup$\cr$\textstyle\cdot}}{\ooalign{\scriptstyle\cup$\cr$\scriptstyle\cdot}}{\ooalign{\scriptscriptstyle\cup$\cr$\scriptscriptstyle\cdot}}}F\mathbin{\mathchoice{\ooalign{\displaystyle\cup$\cr$\displaystyle\cdot}}{\ooalign{\textstyle\cup$\cr$\textstyle\cdot}}{\ooalign{\scriptstyle\cup$\cr$\scriptstyle\cdot}}{\ooalign{\scriptscriptstyle\cup$\cr$\scriptscriptstyle\cdot}}}\{xy\mid x\in V,y\in W\}). A graph $H=(W,F)$ is a subgraph of a graph $G=(V,E)$, in symbols $H\subseteq G$, if $W\subseteq V$ and $F\subseteq E$. If $H\subseteq G$ and $xy\in F$ if and only if $xy\in E$ for all $x,y\in W$, then $H$ is called an induced subgraph. We will often denote an induced subgraph $H=(W,F)$ by $G[W]$. A connected component of $G$ is a connected induced subgraph that is maximal w.r.t. inclusion. We write $G\simeq H$ for two isomorphic graphs $G$ and $H$.

Let $G=(V,E)$ be a graph. The neighborhood $N(v)$ of $v\in V$ is defined as $N(v)=\{x\mid vx\in E\}$. If there is a risk of confusion we will write $N_{G}(v)$ to indicate that the respective neighborhood is taken w.r.t. $G$. The degree $\deg(v)$ of a vertex is defined as $\deg(v)=|N(v)|$.

A tree is a connected graph that does not contain cycles. A path is a tree where every vertex has degree $1$ or $2$. A rooted tree $T=(V,E)$ is a tree with one distinguished vertex $\rho\in V$. We distinguish two further types of vertices in a tree: the leaves which are distinct from the root and are contained in only one edge and the inner vertices which are contained in at least two edges. The first inner vertex $\operatorname{lca}(x,y)$ that lies on both unique paths from two vertices $x$, resp., $y$ to the root, is called lowest common ancestor of $x$ and $y$. We say that a rooted tree $T$ displays the triple $\mathrm{xy|z}$ if $x,y,$ and $z$ are leaves of $T$ and the path from $x$ to $y$ does not intersect the path from $z$ to the root of $T$.

It is well-known that there is a one-to-one correspondence between (isomorphism classes of) rooted trees on $V$ and so-called hierarchies on $V$. For a finite set $V$, a hierarchy on $V$ is a subset $\mathcal{C}$ of the power set $\mathcal{P}(V)$ such that $(i)$ $V\in\mathcal{C}$, $(ii)$ $\{x\}\in\mathcal{C}$ for all $x\in V$ and $(iii)$ $p\cap q\in\{p,q,\emptyset\}$ for all $p,q\in\mathcal{C}$.

Theorem 2.1** ([51]).**

Let $\mathcal{C}$ be a collection of non-empty subsets of $V$. Then, there is a rooted tree $T=(W,E)$ on $V$ with $\mathcal{C}=\{L(v)\mid v\in W\}$ if and only if $\mathcal{C}$ is a hierarchy on $V$.

3 Cographs and the Modular Decomposition

3.1 Introduction to Cographs

Cographs are defined as the class of graphs formed from a single vertex under the closure of the operations of union and complementation, namely: (i) a single-vertex graph $K_{1}$ is a cograph; (ii) the disjoint union G=(V_{1}\mathbin{\mathchoice{\ooalign{\displaystyle\cup$\cr$\displaystyle\cdot}}{\ooalign{\textstyle\cup$\cr$\textstyle\cdot}}{\ooalign{\scriptstyle\cup$\cr$\scriptstyle\cdot}}{\ooalign{\scriptscriptstyle\cup$\cr$\scriptscriptstyle\cdot}}}V_{2},E_{1}\mathbin{\mathchoice{\ooalign{\displaystyle\cup$\cr$\displaystyle\cdot}}{\ooalign{\textstyle\cup$\cr$\textstyle\cdot}}{\ooalign{\scriptstyle\cup$\cr$\scriptstyle\cdot}}{\ooalign{\scriptscriptstyle\cup$\cr$\scriptscriptstyle\cdot}}}E_{2}) of cographs $G_{1}=(V_{1},E_{1})$ and $G_{2}=(V_{2},E_{2})$ is a cograph; (iii) the complement $\overline{G}$ of a cograph $G$ is a cograph. Condition (ii) can be replaced by the equivalent condition that the join $G_{1}\oplus G_{2}$ is a cograph, since $G_{1}\oplus G_{2}$ is the complement of \overline{G}_{1}\mathbin{\mathchoice{\ooalign{\displaystyle\cup$\cr$\displaystyle\cdot}}{\ooalign{\textstyle\cup$\cr$\textstyle\cdot}}{\ooalign{\scriptstyle\cup$\cr$\scriptstyle\cdot}}{\ooalign{\scriptscriptstyle\cup$\cr$\scriptscriptstyle\cdot}}}\overline{G}_{2}.

The name cograph originates from complement reducible graphs, as by definition, cographs can be “reduced” by stepwise complementation of connected components to totally disconnected graphs [50].

It is well-known that for each induced subgraph $H$ of a cograph $G$ either $H$ is disconnected or its complement $\overline{H}$ is disconnected [4]. This, in particular, allows representing the structure of a cograph $G=(V,E)$ in an unambiguous way as a rooted tree $T=(W,F)$, called cotree: If the considered cograph is the single vertex graph $K_{1}$, then output the tree $(\{u\},\emptyset)$. Else if the given cograph $G$ is connected, create an inner vertex $u$ in the cotree with label “series”, build the complement $\overline{G}$ and add the connected components of $\overline{G}$ as children of $u$. If $G$ is not connected, then create an inner vertex $u$ in the cotree with label “parallel” and add the connected components of $G$ as children of $u$. Proceed recursively on the respective connected components that consists of more than one vertex. Eventually, this cotree will have leaf-set $V\subseteq W$ and the inner vertices $u\in W\setminus V$ are labeled with either “parallel” or “series” such that $xy\in E$ if and only if $u=\operatorname{lca}_{T}(x,y)$ is labeled “series”.

The complement of a path on four vertices $P_{4}$ is again a $P_{4}$ and hence, such graphs are not cographs. Intriguingly, cographs have indeed a quite simple characterization as $P_{4}$-free graphs, that is, no four vertices induce a $P_{4}$. A number of further equivalent characterizations are given in [4] and Theorem 3.2. Determining whether a graph is a cograph can be done in linear time [8, 5].

3.2 Modules and the Modular Decomposition

The concept of modular decompositions (MD) is defined for arbitrary graphs $G$ and allows us to present the structure of $G$ in the form of a tree that generalizes the idea of cotrees. However, in general much more information needs to be stored at the inner vertices of this tree if the original graph has to be recovered.

The MD is based on the notion of modules. These are also known as autonomous sets [44, 43], closed sets [19], clans [17], stable sets, clumps [2] or externally related sets [26]. A module of a given graph $G=(V,E)$ is a subset $M\subseteq V$ with the property that for all vertices in $x,y\in M$ it holds that $N(y)\setminus M=N(x)\setminus M$. Therefore, the vertices within a given module $M$ are not distinguishable by the part of their neighborhoods that lie “outside” $M$. We denote with $\operatorname{MD}(G)$ the set of all modules of $G=(V,E)$. Clearly, the vertex set $V$ and the singletons $\{v\}$, $v\in V$ are modules, called trivial modules. A graph $G$ is called prime if it only contains trivial modules. For a module $M$ of $G$ and a vertex $v\in M$, we define the outM-neighborhood of $v$ as $N(v)\setminus M$. Since for any two vertices contained in $M$ the outM-neighborhoods are identical, we can equivalently define $N(v)\setminus M$ as the outM-neighborhood of the module $M$, where $v\in M$.

We say that a module $M$ of $G$ is parallel, resp., series if the induced subgraph $G[M]$, resp., the complement $\overline{G[M]}$ is disconnected. If both $G[M]$ and $\overline{G[M]}$ are connected, then $M$ is called prime.

For a graph $G=(V,E)$ let $M$ and $M^{\prime}$ be disjoint subsets of $V$. We say that $M$ and $M^{\prime}$ are adjacent (in $G$) if each vertex of $M$ is adjacent to all vertices of $M^{\prime}$; the sets are non-adjacent if none of the vertices of $M$ is adjacent to a vertex of $M^{\prime}$. Two disjoint modules are either adjacent or non-adjacent [43]. One can therefore define the quotient graph $G/P$ for an arbitrary subset $P\subseteq\operatorname{MD}(G)$ of pairwise disjoint modules: $G/P$ has $P$ as its vertex set and $M_{i}M_{j}\in E(G/P)$ if and only if $M_{i}$ and $M_{j}$ are adjacent in $G$.

A module $M$ is called strong if for any module $M^{\prime}\neq M$ either $M\cap M^{\prime}=\emptyset$, or $M\subseteq M^{\prime}$, or $M^{\prime}\subseteq M$, i.e., a strong module does not overlap any other module. The set of all strong modules $\operatorname{MDs}(G)\subseteq\operatorname{MD}(G)$ thus forms a hierarchy, the so-called modular decomposition of $G$. While arbitrary modules of a graph form a potentially exponential-sized family, the sub-family of strong modules has size $O(|V(G)|)$ [28].

Let $\operatorname{\mathbb{P}}=\{M_{1},\dots,M_{k}\}$ be a partition of the vertex set of a graph $G=(V,E)$. If every $M_{i}\in\operatorname{\mathbb{P}}$ is a module of $G$, then $\operatorname{\mathbb{P}}$ is a modular partition of $G$. A non-trivial modular partition $\operatorname{\mathbb{P}}=\{M_{1},\dots,M_{k}\}$ that contains only maximal (w.r.t inclusion) strong modules is a maximal modular partition. We denote the (unique) maximal modular partition of $G$ by $\operatorname{\mathbb{P_{\max}}}(G)$. We will refer to the elements of $\operatorname{\mathbb{P_{\max}}}(G[M])$ as the the children of $M$. This terminology is motivated by the following considerations:

The hierarchical structure of $\operatorname{MDs}(G)$ gives rise to a canonical tree representation of $G$, which is usually called the modular decomposition tree $T_{\textrm{MDs}}(G)$ [44, 27]. The root of this tree is the trivial module $V$ and its $|V|$ leaves are the trivial modules $\{v\}$, $v\in V$. The set of leaves $L_{v}$ associated with the subtree rooted at an inner vertex $v$ induces a strong module of $G$. In other words, each inner vertex $v$ of $T_{\textrm{MDs}}(G)$ represents the strong module $L_{v}$. An inner vertex $v$ is then labeled “parallel”, “series”, resp., “prime” if $L_{v}$ is a parallel, series, resp., prime module. The strong module $L_{v}$ of the induced subgraph $G[L_{v}]$ associated to a vertex $v$ labeled “prime” is called prime module. Note, the latter does not imply that the graph $G[L_{v}]$ is prime, however, in all cases the quotient graph $G[L_{v}]/\operatorname{\mathbb{P_{\max}}}(G[L_{v}])$ is prime [27]. Similar to cotrees it holds that $xy\in E$ if $u=\operatorname{lca}_{T_{\textrm{MDs}}(G)}(xy)$ is labeled “series”, and $xy\notin E$ if $u=\operatorname{lca}_{T_{\textrm{MDs}}(G)}(xy)$ is labeled “parallel”. However, to trace back the full structure of a given graph $G$ from $T_{\textrm{MDs}}(G)$ one has to store additionally the information of the subgraph $G[L_{v}]/\operatorname{\mathbb{P_{\max}}}(G[L_{v}])$ in the vertices $v$ labeled “prime”. Although, $\operatorname{MDs}(G)\subseteq\operatorname{MD}(G)$ does not represent all modules, we state the following remarkable fact [43, 12]: Any subset $M\subseteq V$ is a module if and only if $M\in\operatorname{MDs}(G)$ or $M$ is the union of children of non-prime modules. Thus, $T_{\textrm{MDs}}(G)$ represents at least implicitly all modules of $G$.

A simple polynomial time recursive algorithm to compute $T_{\textrm{MDs}}(G)$ is as follows [27]: (1) compute the maximal modular partition $\operatorname{\mathbb{P_{\max}}}(G)$; (2) label the root node according to the parallel, series or prime type of $G$; (3) for each strong module $M$ of $\operatorname{\mathbb{P_{\max}}}(G)$, compute $T_{\textrm{MDs}}(G[M])$ and attach it to the root node and proceed with $\operatorname{\mathbb{P_{\max}}}(G[M])$. The first polynomial time algorithm to compute the modular decomposition is due to Cowan et al. [10], and it runs in $O(|V|^{4})$. Improvements are due to Habib and Maurer [26], who proposed a cubic time algorithm, and to Müller and Spinrad [45], who designed a quadratic time algorithm. The first two linear time algorithms appeared independently in 1994 [9, 40]. Since then a series of simplified algorithms has been published, some running in linear time [13, 41, 52], and others in almost linear time [13, 42, 29, 28].

For later reference we give the following lemma.

Lemma 3.1**.**

Let $M$ be a module of a graph $G=(V,E)$ and $M^{\prime}\subseteq M$. Then, $M^{\prime}$ is a module of $G[M]$ if and only if $M^{\prime}$ is a module of $G$. If $M$ is a strong module of $G$, then $M^{\prime}$ is a strong module of $G[M]$ if and only if $M^{\prime}$ is a strong module of $G$. Moreover, if $M_{1}$ and $M_{2}$ are overlapping modules in $G$, then $M_{1}\setminus M_{2}$, $M_{1}\cap M_{2}$ and $M_{1}\cup M_{2}$ are also modules in $G$.

Proof.

The first and the last statement were shown in [43]. We prove the second statement.

Let $M\in\operatorname{MDs}(G)$. Assume that $M^{\prime}\subseteq M$ is a strong module of $G[M]$. Assume for contradiction that $M^{\prime}$ is not a strong module of $G$. Hence $M^{\prime}$ must overlap some module $M^{\prime\prime}$ in $G$. This module $M^{\prime\prime}$ cannot be entirely contained in $M$ as otherwise, $M^{\prime\prime}$ and $M^{\prime}$ overlap in $G[M]$ implying that $M^{\prime}$ is not a strong module of $G[M]$, a contradiction. But then $M$ and $M^{\prime\prime}$ must overlap, contradicting that $M$ is strong in $G$.

If $M^{\prime}\subseteq M$ is a strong module of $G$ then it does not overlap any module of $G$. Since every module of $G[M]$ is also a module of $G$, there cannot be a module of $G[M]$ that overlaps $M^{\prime}$ and thus, $M^{\prime}$ is a strong module of $G[M]$. ∎

3.3 Useful Properties of Modular Partitions

First, we briefly summarize the relationship between cographs $G$ and the modular decomposition $\operatorname{MDs}(G)$. While the first three items are from [4, 7], the proof of the fourth item can be found in [3, 30].

Theorem 3.2** ([4, 7, 30]).**

Let $G=(V,E)$ be an arbitrary graph. Then the following statements are equivalent.

$G$* is a cograph.* 2. 2.

$G$* does not contain induced paths on four vertices.* 3. 3.

$T_{\textrm{MDs}}(G)$* is the cotree of $G$ and hence, has no inner vertices labeled with “prime”.* 4. 4.

Define a set $\mathcal{R}(G)$ of triples as follows: For any three vertices $x,y,z\in V$ we add the triple $\mathrm{xy|z}$ to $\mathcal{R}(G)$ if either $xz,yz\in E$ and $xy\notin E$ or $xz,yz\notin E$ and $xy\in E$. There is a tree $T$ that displays all triples in $\mathcal{R}(G)$.

For later explicit reference, we summarize in the next theorem several results that we already implicitly referred to in the discussion above.

Theorem 3.3** ([25, 27, 43]).**

The following statements are true for an arbitrary graph $G=(V,E)$:

• (T1)

The maximal modular partition $\operatorname{\mathbb{P_{\max}}}(G)$ and the modular decomposition $\operatorname{MDs}(G)$ of $G$ are unique.

• (T2)

Let $\operatorname{\mathbb{P_{\max}}}(G[M])$ be the maximal modular partition of $G[M]$, where $M$ denotes a prime module of $G$ and $\operatorname{\mathbb{P}}^{\prime}\subsetneq\operatorname{\mathbb{P_{\max}}}(G[M])$ be a proper subset of $\operatorname{\mathbb{P_{\max}}}(G[M])$ with $|\operatorname{\mathbb{P}}^{\prime}|>1$. Then, $\bigcup_{M^{\prime}\in\operatorname{\mathbb{P}}^{\prime}}{M^{\prime}}\notin\operatorname{MD}(G)$.

• (T3)

Any subset $M\subseteq V$ is a module of $G$ if and only if $M$ is either a strong module of $G$ or $M$ is the union of children of a non-prime module of $G$.

Statements (T1) and (T3) are clear. Statement (T2) explains that none of the unions of elements of a maximal modular partition of $G[M]$ are modules of $G$, whenever $M$ is a prime module of $G$. Moreover, Statement (T3) can be used to show that all prime modules are strong.

Lemma 3.4**.**

Let $G=(V,E)$ be an arbitrary graph. Then, every prime module $M$ of $G$ is strong.

Proof.

Let $M$ be a prime module of $G$. Assume for contradiction that $M$ is not strong in $G$. Thm. 3.3(T3) implies that $M$ is the union of children of some non-prime module $M^{\prime}$. Hence, there is a subset $\mathcal{M}\subsetneq\operatorname{\mathbb{P_{\max}}}(G[M^{\prime}])$ such that $M=\bigcup_{M^{\prime}_{i}\in\mathcal{M}}M^{\prime}_{i}$. Note that $1<|\mathcal{M}|<|\operatorname{\mathbb{P_{\max}}}(G[M^{\prime}])|$, since all $M^{\prime}_{i}\in\operatorname{\mathbb{P_{\max}}}(G[M^{\prime}])$ are strong and $\bigcup_{M^{\prime}_{i}\in\operatorname{\mathbb{P_{\max}}}(G[M^{\prime}])}M^{\prime}_{i}=M^{\prime}$ is non-prime. As $M^{\prime}$ is non-prime, it is either parallel or series. Since $M$ is a non-trivial union of elements in $\operatorname{\mathbb{P_{\max}}}(G[M^{\prime}])$, $G[M]$ is either disconnected (if $M^{\prime}$ is parallel) or its complement $\overline{G[M]}$ is disconnected (if $M^{\prime}$ is series). But then $M$ is non-prime; a contradiction. Thus, $M$ is a strong module of $G$. ∎

In what follows, whenever the term “prime module” is used it refers therefore always to a strong module.

3.4 Cograph Editing

Given an arbitrary graph we are interested in understanding how the graph can be edited into a cograph. A well-studied problem is the following optimization problem.

Problem 1** (Optimal Cograph Editing).**

Given a graph $G=(V,E)$. Find a set $F\subseteq{{V}\choose{2}}$ of minimum cardinality such that $H=(V,E\bigtriangleup F)$ is a cograph.

We will simply call an edit set of minimum cardinality an optimal (cograph) edit set. For later reference we recall Lemma 9 of [35]. It shows that it suffices to solve the cograph editing problem separately for each connected component of $G$.

Lemma 3.5** ([35]).**

Let $G=(V,E)$ be a graph with optimal edit set $F$. Then $\{x,y\}\in F\setminus E$ implies that $x$ and $y$ are located in the same connected component of $G$.

Let $G=(V,E)$ be a graph and $F$ be an arbitrary edit set that transforms $G$ to the cograph $H=(V,E\bigtriangleup F)$. If any module of $G$ is a module of $H$, then $F$ is called module-preserving.

Proposition 3.6** ([25]).**

Every graph has an optimal module-preserving cograph edit set.

The importance of module-preserving edit sets lies in the fact that they update either all or none of the edges between any two disjoint modules. It is worth noting that module preserving edit sets do not necessarily preserve the property of modules being strong, i.e., although $M$ might be a strong module in $G$ it needs not to be strong in $H$.

Definition 3.1**.**

Let $G=(V,E)$ be a graph, $F$ a cograph edit set for $G$ and $M$ be a non-trivial module of $G$. The induced edit set in $G[M]$ is

[TABLE]

The next result shows that any optimal edit set $F$ can entirely expressed by the union of edits within prime modules and that $F[M]$ is an optimal edit set of $G[M]$ for any module $M$ of $G$. Hence, if $F[M]$ is not optimal for some module $M$ of $G$, then $F$ cannot be an optimal edit set for $G$.

Lemma 3.7** ([25]).**

Let $G=(V,E)$ be an arbitrary graph and let $M$ be a non-trivial module of $G$. If $F^{\prime}$ is an optimal edit set of the induced subgraph $G[M]$ and $F$ is an optimal edit set of $G$, then $(F\setminus F[M])\cup F^{\prime}$ is an optimal edit set of $G$. Thus, $|F[M]|=|F^{\prime}|$.

Moreover, the optimal cograph editing problem can be solved independently on the prime modules of $G$.

4 Module Merge is the Key to Cograph Editing

Since cographs are characterized by the absence of induced $P_{4}$s, we can interpret every optimal cograph-editing method as the removal of all $P_{4}$s in the input graph with a minimum number of edits. A natural strategy is therefore to detect $P_{4}$s and then to decide which edges must be edited. Optimal edit sets are not necessarily unique, see Figure 1. The computational difficulty arises from the fact that editing an edge of a $P_{4}$ can produce new $P_{4}$s in the updated graph. Hence, we cannot expect a priori that local properties of $G$ alone will allow us to identify optimal edits.

By Lemma 3.7, on the other hand, it is sufficient to edit within the prime modules. Moreover, as shown in Figure 1, there are strong modules $M^{\star}$ in an optimal edited cograph $H$ that are not modules in $G$. Hence, instead of editing $P_{4}$s in $G$, it might suffice to edit the out${}_{M_{i}}$-neighborhoods for some $M_{i}\in\operatorname{\mathbb{P_{\max}}}(G[M])$ in such a way that they result in the new module $M^{\star}$ in $H$. The following definitions are important for the concepts of the “module merge process” that we will extensively use in our approach.

Definition 4.1** (Module Merge).**

Let $G$ and $H$ be arbitrary graphs with $V(H)\subseteq V(G)$ and let $\operatorname{MD}(G)$ and $\operatorname{MD}(H)$ denote their corresponding sets of all modules. Consider a set $\mathcal{M}\coloneqq\{M_{1},M_{2},\dots,M_{k}\}\subseteq\operatorname{MD}(G)$. We say that the modules in $\mathcal{M}$ are merged (w.r.t. $H$) if

• (i)

$M_{1},\dots,M_{k}\in\operatorname{MD}(H)$,

• (ii)

$M\coloneqq\bigcup_{i=1}^{k}M_{i}\in\operatorname{MD}(H)$, and

• (iii)

$M\notin\operatorname{MD}(G)$.

We use the symbols \mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}} and $\to$ as operations that allows us to illustrate the merge process, that is, we write M_{1}\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}\ldots\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}M_{k}=\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}_{i=1}^{k}M_{i}\to M, whenever the modules $M_{1},M_{2},\dots,M_{k}$ are merged w.r.t. $H$ resulting in the module $M=\bigcup_{i=1}^{k}M_{i}$ of $H$.

The intuition is that the modules $M_{1}$ through $M_{k}$ of $G$ are merged into a single new module $M$, their union, that is present in $H$ but not in $G$. This, in particular, already defines all required edits to adjust the neighbors of the vertices in $\bigcup_{i=1}^{k}M_{i}$ in $G$ resulting in the module $M=\bigcup_{i=1}^{k}M_{i}$ of $H$. It is easy to verify that \mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}} is commutative in the sense that if M_{1}\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}M_{2}\to M, then M_{2}\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}M_{1}\to M. However, \mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}} is not necessarily associative. To see this, consider the example in Fig. 2. Although the module $M^{\star}_{3}$ in $H$ is obtained by merging the modules $\{3\}$, $\{4\}$ and $\{5\}$, the set $\{3\}\cup\{4\}$ does not form a module in $H$. Hence, although \{3\}\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}\{4\}\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}\{5\}\to M^{\star}_{3}, it does not hold that \{3\}\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}\{4\}\to M^{\star} for any module $M^{\star}$ in $H$. Thus, we cannot write (\{3\}\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}\{4\})\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}\{5\}\to M^{\star}_{3}.

It follows directly from Def. 4.1 that every new module $M$ of $H$ that is not a module of $G$ can be obtained by merging trivial modules: simply set $M=\bigcup_{x\in M}\{x\}$ and \mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}_{x\in M}\{x\}\to M follows immediately. In what follows we will show, however, that each strong module of $H$ that is not a module of $G$ can be obtained by merging the modules that are contained in $\operatorname{\mathbb{P_{\max}}}(G[M])$ of some prime module $M$ of $G$.

When modules $M_{1},\dots,M_{k}$ of $G$ are merged w.r.t. $H$ then all vertices in $M=\bigcup_{h=1}^{k}M_{h}$ must have the same outM-neighbors in $H$, while at least two vertices $x\in M_{i}$, $y\in M_{j}$, $1\leq i\neq j\leq k$ must have different outM-neighbors in $G$. Hence, in order to merge these modules it is necessary to change the outM-neighbors in $G$. However, edit operations between vertices within $M$ are dispensable for obtaining the module $M$.

Definition 4.2** (Module Merge Edit).**

Let $G=(V,E)$ be an arbitrary graph and $F$ be an arbitrary edit set resulting in the graph $H=(V,E\bigtriangleup F)$. Let $H^{\prime}\subseteq H$ be an induced subgraph of $H$ and suppose $M_{1},\dots,M_{k}\in\operatorname{MD}(G)$ are modules that have been merged w.r.t. $H^{\prime}$ resulting in the module $M=\bigcup_{i=1}^{k}M_{i}\in\operatorname{MD}(H^{\prime})$. We then call

[TABLE]

the module merge edits associated with \mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}_{i=1}^{k}M_{i}\to M w.r.t. $H^{\prime}$.

By construction, the edit set F_{H^{\prime}}(\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}_{i=1}^{k}M_{i}\to M) comprises exactly those (non)edges of $F$ that have been edited so that all vertices in $M$ have the same outM-neighborhood in $H^{\prime}=(V^{\prime},E^{\prime})$. In particular, it contains only (non)edges of $F$ that are not entirely contained in $G[M]$, but entirely contained in $H^{\prime}$. Moreover, (non)edges of $F$ that contain a vertex in $V(H^{\prime})$ and a vertex in $V\setminus V(H^{\prime})$ are not considered as well.

Let $G$ be an arbitrary graph and $F$ be an optimal edit set that applied to $G$ results in the cograph $H$. We will show that every optimal module-preserving edit set $F$ can be expressed completely by means of module merge edits. To this end, we will consider the prime modules $M$ of the given graph $G$ (in particular certain children of $M$ that do not share the same out-neighborhood) and adjust their out-neighbors to obtain new modules. Illustrative examples are given in Figure 1 and 2.

We are now in the position to derive the main results, Theorems 4.1-4.4. We begin with showing that each strong module of $H$ that is not a module of $G$ can be obtained by merging some children of a particular chosen prime module of $G$. Moreover, we prove that any strong module of $H$ that is a module of $G$ must also be strong in $G$.

Theorem 4.1**.**

Let $G=(V,E)$ be an arbitrary graph, $F$ an optimal module-preserving cograph edit set, and $H=(V,E\bigtriangleup F)$ the resulting cograph. Then, each strong module $M^{\star}$ of $H$ is either a module in $G$ or there exists a prime module $P_{M^{\star}}$ of $G$ that contains $M^{\star}$ and is minimal w.r.t. inclusion, i.e., there is no prime module $P^{\prime}_{M^{\star}}$ of $G$ with $M^{\star}\subseteq P^{\prime}_{M^{\star}}\subsetneq P_{M^{\star}}$. In the latter case $M^{\star}$ is obtained by merging some modules in $\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$.

Furthermore, if a strong module $M^{\star}$ of $H$ is a module in $G$, then $M^{\star}$ is a strong module of $G$.

Proof.

Let $M^{\star}$ be an arbitrary strong module of $H$ that is not a module of $G$. We show first that for the module $M^{\star}$ there is a prime module $P_{M^{\star}}$ of $G$ with $M^{\star}\subseteq P_{M^{\star}}$ such that there is no other prime module $P^{\prime}_{M^{\star}}$ of $G$ with $M^{\star}\subseteq P^{\prime}_{M^{\star}}\subsetneq P_{M^{\star}}$.

Since ${M^{\star}}$ is a module of $H$ but not of $G$ there are vertices $x\in M^{\star}$ and $y\in V\setminus M^{\star}$ with $\{x,y\}\in F$. Now, let $P_{M^{\star}}$ be the strong module of $G$ containing $x$ and $y$ that is minimal w.r.t. inclusion, that is, there is no other strong module of $G$ that is properly contained in $P_{M^{\star}}$ and that contains $x$ and $y$. Thus $\{x,y\}\in F[P_{M^{\star}}]$. Lemma 3.7 implies that $F[P_{M^{\star}}]$ is an optimal edit set of $G[P_{M^{\star}}]$. Since $P_{M^{\star}}$ is minimal w.r.t. inclusion it holds that $x$ and $y$ are from distinct children $M_{x},M_{y}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$. We continue to show that this strong module $P_{M^{\star}}$ is indeed prime. Assume for contradiction, that $P_{M^{\star}}$ is a non-prime module of $G$. If $P_{M^{\star}}$ is parallel, then editing $\{x,y\}$ would connect the two connected components $M_{x},M_{y}$ of $G[P_{M^{\star}}]$. Then, it follows by Lemma 3.5 that $F[P_{M^{\star}}]$ is not optimal; a contradiction. By similar arguments for the complement $\overline{G[P_{M^{\star}}]}$ it can be shown that $P_{M^{\star}}$ cannot be a series module. Thus $P_{M^{\star}}$ must be prime. Since $F$ is module-preserving, $P_{M^{\star}}$ is module in $H$. Hence, $P_{M^{\star}}$ and $M^{\star}$ cannot overlap, since $M^{\star}$ is strong in $H$. However, since $x\in P_{M^{\star}}\cap M^{\star}$ and $y\in P_{M^{\star}}$ but $y\notin M^{\star}$ we have $M^{\star}\subseteq P_{M^{\star}}$. Finally, since $P_{M^{\star}}$ is chosen to be minimal w.r.t. inclusion, there exists in particular no prime module $P^{\prime}_{M^{\star}}$ of $G$ with $M^{\star}\subseteq P^{\prime}_{M^{\star}}\subsetneq P_{M^{\star}}$.

We continue to show that $M^{\star}$ is obtained by merging some child modules of $P_{M^{\star}}$ in $G$, say $M_{1},\dots,M_{k}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$. Note that we just formally prove the existence of such a subset $\{M_{1},\dots,M_{k}\}\subset\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$ without explicitly constructing it. To this end, we need to verify the three conditions of Definition 4.1, i.e., (i) $M_{1},\dots,M_{k}\in\operatorname{MD}(H)$, (ii) $M^{\star}\coloneqq\bigcup_{i=1}^{k}M_{i}\in\operatorname{MD}(H)$, and (iii) $M^{\star}\notin\operatorname{MD}(G)$. Since each $M_{i}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$ is module of $G$ and $F$ is module-preserving, Condition (i) is always satisfied. Moreover, by assumption $M^{\star}\notin\operatorname{MD}(G)$ and thus Condition (iii) is satisfied.

It remains to show that Condition (ii) is satisfied. To this end, we show that there are modules $M_{1},\dots,M_{k}$ of $G$ (without explicitly constructing them) such that $M^{\star}=\bigcup_{i=1}^{k}M_{i}$. We prove this by showing that each module from $P_{M^{\star}}$ is either completely contained in, or disjoint from $M^{\star}$. First, note that $M^{\star}\neq P_{M^{\star}}$, since $M^{\star}$ is not a module of $G$. Second, $M^{\star}$ cannot overlap any $M_{i}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$, since $M_{i}$ is a module of $H$ and $M^{\star}$ is strong in $H$. We continue to show that there is no $M_{i}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$ such that $M^{\star}\subseteq M_{i}$. Assume for contradiction that there is a module $M_{i}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$ with $M^{\star}\subseteq M_{i}$. Note that $M_{i}$ cannot be prime in $G$, as otherwise $M^{\star}\subseteq M_{i}=P^{\prime}_{M^{\star}}\subsetneq P_{M^{\star}}$, contradicting the minimality of $P_{M^{\star}}$. Moreover, $M^{\star}$ cannot overlap any $M^{i}_{j}\in\operatorname{\mathbb{P_{\max}}}(G[M_{i}])$, since $M^{\star}$ is strong in $H$ and any $M^{i}_{j}$ is a module of $H$, since $F$ is module-preserving. Furthermore, since $M_{i}$ is non-prime in $G$ for any subset $\{M^{i}_{1},\ldots,M^{i}_{l}\}\subsetneq\operatorname{\mathbb{P_{\max}}}(G[M_{i}])$ it holds that the set $M^{\prime}=\bigcup_{j=1}^{l}M^{i}_{j}$ is a module of $G$ (cf. Theorem 3.3(T3)). Since $M^{\star}$ is no module of $G$ it cannot be a union of elements in $\operatorname{\mathbb{P_{\max}}}(G[M_{i}])$. Note that this especially implies that $M^{\star}\neq M_{i}$ and $M^{\star}\neq M^{i}_{j}$ for all $M^{i}_{j}\in\operatorname{\mathbb{P_{\max}}}(G[M_{i}])$. Now it follows, that $M^{\star}\subset M^{i}_{j}$ for some $M^{i}_{j}\in\operatorname{\mathbb{P_{\max}}}(G[M_{i}])$. Repeating the latter arguments and since $G$ is finite, there must be a minimal set $M^{a}_{b}$ with $M^{\star}\subset M^{a}_{b}\subset\dots\subset M^{i}_{j}\subset M_{i}$. Now we apply the latter arguments again and obtain that $M^{\star}\subset M^{\prime}\in\operatorname{\mathbb{P_{\max}}}(G[M^{a}_{b}])$ which is not possible, since $M^{a}_{b}$ is chosen to be the minimal module that contains $M^{\star}$. Thus, there is no $M_{i}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$ such that $M^{\star}\subseteq M_{i}$.

Now, since $M^{\star}\neq P_{M^{\star}}$, and $M^{\star}$ does not overlap any $M_{i}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$, and there is no $M_{i}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$ such that $M^{\star}\subseteq M_{i}$, there must be a set $\{M_{1},\ldots,M_{k}\}\subsetneq\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$ such that $M^{\star}=\bigcup_{i=1}^{k}M_{i}$. Thus, Condition (ii) is satisfied and therefore $M^{\star}$ is obtained by merging modules in $\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$.

Hence, any strong module of $H$ is either a module of $G$ or obtained by merging the children of a prime module of $G$.

Finally, assume that there is a strong module $M^{\star}$ in $H$ that is a module of $G$. Assume that $M^{\star}$ is not strong in $G$. Then there is a module $M$ in $G$ that overlaps $M^{\star}$. Since $F$ is module-preserving, $M$ is a module in $H$ and thus, $M$ overlaps $M^{\star}$ in $H$; a contradiction. Thus, any strong module $M^{\star}$ of $H$ that is also a module of $G$ must be strong in $G$. ∎

Theorem 4.1 allows us to give the following definitions that we will use in the subsequent part.

Definition 4.3**.**

Let $G=(V,E)$ be an arbitrary graph, $F$ an optimal module-preserving cograph edit set, and $H=(V,E\bigtriangleup F)$ the resulting cograph. Let $M^{\star}$ be a strong module of $H$ but no module of $G$.

We denote by $P_{M^{\star}}$ the prime module of $G$ that contains $M^{\star}$ and is minimal w.r.t. inclusion, i.e., there is no prime module $P^{\prime}_{M^{\star}}$ of $G$ with $M^{\star}\subseteq P^{\prime}_{M^{\star}}\subsetneq P_{M^{\star}}$. Furthermore, we denote by $\mathcal{C}(M^{\star})\subset\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$ the set of children of $P_{M^{\star}}$ that satisfies $\bigcup_{M_{i}\in\mathcal{C}(M^{\star})}M_{i}=M^{\star}$.

The next result provides a characterization of module-preserving edit sets by means of module merge of the children of prime modules.

Theorem 4.2**.**

Let $G=(V,E)$ be an arbitrary graph, $F$ an optimal cograph edit set, and $H=(V,E\bigtriangleup F)$ the resulting cograph. Then $F$ is module-preserving for $G$ if and only if each new strong module $M^{\star}$ of $H$ that is not a module of $G$ is obtained by merging the modules in $\mathcal{C}(M^{\star})\subset\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$, in symbols \mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}_{M_{i}\in\mathcal{C}(M^{\star})}M_{i}\to M^{\star}.

Proof.

If $F$ is an optimal and module-preserving edit-set for $G$, we can apply Theorem 4.1.

For the converse, assume for contraposition that $F$ is not module-preserving. Then, there is a module $M_{i}$ in $G$ that is not a module in $H$. Hence, there is a vertex $z\in V\setminus M_{i}$ and two vertices $x,y\in M_{i}$ such that $xz\in E(H)$ and $yz\notin E(H)$ and thus, either $\{x,z\}\in F$ or $\{y,z\}\in F$. There are two cases, either $xy\in E(H)$ or $xy\notin E(H)$. Since $H$ is a cograph we can apply Theorem 3.2 and conclude that either $\mathrm{yz|x}\in\mathcal{R}(H)$ or $\mathrm{xz|y}\in\mathcal{R}(H)$. Assume that $\mathrm{xz|y}\in\mathcal{R}(H)$ and let $T$ be the cotree of $H$. Since $T$ displays $\mathrm{xz|y}$, the strong module $M^{\star}$ of $H$ located at the $\operatorname{lca}_{T}(x,z)$ contains the vertices $x$ and $z$ but not $y$. Moreover, since there is an edit $\{x,z\}$ or $\{y,z\}$ in $F$ there is a strong prime module $P_{M^{\star}}$ in $G$ that contains $x,y,z$ and is minimal w.r.t. inclusion. Note, $M_{i}\neq P_{M^{\star}}$ since $x,y\in M_{i}$ and $z\not\in M_{i}$. Moreover, since $M_{i}$ is a module in $G$, but none of the unions of the children of $P_{M^{\star}}$ is a module of $G$ (cf. Theorem 3.3(T3)), we can conclude that $M_{i}\subseteq M^{\prime}$, where $M^{\prime}$ is a child of $P_{M^{\star}}$ in $G$. Since $P_{M^{\star}}$ is the minimal prime module that contains $x,y,z$ and there is an edit $\{x,z\}$ or $\{y,z\}$ in $F$, the vertex $z$ must be located in a module different from the module $M^{\prime}$ that contains both $x$ and $y$. Thus, $z\notin M^{\prime}$. Therefore, there is no module in $G$ that contains $x$ and $z$ but not $y$. Thus, $M^{\star}$ is no module of $G$. Since there is no module in $G$ that contains $x$ and $z$ but not $y$, the set $M^{\star}$ cannot be written as the union of children of any strong prime module $P_{M^{\star}}$ and thus, $M^{\star}$ is not obtained by merging modules of $\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$. The case $\mathrm{yz|x}\in\mathcal{R}(H)$ is shown analogously. ∎

Combining the latter results, it can be shown that for every graph $G$ there is always an optimal edit set such that the resulting cograph $H$ contains all modules of $G$ and any newly created strong module $M^{\star}$ of $H$ is obtained by merging the respective modules in $\mathcal{C}(M^{\star})$.

Theorem 4.3**.**

Any graph $G=(V,E)$ has an optimal edit-set $F$ such that each strong module $M^{\star}$ in $H=(V,E\bigtriangleup F)$ that is not a module of $G$ is obtained by merging modules in $\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$, where $P_{M^{\star}}$ is a prime module of $G$.

Proof.

Proposition 3.6 implies that any graph has a module-preserving optimal edit set. Hence, we can apply Theorem 4.2 to derive the statement. ∎

Finally, the following result shows that each module-preserving edit set can indeed be derived by considering the module merge edits only.

Theorem 4.4**.**

Let $G=(V,E)$ be an arbitrary graph, $F$ an optimal module-preserving cograph edit set, $H=(V,E\bigtriangleup F)$ the resulting cograph, and $\mathcal{M}$ the set of all strong modules of $H$ that are no modules of $G$. Then,

[TABLE]

Proof.

We set F^{\star}=\bigcup_{M^{\star}\in\mathcal{M}}\left(F_{H[P_{M^{\star}}]}(\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}_{M_{i}\in\mathcal{C}(M^{\star})}M_{i}\to M^{\star})\right). Clearly, it holds that $F^{\star}\subseteq F$. It remains to show that, $F\subseteq F^{\star}$. First, observe, that every edit $\{x,y\}\in F$ is between distinct children $M_{x},M_{y}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$ of a prime module $P_{M^{\star}}$ of $G$. To see this, let $P_{M^{\star}}$ be a strong module of $G$ such that $x$ and $y$ are in distinct children $M_{x},M_{y}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$ and assume for contradiction that $P_{M^{\star}}$ is non-prime in $G$. Let $F^{\prime}\coloneqq\bigcup_{M_{i}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])}F[M_{i}]$. Since $P_{M^{\star}}$ is non-prime in $G$ it follows that $F^{\prime}$ is an edit set for $G[P_{M^{\star}}]$, that is, $G[P_{M^{\star}}]\Delta F^{\prime}$ is a cograph. But $|F^{\prime}|<|F[P_{M^{\star}}]|$; contradicting Lemma 3.7. Thus, every edit $\{x,y\}\in F$ is between distinct children $M_{x},M_{y}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$ of a prime module $P_{M^{\star}}$ of $G$.

Assume that $\{x,y\}\in F$, but $\{x,y\}\notin F^{\star}$. By the latter arguments, there is a prime module $P_{M^{\star}}$ of $G$ with $x\in M_{x}$ and $y\in M_{y}$ and $M_{x},M_{y}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$. Now let $M^{\prime}_{x}$ be the strong module of $H$ that contains $x$ but not $y$ and that is maximal w.r.t. inclusion. Since $F$ is module-preserving, $M_{x}$ is a module in $H$. Moreover, since $M^{\prime}_{x}$ is a strong module of $H$, the modules $M^{\prime}_{x}$ and $M_{x}$ do not overlap in $H$. Therefore, either $M_{x}\subsetneq M^{\prime}_{x}$ or $M^{\prime}_{x}\subseteq M_{x}$. We show first that the case $M_{x}\subsetneq M^{\prime}_{x}$ is not possible. Assume for contradiction, that $M_{x}\subsetneq M^{\prime}_{x}$. Thus, there is a vertex $z\in M^{\prime}_{x}\setminus M_{x}$. Since $P_{M^{\star}}$ is prime in $G$ and $M_{x}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$, we can apply Theorem 3.3 (T2) and conclude that there is no other module than $M_{x}$ in $G$ that entirely contains $M_{x}$ but not $y$. Since $M_{x}\subsetneq M^{\prime}_{x}\subsetneq P_{M^{\star}}$ it follows that $M^{\prime}_{x}$ is a new strong module of $H$ and therefore, by Theorem 4.1, obtained by merging modules $M_{1},\ldots,M_{k}\in\mathcal{C}(M^{\prime}_{x})\subsetneq\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}}])$. But then \{x,y\}\in F_{H[P_{M^{\star}}]}(\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}_{M_{i}\in\mathcal{C}(M^{\prime}_{x})}M_{i}\to M^{\prime}_{x})\subseteq F^{\star}; contradicting that $\{x,y\}\notin F^{\star}$. Hence, $M^{\prime}_{x}\subseteq M_{x}$. Similarly, $M^{\prime}_{y}\subseteq M_{y}$ for the strong module $M^{\prime}_{y}$ of $H$ that contains $y$ but not $x$ and that is maximal w.r.t. inclusion.

Consider now the strong module $M^{\star}$ of $H$ that is identified with the lowest common ancestor of the modules $\{x\}$ and $\{y\}$ within the cotree of $H$. Then, there are distinct children in $\operatorname{\mathbb{P_{\max}}}(H[M^{\star}])$, containing $x$ and $y$, respectively. Since $M^{\prime}_{x}$ is the strong module of $H$ that contains $x$ but not $y$ and that is maximal w.r.t. inclusion, we have $M^{\prime}_{x}\in\operatorname{\mathbb{P_{\max}}}(H[M^{\star}])$. Analogously, $M^{\prime}_{y}\in\operatorname{\mathbb{P_{\max}}}(H[M^{\star}])$.

Both, $M_{x}$ as well as $M_{y}$ are modules in $H$ and $G$. Since $F$ is module-preserving, either all or none of the edges between $M_{x}$ and $M_{y}$ are edited. Since $\{x,y\}\in F$ we have, therefore, $\{x^{\prime},y^{\prime}\}\in F$ for all $x^{\prime}\in M^{\prime}_{x}\subseteq M_{x}$ and $y^{\prime}\in M^{\prime}_{y}\subseteq M_{y}$. Let $F^{\prime}\coloneqq\{\{x^{\prime},y^{\prime}\}\mid x^{\prime}\in M^{\prime}_{x},y^{\prime}\in M^{\prime}_{y}\}$. By the latter argument $F^{\prime}\neq\emptyset$ and $F^{\prime}\subseteq F$.

Note, the subgraphs $H[M^{\prime}_{x}]$ and $H[M^{\prime}_{y}]$ are cographs. Since $M^{\star}$ is either a parallel or a series module in $H$, we have either (i) H[M^{\prime}_{x}\cup M^{\prime}_{y}]=H[M^{\prime}_{x}]\mathbin{\mathchoice{\ooalign{\displaystyle\cup$\cr$\displaystyle\cdot}}{\ooalign{\textstyle\cup$\cr$\textstyle\cdot}}{\ooalign{\scriptstyle\cup$\cr$\scriptstyle\cdot}}{\ooalign{\scriptscriptstyle\cup$\cr$\scriptscriptstyle\cdot}}}H[M^{\prime}_{y}] or (ii) $H[M^{\prime}_{x}\cup M^{\prime}_{y}]=H[M^{\prime}_{x}]\oplus H[M^{\prime}_{y}]$, respectively. Since $F^{\prime}$ comprises the edits $\{x^{\prime},y^{\prime}\}$ between all vertices $x^{\prime}\in M^{\prime}_{x}$ and $y^{\prime}\in M^{\prime}_{y}$, the graph $H[M^{\prime}_{x}\cup M^{\prime}_{y}]\bigtriangleup F^{\prime}$ is in case (i) the graph $H[M^{\prime}_{x}]\oplus H[M^{\prime}_{y}]$ and in case (ii) H[M^{\prime}_{x}]\mathbin{\mathchoice{\ooalign{\displaystyle\cup$\cr$\displaystyle\cdot}}{\ooalign{\textstyle\cup$\cr$\textstyle\cdot}}{\ooalign{\scriptstyle\cup$\cr$\scriptstyle\cdot}}{\ooalign{\scriptscriptstyle\cup$\cr$\scriptscriptstyle\cdot}}}H[M^{\prime}_{y}]. By definition, in both cases $H[M^{\prime}_{x}\cup M^{\prime}_{y}]\bigtriangleup F^{\prime}$ is a cograph. Note that $F^{\prime}$ did not change the out${}_{M^{\prime}_{x}\cup M^{\prime}_{y}}$-neighborhood and thus, the graph $H[M^{\star}]\bigtriangleup F^{\prime}=G[M^{\star}]\bigtriangleup(F[M^{\star}]\setminus F^{\prime})$ is a cograph as well. Since $\{x,y\}\in F^{\prime}\cap F[M^{\star}]$ it holds that $|F[M^{\star}]\setminus F^{\prime}|<|F[M^{\star}]|$. But then, $F[M^{\star}]$ is not optimal, and therefore, by Lemma 3.7 the set $F$ is not optimal; a contradiction.

In summary, there exists no edit $\{x,y\}\in F$ with $\{x,y\}\notin F^{\star}$. Hence, $F\subseteq F^{\star}$ and the statement follows. ∎

From an algorithmic perspective, Theorem 4.4 implies that it is sufficient to correctly determine the set of strong modules of a resulting cograph $H$ that are no modules of the given graph $G$. Afterwards, the module-preserving edit set $F$ is obtained by taking all the edits needed for the corresponding module merge operations. On the other hand, by Theorem 4.3 it is ensured that such a closest cograph $H$ that contains all modules of $G$ always exists.

5 Pairwise Module Merge and Algorithmic Issues

So far, we have shown that for an arbitrary graph $G=(V,E)$ there is an optimal module-preserving edit set $F$ that transforms $G$ into the cograph $H=(V,E\bigtriangleup F)$ (cf. Theorem 4.3). Moreover, this edit set $F$ can be expressed in terms of edits derived by module merge operations on the strong modules of $H$ that are no modules of $G$ (cf. Theorem 4.4). In what follows, we show that there is an explicit order in which these individual merge operations can be consecutively applied to $G$ such that all intermediate edit-steps result in graphs that contain all modules of $G$, and, moreover, all new strong modules produced in this edit-step are preserved in any further step. In Section 5.1, we show that an optimal edit set can always be obtained by a series of “ordered” pairwise merge operations. In Section 5.2, we show that the latter “order”-condition can even be relaxed and that particular modules can be pairwisely merged in an arbitrary order to obtain an optimal edited graph.

The next Lemma shows that the number of edits in an optimal edit set $F$ can be expressed as the sum of individual edits based on the \mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}-operator to obtain the strong modules in a cograph $H=G\bigtriangleup F$ that are no modules in $G$.

Lemma 5.1**.**

Let $G=(V,E)$ be a graph, $F$ an optimal module-preserving cograph edit-set, and $H=(V,E\bigtriangleup F)$ the resulting cograph. Let $\mathcal{M}=\{M^{\star}_{1},\dots,M^{\star}_{n}\}$ be the set of all strong modules of $H$ that are no modules of $G$ and assume that the elements in $\mathcal{M}$ are partially ordered w.r.t. inclusion, i.e., $M^{\star}_{i}\subseteq M^{\star}_{j}$ implies $i\leq j$.

Let $M^{\star}\in\mathcal{M}$. We set $F_{M^{\star}}\coloneqq\{\{x,v\}\in F\ \mid\ x\in M^{\star},v\in P_{M^{\star}}\setminus M^{\star}\}$, that is, the set $F_{M^{\star}}\subseteq F$ comprises all edits in $F$ that are used to obtain the module $M^{\star}$ within $G[P_{M^{\star}}]$.

Furthermore, we set $\sigma_{M^{\star}_{1}}=F_{M^{\star}_{1}}$ and $\sigma_{M^{\star}_{i}}=F_{M^{\star}_{i}}\setminus(\bigcup_{j=1}^{i-1}F_{M^{\star}_{j}})$, $2\leq i\leq n$. Then

[TABLE]

Moreover, for each intermediate graph $G_{j}=G\bigtriangleup\left(\bigcup_{i=1}^{j}\sigma_{M^{\star}_{i}}\right)$ and any $M^{\star}_{i}\in\mathcal{M}$ with $i-1\leq j$ we have

[TABLE]

In each step $j$ the induced subgraphs $G_{j}[M^{\star}_{i}]$ are already cographs for all sets $M^{\star}_{i}$ with $i-1\leq j$ and hence $F[M^{\star}_{i}]\setminus\bigcup_{k=1}^{j}\sigma_{M^{\star}_{k}}=\emptyset$, for all $i-1\leq j$.

Proof.

By Theorem 4.1, for each $M^{\star}\in\mathcal{M}$ there is an inclusion-minimal prime module ${P}_{M^{\star}}$ in $G$ and a set of children $\mathcal{C}(M^{\star})\subseteq\operatorname{\mathbb{P_{\max}}}(G[{P}_{M^{\star}}])$ such that \mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}_{M_{i}\in\mathcal{C}(M^{\star})}M_{i}\to M^{\star}. Thus, ${P}_{M^{\star}}$ and $\mathcal{C}(M^{\star})$ exists and $\mathcal{C}(M^{\star})$ is not empty.

Now, we show that $|F|$ can be expressed by the sum of the size of the edits in $\sigma_{M^{\star}_{i}}$ To this end, observe that by Theorem 4.4, F=\bigcup_{M^{\star}\in\mathcal{M}}\left(F_{H[P_{M^{\star}}]}(\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}_{M_{i}\in\mathcal{C}(M^{\star})}M_{i}\to M^{\star})\right). Thus, $F=\bigcup_{M^{\star}\in\mathcal{M}}F_{M^{\star}}$. By construction of $\sigma_{M^{\star}_{i}}$ it holds first that $\bigcup_{i=1}^{n}\sigma_{M^{\star}_{i}}=\bigcup_{i=1}^{n}F_{M^{\star}_{i}}$ and second that $\sigma_{M^{\star}_{i}}\cap\sigma_{M^{\star}_{j}}=\emptyset$ for all $i\neq j$. Hence, F=\mathop{\vphantom{\bigcup}\mathchoice{\ooalign{\displaystyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\displaystyle\cdot}}}}{\ooalign{\textstyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\textstyle\cdot}}}}{\ooalign{\scriptstyle\bigcup\cr\raise-6.61116pt\hbox{\scalebox{2.0}{\scriptstyle\cdot}}}}{\ooalign{\scriptscriptstyle\bigcup\cr\raise-4.72224pt\hbox{\scalebox{2.0}{\scriptscriptstyle\cdot}}}}}_{i=1}^{n}\sigma_{M^{\star}_{i}} and thus, $|F|=\sum_{i=1}^{n}|\sigma_{M^{\star}_{i}}|$.

By construction, $\mathcal{M}$ is partially ordered w.r.t. inclusion. We want to show that $G_{j}[M^{\star}_{i}]=H[M^{\star}_{i}]$ for all $i-1\leq j$. To this end, we show that $F[M^{\star}_{i}]\setminus\bigcup_{k=1}^{j}\sigma_{M^{\star}_{k}}=\emptyset$, in which case after each step $j$ there are no more edits left to modify an edge between vertices within $M^{\star}_{i}$. We show first that the latter is satisfied for all $1\leq i\leq n$ and a fixed $j=i-1$. Assume for contradiction that $\{x,y\}\in F[M^{\star}_{i}]\setminus\bigcup_{k=1}^{i-1}\sigma_{M^{\star}_{k}}$ and thus, $x,y\in M^{\star}_{i}$. Since $\{x,y\}\in F=\bigcup_{k=1}^{n}F_{M^{\star}_{k}}$, there must be a module $M^{\star}_{\ell}\in\mathcal{M}$ such that $\{x,y\}\in F_{M^{\star}_{\ell}}$. By construction, $F_{M^{\star}_{\ell}}$ contains only the edits that affect the out${}_{M^{\star}_{\ell}}$-neighborhood. Thus, w.l.o.g. we can assume that $x\in M^{\star}_{\ell}$ and $y\not\in M^{\star}_{\ell}$. Since $M^{\star}_{\ell}$ and $M^{\star}_{i}$ are strong modules, they do not overlap, and therefore, $M^{\star}_{\ell}\subsetneq M^{\star}_{i}$. However, since $\mathcal{M}$ is partially ordered, we can conclude that ${\ell}<i$ and therefore, $\{x,y\}\in\bigcup_{k=1}^{i-1}\sigma_{M^{\star}_{k}}$. Hence, $\{x,y\}\notin F[M^{\star}_{i}]\setminus\bigcup_{k=1}^{i-1}\sigma_{M^{\star}_{k}}$; a contradiction. Thus, $F[M^{\star}_{i}]\setminus\bigcup_{k=1}^{i-1}\sigma_{M^{\star}_{k}}=\emptyset$ for all $1\leq i\leq n$. But then, clearly $F[M^{\star}_{i}]\setminus\bigcup_{k=1}^{j}\sigma_{M^{\star}_{k}}=\emptyset$ holds for any $j\geq i-1$. Thus, $G_{j}[M^{\star}_{i}]=H[M^{\star}_{i}]$ for all $i-1\leq j$. ∎

The following Lemma shows that, given the explicit order $\mathcal{M}=\{M^{\star}_{1},\dots,M^{\star}_{n}\}$ from Lemma 5.1, in which the edits are applied to the graph $G$, the intermediate graphs $G_{i}$ retain all modules of $G$ and also all new modules $M^{\star}_{j}$, $j\leq i$.

Lemma 5.2**.**

Let $G=(V,E)$ be an arbitrary graph, $F$ an optimal module-preserving cograph edit set, and $H=(V,E\bigtriangleup F)$ the resulting cograph. Moreover, let $\mathcal{M}=\{M^{\star}_{1},\dots,M^{\star}_{n}\}$ be the partially ordered (w.r.t. inclusion) set of all strong modules of $H$ that are no modules of $G_{0}\coloneqq G$, and choose $\sigma_{M^{\star}_{i}}$, $F_{M^{\star}_{i}}$ and the intermediate graphs $G_{i}$, $1\leq i\leq n$ as in Lemma 5.1.

Then, any module $M^{\prime}$ of $G$ is a module of $G_{i}$ and the set $M^{\star}_{j}$ is a module of $G_{i}$ for $1\leq i\leq n$ and any $j\leq i$.

Proof.

First note that $\sigma_{M^{\star}_{i}}$ affects only modules that are entirely contained in $P_{M^{\star}_{i}}$ and only their out-neighbors within $P_{M^{\star}_{i}}$. Moreover $M^{\star}_{j}\subseteq M^{\star}_{i}$ implies that $P_{M^{\star}_{j}}\subseteq P_{M^{\star}_{i}}$. The partial ordering of the elements in $\mathcal{M}$ implies that $P_{M^{\star}_{i}}$ remains a module in $G_{i}$.

Before we prove the main statement, we show first that the following statement is satisfied:

Claim 1:

For every $M^{\prime}$ with $M^{\star}_{i}\subsetneq M^{\prime}\subsetneq P_{M^{\star}_{i}}$ we have $M^{\prime}\neq M^{\star}_{j}\in\mathcal{M}$, $j\leq i$ and $M^{\prime}$ cannot be a module of $G$.

Let $M^{\prime}$ be an arbitrary set with $M^{\star}_{i}\subsetneq M^{\prime}\subsetneq P_{M^{\star}_{i}}$. By the partial order of the elements in $\mathcal{M}$ we immediately observe that $M^{\prime}\neq M^{\star}_{j}\in\mathcal{M}$ for any $j\leq i$. Now assume for contradiction that $M^{\prime}$ is a module of $G$. Note, all elements in $\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}_{i}}])$ are strong modules of $G$, and thus, do not overlap the module $M^{\prime}$. Moreover, since $P_{M^{\star}_{i}}$ is prime in $G$, we can apply Theorem 3.3(T2) and conclude that the union of elements of any proper subset $\operatorname{\mathbb{P}}^{\prime}\subsetneq\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}_{i}}])$ with $|\operatorname{\mathbb{P}}^{\prime}|>1$ is not a module of $G$. Taken the latter arguments together and because $M^{\prime}\subsetneq P_{M^{\star}_{i}}$, we have $M^{\prime}\subseteq M_{\ell}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}_{i}}])$ for some $\ell$. Hence, $M^{\star}_{i}\subsetneq M^{\prime}\subseteq M_{\ell}$. However, since $M^{\star}_{i}$ is the union of some children $\operatorname{\mathbb{P}}^{\prime}\subseteq\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}_{i}}])$ of $P_{M^{\star}_{i}}$ it follows that $M_{\ell}\subseteq M^{\star}_{i}$; a contradiction. This proves Claim 1.

We continue with proving the main statement by induction over $i$. Since $G_{0}=G$, the statement is satisfied for $G_{0}$. We continue to show that the statement is satisfied for $G_{i+1}$ under the assumption that it is satisfied for $G_{i}$.

For further reference, we note that $P_{M^{\star}_{i+1}}$ is a module of $G_{i}$, since $P_{M^{\star}_{i+1}}$ is a module of $G$ and by induction assumption. Moreover, $P_{M^{\star}_{i+1}}$ remains a module of $G_{i+1}$, since $G_{i+1}=G_{i}\bigtriangleup\sigma_{M^{\star}_{i+1}}$ and $\sigma_{M^{\star}_{i+1}}$ does not affect the out${}_{P_{M^{\star}_{i+1}}}$-neighborhood. Furthermore, $M^{\star}_{i+1}$ is a module of $H$ and thus, of $H[P_{M^{\star}_{i+1}}]$. Since $\sigma_{M^{\star}_{i+1}}$ contains all such edits to adjust $M^{\star}_{i+1}$ to a module in $H[P_{M^{\star}_{i+1}}]$, we can conclude that $M^{\star}_{i+1}$ is a module in $G_{i+1}[P_{M^{\star}_{i+1}}]$. Therefore, Lemma 3.1 implies that $M^{\star}_{i+1}$ is a module of $G_{i+1}$.

Now, let $M^{\prime}$ be an arbitrary module of $G$. We proceed to show that $M^{\prime}$ is a module of $G_{i+1}$. By induction assumption, each module $M^{\prime}$ of $G$ is a module of $G_{i}$. Since $F$ is module-preserving, $M^{\prime}$ is also a module of $H$. Hence, $M^{\prime}\in\operatorname{MD}(G)\cap\operatorname{MD}(G_{i})\cap\operatorname{MD}(H)$. Moreover, by Claim 1 the case $M^{\star}_{i+1}\subsetneq M^{\prime}\subsetneq P_{M^{\star}_{i+1}}$ cannot occur for any module $M^{\prime}$ of $G$.

Note, the module $M^{\prime}$ cannot overlap $P_{M^{\star}_{i+1}}$, since $P_{M^{\star}_{i+1}}$ is strong in $G$. Hence, for $M^{\prime}$ one of the following three cases can occur: either $P_{M^{\star}_{i+1}}\subseteq M^{\prime}$, $P_{M^{\star}_{i+1}}\cap M^{\prime}=\emptyset$, or $M^{\prime}\subsetneq P_{M^{\star}_{i+1}}$. In the first two cases, $M^{\prime}$ remains a module of $G_{i+1}$, since $\sigma_{M^{\star}_{i+1}}$ contains only edits between vertices within $P_{M^{\star}_{i+1}}$, and thus, the out${}_{M^{\prime}}$-neighborhood is not affected. Therefore, assume that $M^{\prime}\subsetneq P_{M^{\star}_{i+1}}$. The module $M^{\prime}$ cannot overlap $M^{\star}_{i+1}$, since $M^{\star}_{i+1}$ is strong in $H$. As shown above, the case $M^{\star}_{i+1}\subsetneq M^{\prime}\subsetneq P_{M^{\star}_{i+1}}$ cannot occur, and thus we have either (1) $M^{\prime}\subseteq M^{\star}_{i+1}$, or (2) $M^{\star}_{i+1}\cap M^{\prime}=\emptyset$.

Case (1)

Since $\sigma_{M^{\star}_{i+1}}$ affects only the out${}_{M^{\star}_{i+1}}$-neighborhood, there is no edit between vertices in $M^{\prime}$ and $M^{\star}_{i+1}\setminus M^{\prime}$ and, moreover, $G_{i+1}[M^{\star}_{i+1}]=G_{i}[M^{\star}_{i+1}]$. By assumption, $M^{\prime}$ is a module of $G_{i}$. Thus, $M^{\prime}$ is a module in any induced subgraph of $G_{i}$ that contains $M^{\prime}$ and hence, in particular in $G_{i}[M^{\star}_{i+1}]$. Hence, $M^{\prime}$ is a module of $G_{i+1}[M^{\star}_{i+1}]$. Now, we can apply Lemma 3.1 and conclude that $M^{\prime}$ is also a module of $G_{i+1}$.

Case (2)

Assume for contradiction that $M^{\prime}$ is no module of $G_{i+1}$. Thus, there must be an edge $xy\in E(G_{i+1})$, $x\in M^{\prime},y\in V\setminus M^{\prime}$ such that for some other vertex $x^{\prime}\in M^{\prime}$ we have $x^{\prime}y\notin E(G_{i+1})$. Since $M^{\prime}$ is a module of $G_{i}$ it must hold that $\{x,y\}\in\sigma_{M^{\star}_{i+1}}$ or $\{x^{\prime},y\}\in\sigma_{M^{\star}_{i+1}}$. Since $x,x^{\prime}\notin M^{\star}_{i+1}$ and each edit in $\sigma_{M^{\star}_{i+1}}$ affects a vertex within $M^{\star}_{i+1}$, we can conclude that $y\in M^{\star}_{i+1}$. Now, by construction of $F_{M^{\star}_{i+1}}$ and since $M^{\prime}\subsetneq P_{M^{\star}_{i+1}}$, all edits between vertices of $M^{\star}_{i+1}$ and $M^{\prime}$ are entirely contained in $F_{M^{\star}_{i+1}}$. But this implies that none of the sets $\sigma_{M^{\star}_{\ell}}$ with $\ell>i+1$ contains $\{x,y\}$ or $\{x^{\prime},y\}$. Hence, it holds that $xy\in E(H)$ and $x^{\prime}y\notin E(H)$, which implies that $M^{\prime}$ is no module of $H$; a contradiction.

Therefore, each module $M^{\prime}$ of $G$ is a module of $G_{i+1}$.

We proceed to show that $M^{\star}_{j}\in\mathcal{M}$ is a module of $G_{i+1}$ for all $j\leq i+1$. As we have already shown this for $j=i+1$, we proceed with $j<i+1$. By induction assumption, each module $M^{\star}_{j}$ is a module of $G_{i}$ for all $j<i+1$. Note, the module $M^{\star}_{j}$ cannot overlap $P_{M^{\star}_{i+1}}$, since $M^{\star}_{j}$ is strong in $H$ and $P_{M^{\star}_{i+1}}$ is a module of $H$, because $F$ is module-preserving. Hence, for $M^{\star}_{j}$ one of the following three cases can occur: either $P_{M^{\star}_{i+1}}\subseteq M^{\star}_{j}$, $P_{M^{\star}_{i+1}}\cap M^{\star}_{j}=\emptyset$, or $M^{\star}_{j}\subsetneq P_{M^{\star}_{i+1}}$. In the first two cases, $M^{\star}_{j}$ remains a module of $G_{i+1}$, since $\sigma_{M^{\star}_{i+1}}$ contains only edits between vertices within $P_{M^{\star}_{i+1}}$, and thus, the out${}_{M^{\star}_{j}}$-neighborhood is not affected. Therefore, assume that $M^{\star}_{j}\subsetneq P_{M^{\star}_{i+1}}$. The module $M^{\star}_{j}$ cannot overlap $M^{\star}_{i+1}$, since both are strong in $H$. Due to the partial ordering of the elements in $\mathcal{M}$, the case $M^{\star}_{i+1}\subsetneq M^{\star}_{j}$ cannot occur. Hence there are two cases, either (A) $M^{\star}_{j}\subseteq M^{\star}_{i+1}$, or (B) $M^{\star}_{i+1}\cap M^{\star}_{j}=\emptyset$.

Case (A)

Since $\sigma_{M^{\star}_{i+1}}$ affects only the out${}_{M^{\star}_{i+1}}$-neighborhood, there is no edit between vertices in $M^{\star}_{j}$ and $M^{\star}_{i+1}\setminus M^{\star}_{j}$. By analogous arguments as in Case (1), we can conclude that $M^{\star}_{j}$ remains a module of $G_{i+1}[M^{\star}_{i+1}]$. Lemma 3.1 implies that $M^{\star}_{j}$ is also a module of $G_{i+1}$.

Case (B)

Assume for contradiction that $M^{\star}_{j}$ is no module of $G_{i+1}$. Thus, there must be an edge $xy\in E(G_{i+1})$, $x\in M^{\star}_{j},y\in V\setminus M^{\star}_{j}$ such that for some other vertex $x^{\prime}\in M^{\star}_{j}$ we have $x^{\prime}y\notin E(G_{i+1})$. Since $M^{\star}_{j}$ is a module of $G_{i}$ it must hold that $\{x,y\}\in\sigma_{M^{\star}_{i+1}}$ or $\{x^{\prime},y\}\in\sigma_{M^{\star}_{i+1}}$. Now, we can argue analogously as in Case (2) and conclude that $xy\in E(H)$ and $x^{\prime}y\notin E(H)$, which implies that $M^{\star}_{j}$ is no module of $H$; a contradiction.

Therefore, each module $M^{\star}_{j}$, $j\leq i+1$ is a module of $G_{i+1}$. ∎

The latter two Lemmata show that there exists an explicit order, in which all new modules $M^{\star}_{i}$ of $H$ can be constructed such that whenever a module $M^{\star}_{i}$ is produced step $i$ the induced subgraph $G_{i-1}[M^{\star}_{i}]$ is already a cograph and, moreover, is not edited any further in subsequent steps.

5.1 Pairwise Module-merge

Regarding Lemma 5.1, each module $M^{\star}_{i}$ is created by applying the remaining edits $\sigma_{M^{\star}_{i}}\subseteq F_{M^{\star}_{i}}$ of the module merge \mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}_{M^{\prime}\in\mathcal{C}(M^{\star}_{i})}M^{\prime}\to M^{\star}_{i} to the previous intermediate graph $G_{i-1}$. Now, there might be linear many modules in $\mathcal{C}(M^{\star}_{i})$ which have to be merged at once to create $M^{\star}_{i}$. However, from an algorithmic point of view the module $M^{\star}_{i}$ is not known in advance. Hence, in each step, for a given prime module $M$ of $G$ an editing algorithm has to choose one of the exponentially many sets from the power set $\mathcal{P}(\operatorname{\mathbb{P_{\max}}}{G[M]})$ to determine which new module $M^{\star}_{i}$ have to be created. For an algorithmic approach, however, it would be more convenient to only merge modules in a pairwise manner, since then only quadratic many combinations of choosing two elements of $\operatorname{\mathbb{P_{\max}}}{G[M]}$ have to be considered in each step.

The aim of this section is to show that for each of the $n$ steps of creating one of the new strong modules $\mathcal{M}=\{M^{\star}_{1},\dots,M^{\star}_{n}\}$ of $H$ it is possible to replace the merge operation \mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}_{M^{\prime}\in\mathcal{C}(M^{\star}_{i})}M^{\prime}\to M^{\star}_{i} with a series of pairwise merge operations.

Before we can state this result we have to define the following partition of strong modules of a resulting cograph $H$ that are no modules of a given graph $G$.

Definition 5.1**.**

Let $G=(V,E)$ be an arbitrary graph, $F$ a module-preserving cograph edit set, and $H=(V,E\bigtriangleup F)$ the resulting cograph. Moreover, let $M^{\star}\in\mathcal{M}$ be a strong module of $H$ that is no module of $G$ and consider the partitions $\operatorname{\mathbb{P_{\max}}}(H[M^{\star}])=\{\widetilde{M}_{1},\ldots,\widetilde{M}_{k}\}$ and $\mathcal{C}(M^{\star})=\{\widehat{M}_{1},\dots,\widehat{M}_{l}\}$. We define with $\mathcal{X}(M^{\star})=\{M_{0},\ldots,M_{n}\}$ the set of modules that contains the maximal (w.r.t. inclusion) modules of $\operatorname{\mathbb{P_{\max}}}(H[M^{\star}_{i}])\cup\mathcal{C}(M^{\star}_{i})$ as follows

[TABLE]

Note that for technical reasons the index of the elements in $\mathcal{X}$ starts with 0.

Furthermore, assume that $\mathcal{M}=\{M^{\star}_{1},\dots,M^{\star}_{n}\}$ is a partially ordered (w.r.t. inclusion) set of all strong modules of $H$ that are no modules of $G$. For each $M^{\star}_{i}\in\mathcal{M}$ let $\mathcal{X}(M^{\star}_{i})=\{M_{i,0},\ldots,M_{i,l_{i}}\}$ and set $M^{\star}_{i}(j)=\bigcup_{k=0}^{j}M_{i,k}$ for all $1\leq i\leq n$ and $1\leq j\leq l_{i}$. Then, we denote with

[TABLE]

the set of all such $M^{\star}_{i}(j)$. In particular, we assume that $\mathcal{N}(\mathcal{M})$ is ordered as follows: if $N^{\star}_{k}=M^{\star}_{i}(j)$ and $N^{\star}_{l}=M^{\star}_{i^{\prime}}(j^{\prime})$, then $k<l$ if and only if either $i<i^{\prime}$, or $i=i^{\prime}$ and $j<j^{\prime}$, i.e., within $\mathcal{N}(\mathcal{M})$ the elements $M^{\star}_{i}(j)$ are ordered first w.r.t. $i$, and second w.r.t. $j$.

Although, we have already shown by Theorem 4.2 that any new strong module $M^{\star}\in\mathcal{M}$ of $H$ can be obtained by merging the modules from $\mathcal{C}(M^{\star})$, we will see in the following that $M^{\star}$ can also be obtained by merging the modules form $\mathcal{X}(M^{\star})$. In particular, we will see that if all elements in $\mathcal{X}(M^{\star})$ are already modules of the intermediate graph $G^{\star}$, then we can use any order of the elements within $\mathcal{X}(M^{\star})$ and successively merge them in a pairwise manner to construct $M^{\star}$. As a consequence of doing pairwise module merges we obtain in each step an intermediate module $N^{\star}\in\mathcal{N}(\mathcal{M})$.

To see the intention to use the partition $\mathcal{X}(M^{\star})$ instead of $\mathcal{C}(M^{\star})$ observe the following. Due to the order of the elements in $\mathcal{M}$, the modules $M^{\star}_{1},\dots,M^{\star}_{n}$ are constructed from bottom to top, i.e., when module $M^{\star}$ is processed then all child modules from $\operatorname{\mathbb{P_{\max}}}(H[M^{\star}])$ are already constructed. So, instead of obtaining $M^{\star}$ by merging $\mathcal{C}(M^{\star})$ we can indeed obtain $M^{\star}$ also by merging $\operatorname{\mathbb{P_{\max}}}(H[M^{\star}])$. However, it might be the case that a non-trivial subset $\bigcup_{i\in I}\widetilde{M}_{i}=\widehat{M}_{j}$ for some $j$, e.g., if $\widehat{M}_{j}$ is a (strong) prime module of $G$ but not a strong module of $H$. But also in this case, we have to assure that $\widehat{M}_{j}$ remains a module of $H$. In particular, we do not want to destroy $\widehat{M}_{j}$ by merging the elements from $\operatorname{\mathbb{P_{\max}}}(H[M^{\star}])$ in the incorrect order. Thus, we choose $\widehat{M}_{j}\in\mathcal{X}(M^{\star})$ and do not include the individual $\widetilde{M}_{i},i\in I$ into $\mathcal{X}(M^{\star})$.

Before we can continue, we have to show that $\mathcal{X}(M^{\star})$ as given in Definition 5.1 is indeed a partition of $M^{\star}$.

Proposition 5.3**.**

Let $G=(V,E)$ be an arbitrary graph, $F$ a module-preserving cograph edit set, and $H=(V,E\bigtriangleup F)$ the resulting cograph. Moreover, let $M^{\star}$ be a strong module of $H$ that is no module of $G$ and consider the partitions $\operatorname{\mathbb{P_{\max}}}(H[M^{\star}])=\{\widetilde{M}_{1},\ldots,\widetilde{M}_{k}\}$ and $\mathcal{C}(M^{\star})=\{\widehat{M}_{1},\dots,\widehat{M}_{l}\}$. Then $\mathcal{X}(M^{\star})$ is a partition of $M^{\star}$. As a consequence, for each $M\in\mathcal{X}(M^{\star})$ there are index sets $I\subseteq\{1,\ldots,k\}$ and $J\subseteq\{1,\ldots,l\}$ such that $M=\bigcup_{i\in I}\widetilde{M}_{i}$ and $M=\bigcup_{j\in J}\widehat{M}_{j}$.

Proof.

First note that all $\widetilde{M}_{i}\in\operatorname{\mathbb{P_{\max}}}(H[M^{\star}])$ are strong modules of $H$. Moreover, all $\widehat{M}_{j}\in\mathcal{C}(M^{\star})$ are strong modules of $G$. Since $F$ is module-preserving it follows that none of the elements $\widetilde{M}_{i}\in\operatorname{\mathbb{P_{\max}}}(H[M^{\star}])$ overlap any $\widehat{M}_{j}\in\mathcal{C}(M^{\star})$, and vice versa. Hence, for each $\widetilde{M}_{i}\in\operatorname{\mathbb{P_{\max}}}(H[M^{\star}])$ there are three distinct cases: Either $\widetilde{M}_{i}\subseteq\widehat{M}_{j}$, or $\widehat{M}_{j}\subsetneq\widetilde{M}_{i}$, or $\widetilde{M}_{i}\cap\widehat{M}_{j}=\emptyset$ for all $\widehat{M}_{j}\in\mathcal{C}(M^{\star})$. Now, since $\operatorname{\mathbb{P_{\max}}}(H[M^{\star}])$ and $\mathcal{C}(M^{\star})$ are partitions of $M^{\star}$ it follows for each $x\in M^{\star}$ that $x$ is contained in exactly one $\widetilde{M}_{i}\in\operatorname{\mathbb{P_{\max}}}(H[M^{\star}])$ and exactly one $\widehat{M}_{j}\in\mathcal{C}(M^{\star})$ and either $\widetilde{M}_{i}\subseteq\widehat{M}_{j}$ or $\widehat{M}_{j}\subsetneq\widetilde{M}_{i}$. By construction of $\mathcal{X}(M^{\star})$ then either $\widetilde{M}_{i}=\widehat{M}_{j}\in\mathcal{X}(M^{\star})$; or $\widetilde{M}_{i}\in\mathcal{X}(M^{\star})$ and $\widehat{M}_{j}\not\in\mathcal{X}(M^{\star})$; or $\widetilde{M}_{i}\not\in\mathcal{X}(M^{\star})$ and $\widehat{M}_{j}\in\mathcal{X}(M^{\star})$. Thus, $\mathcal{X}(M^{\star})$ is a partition of $M^{\star}$. ∎

Using the partitions $\mathcal{X}(M^{\star}),M^{\star}\in\mathcal{M}$ we now show that there is a sequence of pairwise module merge operations that construct the intermediate modules $N^{\star}_{j}\in\mathcal{N}(\mathcal{M})$ while keeping all modules from $G$ as well as all previous modules $N^{\star}_{i},i<j$.

Lemma 5.4**.**

Let $G=(V,E)$ be an arbitrary graph, $F$ an optimal module-preserving cograph edit set, $H=(V,E\bigtriangleup F)$ the resulting cograph and $\mathcal{M}=\{M^{\star}_{1},\dots,M^{\star}_{n}\}$ be the partially ordered (w.r.t. inclusion) set of all strong modules of $H$ that are no modules of $G$.

For each $M^{\star}_{i}\in\mathcal{M}$ let $\mathcal{X}(M^{\star}_{i})=\{M_{i,0},\ldots,M_{i,l_{i}}\}$ and assume that $\mathcal{N}\coloneqq\mathcal{N}(\mathcal{M})=\{N^{\star}_{1},\ldots,N^{\star}_{m}\}$. Note, each $N^{\star}_{l}$ coincides with some $M^{\star}_{i}(j)=\bigcup_{k=0}^{j}M_{i,k}$. We define $F_{M^{\star}_{i}(j)}\subseteq F$ as the set

[TABLE]

Furthermore, set $G^{\prime}_{0}=G$ and for each $1\leq l\leq m$ define $G^{\prime}_{l}=G^{\prime}_{l-1}\bigtriangleup\theta_{l}$ with

[TABLE]

If $N^{\star}_{l}$ is no module of $G^{\prime}_{l-1}$, then $\theta_{l}$ contains exactly those edits that affect the out-neighborhood of $N^{\star}_{l}=M^{\star}_{i}(j)$ within $G[P_{M^{\star}_{i}}]$ that have not been used so far.

The following statements are true for the intermediate graphs $G^{\prime}_{l}$, $1\leq l\leq m$:

Any set $N^{\star}_{k}$ is a module of $G^{\prime}_{l}$ for all $k\leq l$. 2. 2.

Any module $M^{\prime}$ of $G$ is a module of $G^{\prime}_{l}$, i.e., $\bigcup_{k=1}^{l}\theta_{k}$ is module-preserving. 3. 3.

Either $G^{\prime}_{l-1}\simeq G^{\prime}_{l}$, or there are two modules $M_{1},M_{2}\in G^{\prime}_{l-1}$ such that M_{1}\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}M_{2}\to N^{\star}_{l} is a pairwise module merge w.r.t. $G^{\prime}_{l}$.

Proof.

Before we start to prove the statements, we will first show

Claim 1:

For each $1\leq l\leq m$ it holds that $N^{\star}_{l}$ is a module of $H$.

By construction $N^{\star}_{l}=M^{\star}_{i}(j)=\bigcup_{k=0}^{j}M_{i,k}$ for some $1\leq i\leq n$ and $1\leq j\leq l_{i}$ with $M_{i,k}\in\mathcal{X}(M^{\star}_{i})$. Moreover, for each $M_{i,k}$ it holds either that $M_{i,k}\in\operatorname{\mathbb{P_{\max}}}{H[M^{\star}_{i}]}$ or $M_{i,k}$ is a union of elements in $\operatorname{\mathbb{P_{\max}}}{H[M^{\star}_{i}]}$. Therefore, $N^{\star}_{l}$ is a union of elements in $\operatorname{\mathbb{P_{\max}}}{H[M^{\star}_{i}]}$. Since $M^{\star}_{i}$ is a strong non-prime module of $H$, Theorem 3.3(T3) implies that each union of elements in $\operatorname{\mathbb{P_{\max}}}{H[M^{\star}_{i}]}$ is a module of $H$ and therefore, $N^{\star}_{l}$ is a module of $H$, which proves Claim 1.

We proceed to prove Statements 1 and 2 for each intermediate graph $G^{\prime}_{l}$ by induction over $l$. Since $G^{\prime}_{0}=G$, the Statements 1 and 2 are satisfied for $G^{\prime}_{0}$. We continue to show that Statements 1 and 2 are satisfied for $G^{\prime}_{l+1}$ under the assumption that they are satisfied for $G_{l}$.

We start to prove Statement 1. First assume that $N^{\star}_{l+1}$ is already a module of $G^{\prime}_{l}$. Then, by construction it holds that $\theta_{l+1}=\emptyset$ and therefore, $G^{\prime}_{l}=G^{\prime}_{l+1}$. Now, by induction assumption, it holds that all modules of $G$ and all modules $N^{\star}_{k}\in\mathcal{N}$, $k\leq l$ are modules of $G^{\prime}_{l}=G^{\prime}_{l+1}$. Hence, all modules $N^{\star}_{k}\in\mathcal{N}$, $k\leq l+1$ are modules of $G^{\prime}_{l+1}$. Hence, if $N^{\star}_{l+1}$ is already a module of $G^{\prime}_{l}$, then Statement 1 is satisfied for $G^{\prime}_{l+1}$.

Now assume that $N^{\star}_{l+1}$ is not a module of $G^{\prime}_{l}$. For the proof of Statement 1, we show first

Claim 2:

$N^{\star}_{l+1}$ is a module of $G^{\prime}_{l+1}$.

By construction it holds that $N^{\star}_{l+1}=M^{\star}_{i}(j)$ for some $1\leq i\leq n$ and $1\leq j\leq l_{i}$. Note that $P_{M^{\star}_{i}}$ is a module of $G$ and therefore, by induction assumption it is a module of $G^{\prime}_{l}$. Since $\theta_{l+1}\subseteq F_{M^{\star}_{i}(j)}$ did only affect the out${}_{M^{\star}_{i}(j)}$-neighborhood within the prime module $P_{M^{\star}_{i}}$ of $G$ it follows that $P_{M^{\star}_{i}}$ is a module of $G^{\prime}_{l+1}$. Moreover, it holds that $F_{M^{\star}_{i}(j)}\subseteq\bigcup_{k=1}^{l+1}\theta_{k}$. Note that $F_{M^{\star}_{i}(j)}$ contains all those edits that affect the out${}_{M^{\star}_{i}(j)}$-neighborhood within the prime module $P_{M^{\star}_{i}}$ of $G$. Hence, for all $x\in M^{\star}_{i}(j)$ and all $y\in P_{M^{\star}_{i}}\setminus M^{\star}_{i}(j)$ it holds that $xy\in E(H)$ if and only if $xy\in E(G^{\prime}_{l+1})$. The latter arguments then imply that $M^{\star}_{i}(j)$ is a module of $G^{\prime}_{l+1}$ and therefore, $N^{\star}_{l+1}$ is a module of $G^{\prime}_{l+1}$. This proves Claim 2.

Now, we proceed with showing

Claim 3:

$N^{\star}_{k}$, $k\leq l$ is a module of $G^{\prime}_{l+1}$.

Let $N^{\star}_{k}=M^{\star}_{i^{\prime}}(j^{\prime})$ and $N^{\star}_{l+1}=M^{\star}_{i}(j)$. By induction assumption it holds that $N^{\star}_{k}$ is a module of $G^{\prime}_{l}$. By the ordering of elements in $\mathcal{N}$ it holds that $i^{\prime}\leq i$ and by the ordering of elements in $\mathcal{M}$ it then follows that $P_{M^{\star}_{i^{\prime}}}\subseteq P_{M^{\star}_{i}}$ or $P_{M^{\star}_{i^{\prime}}}\cap P_{M^{\star}_{i}}=\emptyset$.

If $P_{M^{\star}_{i^{\prime}}}\cap P_{M^{\star}_{i}}=\emptyset$ then $N^{\star}_{k}$ is not affected by the edits in $\theta_{l+1}$ since they are all within $P_{M^{\star}_{i}}$ and thus, $N^{\star}_{k}$ remains a module of $G^{\prime}_{l+1}$.

Now consider the case $P_{M^{\star}_{i^{\prime}}}\subseteq P_{M^{\star}_{i}}$. For later reference, we show

Claim 3’:

$N^{\star}_{k}\subseteq N^{\star}_{l+1}$ or $N^{\star}_{k}\cap N^{\star}_{l+1}=\emptyset$.

If $i^{\prime}=i$, then $j^{\prime}<j$ and by construction, $M^{\star}_{i^{\prime}}(j^{\prime})\subseteq M^{\star}_{i}(j)$ which implies that $N^{\star}_{k}\subseteq N^{\star}_{l+1}$. Assume now that $i^{\prime}<i$ and thus, $N^{\star}_{k}=M^{\star}_{i^{\prime}}(j^{\prime})\subseteq M^{\star}_{i^{\prime}}$. Since $M^{\star}_{i}$ and $M^{\star}_{i^{\prime}}$ are strong modules of $H$ they cannot overlap. Therefore, and due to the ordering of the elements in $\mathcal{M}$ it follows that either $M^{\star}_{i^{\prime}}\subset M^{\star}_{i}$ or $M^{\star}_{i^{\prime}}\cap M^{\star}_{i}=\emptyset$. If $M^{\star}_{i^{\prime}}\cap M^{\star}_{i}=\emptyset$, then $N^{\star}_{k}\cap N^{\star}_{l+1}=\emptyset$. If $M^{\star}_{i^{\prime}}\subset M^{\star}_{i}$, then there is a module $M^{\prime}\in\operatorname{\mathbb{P_{\max}}}(H[M^{\star}_{i}])$ such that $M^{\star}_{i^{\prime}}\in M^{\prime}$, since $M^{\star}_{i}$ and $M^{\star}_{i^{\prime}}$ are strong modules of $H$. Furthermore, the set $M^{\star}_{i}(j)$ is a union of elements in $\mathcal{X}(M^{\star}_{i})$ and for each $M_{i,h}\in\mathcal{X}(M^{\star}_{i})$ it holds that either $M_{i,h}\in\operatorname{\mathbb{P_{\max}}}(H[M^{\star}_{i}])$ or $M_{i,h}$ is the union of elements in $\operatorname{\mathbb{P_{\max}}}(H[M^{\star}_{i}])$. Hence, it follows that either $M^{\prime}\subseteq M^{\star}_{i}(j)$ or $M^{\prime}\cap M^{\star}_{i}(j)=\emptyset$. If $M^{\prime}\cap M^{\star}_{i}(j)=\emptyset$, then $M^{\star}_{i^{\prime}}(j^{\prime})\cap M^{\star}_{i}(j)=\emptyset$ and hence, $N^{\star}_{k}\cap N^{\star}_{l+1}=\emptyset$. If, on the other hand, $M^{\prime}\subseteq M^{\star}_{i}(j)$, then $M^{\star}_{i^{\prime}}(j^{\prime})\subseteq M^{\star}_{i}(j)$ and thus, $N^{\star}_{k}\subseteq N^{\star}_{l+1}$. Therefore, in all cases we have either $N^{\star}_{k}\subseteq N^{\star}_{l+1}$ or $N^{\star}_{k}\cap N^{\star}_{l+1}=\emptyset$, which proves Claim 3’.

By Claim 3’, we are left with the following two cases.

Case $N^{\star}_{k}\subseteq N^{\star}_{l+1}$.

Since $\theta_{l+1}$ did not effect edges within $N^{\star}_{l+1}$ it holds that $G^{\prime}_{l}[N^{\star}_{l+1}]\simeq G^{\prime}_{l+1}[N^{\star}_{l+1}]$. By induction assumption, $N^{\star}_{k}$ is a module of $G^{\prime}_{l}$ and hence, of $G^{\prime}_{l}[N^{\star}_{l+1}]=G^{\prime}_{l}[M^{\star}_{i}(j)]$. Thus, $N^{\star}_{k}$ is a module of $G^{\prime}_{l+1}[M^{\star}_{i}(j)]$. Now, since $N^{\star}_{l+1}$ is a module of $G^{\prime}_{l+1}$ and by Lemma 3.1 it follows that $N^{\star}_{k}$ is a module of $G^{\prime}_{l+1}$.

Case $N^{\star}_{k}\cap N^{\star}_{l+1}=\emptyset$.

Recall that $N^{\star}_{k}=M^{\star}_{i^{\prime}}(j^{\prime})$ and $N^{\star}_{l+1}=M^{\star}_{i}(j)$ by the fact that $i^{\prime}\leq i$. Moreover, as shown in the proof of Claim 2, we have $F_{M^{\star}_{i}(j)}\subseteq\bigcup_{k=1}^{l+1}\theta_{k}$. Therefore, for all $x\in M^{\star}_{i}(j)$ and all $y\in M^{\star}_{i^{\prime}}(j^{\prime})$ it holds that $xy\in E(H)$ if and only if $xy\in E(G^{\prime}_{l+1})$. Now let $y,y^{\prime}\in M^{\star}_{i^{\prime}}(j^{\prime})$ and $x\not\in\setminus M^{\star}_{i^{\prime}}(j^{\prime})$. Since $M^{\star}_{i^{\prime}}(j^{\prime})$ is a module of $H$, $xy$ as well as $xy^{\prime}$ are either both edges $H$ or both are non-edges in $H$.

If $x\in M^{\star}_{i}(j)$, then there are no further edits $F\setminus F_{M^{\star}_{i}(j)}$ that may affect any of these edges, since $F_{M^{\star}_{i}(j)}\subseteq\bigcup_{k=1}^{l+1}\theta_{k}$. Thus, $xy\in E(G^{\prime}_{l+1})$ if and only if $xy^{\prime}\in E(G^{\prime}_{l+1})$.

If $x\not\in M^{\star}_{i}(j)$, then $xy$ as well as $xy^{\prime}$ are not affected by $\theta_{l+1}$. Hence, $xy^{\prime}\in E(G^{\prime}_{l+1})$ if and only if $xy^{\prime}\in E(G^{\prime}_{l})$. By induction assumption, $M^{\star}_{i^{\prime}}(j^{\prime})$ is a module of $G^{\prime}_{l}$ and hence, $xy\in E(G^{\prime}_{l})$ if and only if $xy^{\prime}\in E(G^{\prime}_{l})$ and therefore, $xy\in E(G^{\prime}_{l+1})$ if and only if $xy^{\prime}\in E(G^{\prime}_{l+1})$. Hence, $N^{\star}_{k}=M^{\star}_{i^{\prime}}(j^{\prime})$ is a module of $G^{\prime}_{l+1}$, which proves Claim 3.

By Claim 1, 2 and 3, Statement 1 is satisfied for $G^{\prime}_{l+1}$. We continue to prove Statement 2 and assume that $M^{\prime}$ is a module of $G$ and by induction assumption $M^{\prime}$ is a module of $G^{\prime}_{l}$.

Again, let $N^{\star}_{l+1}=M^{\star}_{i}(j)$ and consider the module $P_{M^{\star}_{i}}$ of $G$. Since $P_{M^{\star}_{i}}$ is strong in $G$, it cannot overlap $M^{\prime}$. Thus, either $M^{\prime}\cap P_{M^{\star}_{i}}=\emptyset$, or $P_{M^{\star}_{i}}\subseteq M^{\prime}$, or $M^{\prime}\subset P_{M^{\star}_{i}}$.

If $M^{\prime}\cap P_{M^{\star}_{i}}=\emptyset$ or $P_{M^{\star}_{i}}\subseteq M^{\prime}$ then $M^{\prime}$ is not affected by the edits in $\theta_{l+1}$ since they are all within $P_{M^{\star}_{i}}$ and thus, $M^{\prime}$ remains a module of $G^{\prime}_{l+1}$.

Hence, we only have to consider the case $M^{\prime}\subset P_{M^{\star}_{i}}$. We show

Claim 4:

Either $M^{\prime}\subseteq N^{\star}_{l+1}$ or $M^{\prime}\cap N^{\star}_{l+1}=\emptyset$.

Note again, that the set $M^{\star}_{i}(j)$ is a union of elements in $\mathcal{X}(M^{\star}_{i})$ and for each $M_{i,h}\in\mathcal{X}(M^{\star}_{i})$ it holds that either $M_{i,h}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}_{i}}])$ or $M_{i,h}$ is the union of elements in $\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}_{i}}])$. Hence, $M^{\star}_{i}(j)$ is a union of elements in $\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}_{i}}])$. Theorem 3.3(T2) implies that no union of elements in $\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}_{i}}])$ of the prime module $P_{M^{\star}_{i}}$ is a module of $G$ and thus, $M^{\star}_{i}(j)$ cannot be a proper subset of $M^{\prime}$. Therefore, either $M^{\prime}\subseteq M^{\star}_{i}(j)$ or $M^{\prime}\cap M^{\star}_{i}(j)=\emptyset$ or $M^{\prime}$ and $M^{\star}_{i}(j)$ overlap. However, the latter case cannot occur, since then $M^{\prime}$ would either overlap one of the strong modules in $\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}_{i}}])$ or be a union of elements in $\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}_{i}}])$. Thus, in all cases either $M^{\prime}\subseteq N^{\star}_{l+1}$ or $M^{\prime}\cap N^{\star}_{l+1}=\emptyset$, which proves Claim 4.

Now the same argumentation that was used to show Statement 1 can be used to show Statement 2. Thus, Statement 2 is satisfied for $G^{\prime}_{l+1}$.

Finally, we prove Statement 3. To this end, assume that $G^{\prime}_{l}\not\simeq G^{\prime}_{l+1}$ and that $N^{\star}_{l+1}$ is no module of $G^{\prime}_{l}$. We show that there are modules $M_{1},M_{2}\in G^{\prime}_{l}$ with M_{1}\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}M_{2}\to N^{\star}_{l+1} being a pairwise module merge w.r.t. $G^{\prime}_{l+1}$. Clearly, Items (ii) and (iii) of Def. 4.1 are satisfied, since $N^{\star}_{l+1}$ is a module of $G^{\prime}_{l+1}$ but no module of $G^{\prime}_{l}$. It remains to show that there are two modules $M_{1},M_{2}\in G^{\prime}_{l}$ with $M_{1}\cup M_{2}=N^{\star}_{l+1}$ and $M_{1},M_{2}\in G^{\prime}_{l+1}$, i.e., Item (i) of Def. 4.1 is satisfied. Note, $N^{\star}_{l+1}=M^{\star}_{i}(j)$ for some $i$ and $j\geq 1$. Assume first that $j=1$. Then, $M^{\star}_{i}(1)=M_{i,0}\cup M_{i,1}$ with $M_{i,0},M_{i,1}\in\mathcal{X}(M^{\star}_{i})$. For each $M_{i,h}$ it holds that $M_{i,h}\in\operatorname{\mathbb{P_{\max}}}(H[P_{M^{\star}_{i}}])$ or $M_{i,h}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}_{i}}])$. If $M_{i,h}\in\operatorname{\mathbb{P_{\max}}}(G[P_{M^{\star}_{i}}])$ then $M_{i,h}$ is a module of $G$ and by Statement 2, a module of $G^{\prime}_{l}$ and $G^{\prime}_{l+1}$. If $M_{i,h}$ is no module of $G$, then $M_{i,h}\in\operatorname{\mathbb{P_{\max}}}(H[P_{M^{\star}_{i}}])$ is a new strong module of $H$. Therefore, there exists a $k<i$ such that $M_{i,h}=M^{\star}_{k}$. Since $M^{\star}_{k}=M^{\star}_{k}(l_{k})$ and by the ordering of elements in $\mathcal{N}$ it holds that $M^{\star}_{k}(l_{k})=N^{\star}_{k^{\prime}}$ for some $k^{\prime}\leq l$. Thus, by Statement 1, all $M_{i,h}$ and therefore, $M_{i,0}$ and $M_{i,1}$ are modules of $G^{\prime}_{l}$ and $G^{\prime}_{l+1}$.

Now, assume that $N^{\star}_{l+1}=M^{\star}_{i}(j)$ with $j>1$. Then, $M^{\star}_{i}(j)=M^{\star}_{i}(j-1)\cup M_{i,j}$. By the same argumentation as before, it holds that $M_{i,j}$ is a module of $G^{\prime}_{l}$ and $G^{\prime}_{l+1}$. Moreover, by Statement 1, $M^{\star}_{i}(j-1)=N^{\star}_{l}$ is a module of $G^{\prime}_{l}$ and $G^{\prime}_{l+1}$.

Thus, there are modules $M_{1},M_{2}$ of $G^{\prime}_{l}$ and $G^{\prime}_{l+1}$ with $M_{1}\cup M_{2}=N^{\star}_{l+1}$. Moreover, since for all $\{x,y\}\in\theta_{l+1}$ it holds that either $x\in N^{\star}_{l+1}$ and $y\in P_{M^{\star}_{i}}\setminus N^{\star}_{l+1}$, or vice versa, it follows that there are no additional edits contained in $\theta_{l+1}$ besides the edits of the module merge M_{1}\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}M_{2}\to N^{\star}_{l+1} that transforms $G^{\prime}_{l}$ into $G^{\prime}_{l+1}$. ∎

We are now in the position to derive the main result of this section that shows that optimal pairwise module-merge is always possible.

Theorem 5.5** (Pairwise Module-Merge).**

For an arbitrary graph $G=(V,E)$ and an optimal module-preserving cograph edit set $F$ with $H=(V,E\bigtriangleup F)$ being the resulting cograph there exists a sequence of pairwise module merge operations that transforms $G$ into $H$.

Proof.

Set $\mathcal{M}=\{M^{\star}_{1},\ldots,M^{\star}_{n}\}$, $\mathcal{N}=\{N^{\star}_{1},\ldots,N^{\star}_{m}\}$, $\mathcal{X}(M^{\star}_{i})=\{M_{i,0},\ldots,M_{i,l_{i}}\}$, as well as $\theta_{k}$ and $G^{\prime}_{k}$ for all $1\leq k\leq m$ as in Lemma 5.4. Again, we set $G_{0}\coloneqq G$ and $H^{\prime}\coloneqq G_{m}$. By Lemma 5.4 for each $1\leq k\leq m$ there is a pairwise module merge M_{1}\mathbin{\mathchoice{\ooalign{\displaystyle\sqcup$\cr$\displaystyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\textstyle\sqcup$\cr$\textstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptstyle\sqcup$\cr$\scriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}{\ooalign{\scriptscriptstyle\sqcup$\cr$\scriptscriptstyle\mathchoice{\raisebox{1.4pt}{$\displaystyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\textstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptstyle\scriptscriptstyle{+}$}}{\raisebox{1.4pt}{$\scriptscriptstyle\scriptscriptstyle{+}$}}}}}M_{2}\to N^{\star}_{k} that transforms $G_{k-1}$ to $G_{k}$. Thus, there exists a sequence of module merge operations that transforms $G$ to some graph $H^{\prime}$.

In what follows, we will show that \mathop{\vphantom{\bigcup}\mathchoice{\ooalign{\displaystyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\displaystyle\cdot}}}}{\ooalign{\textstyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\textstyle\cdot}}}}{\ooalign{\scriptstyle\bigcup\cr\raise-6.61116pt\hbox{\scalebox{2.0}{\scriptstyle\cdot}}}}{\ooalign{\scriptscriptstyle\bigcup\cr\raise-4.72224pt\hbox{\scalebox{2.0}{\scriptscriptstyle\cdot}}}}}_{k=1}^{m}\theta_{k}=F and therefore $H^{\prime}\simeq H$, from which we can conclude the statement. For simplicity, we put $F^{\prime}\coloneqq\bigcup_{k=1}^{m}\theta_{k}$.

We start with showing

Claim 1:

$F^{\prime}\subseteq F$.

Note first that by construction it holds that $\theta_{k}\cap\theta_{l}=\emptyset$ for all $k\neq l$ and therefore, F^{\prime}=\bigcup_{k=1}^{m}\theta_{k}=\mathop{\vphantom{\bigcup}\mathchoice{\ooalign{\displaystyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\displaystyle\cdot}}}}{\ooalign{\textstyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\textstyle\cdot}}}}{\ooalign{\scriptstyle\bigcup\cr\raise-6.61116pt\hbox{\scalebox{2.0}{\scriptstyle\cdot}}}}{\ooalign{\scriptscriptstyle\bigcup\cr\raise-4.72224pt\hbox{\scalebox{2.0}{\scriptscriptstyle\cdot}}}}}_{k=1}^{m}\theta_{k}. By construction of $\theta$ it holds that $\theta_{k}\subseteq F$ for all $1\leq k\leq m$. Hence, $F^{\prime}\subseteq F$.

Before we show that $F=F^{\prime}$, we will prove

Claim 2:

All strong modules of $H$ are modules of $H^{\prime}$.

Lemma 5.4(1) implies that all modules $M^{\prime}$ of $G$ are modules of $H^{\prime}$. Moreover, Lemma 5.4(2) implies that all $N^{\star}_{k}\in\mathcal{N}$ are modules of $H^{\prime}$. Since for all $M^{\star}_{i}\in\mathcal{M}$ it holds that $M^{\star}_{i}=M^{\star}_{i}(l_{i})=N^{\star}_{k}$ for some $1\leq k\leq m$, the set $M^{\star}_{i}$ is a module of $H^{\prime}$. Since each strong module of $H$ is either a module of $G$ or a new module $M^{\star}_{i}\in\mathcal{M}$, all strong modules of $H$ are modules of $H^{\prime}$.

We continue to show

Claim 3:

$F^{\prime}\subsetneq F$ is not possible.

By Claim 1, $F^{\prime}\subseteq F$. Thus assume for contradiction that $F^{\prime}\neq F$. Since $F$ is an optimal edit set and $F^{\prime}\subsetneq F$ it follows that $H^{\prime}$ is not a cograph. Thus, there exist a prime module $M$ in $H^{\prime}$ that contains no other prime module.

We will now show that $M$ is a module of $H$ and that all $M_{i}\in\operatorname{\mathbb{P_{\max}}}(H[M])$ are modules of $H^{\prime}$. Therefore, consider the strong module $P_{M}$ of $H$ that entirely contains $M$ and that is minimal w.r.t. inclusion. Since $P_{M}$ is strong in $H$ it is, by Claim 2, also a module of $H^{\prime}$. Moreover, each module $M_{i}\in\operatorname{\mathbb{P_{\max}}}(H[P_{M}])$ is strong in $H$ and, again by Claim 2, a module of $H^{\prime}$ as well. If $P_{M}=M$, then $M$ is a module of $H$ and we are done. Assume now that $M\subsetneq P_{M}$. Note that since $M$ and all $M_{i}\in\operatorname{\mathbb{P_{\max}}}(H[P_{M}])$ are modules of $H^{\prime}$ and $M$ is strong in $H^{\prime}$ it holds that $M$ does not overlap any $M_{i}\in\operatorname{\mathbb{P_{\max}}}(H[P_{M}])$. Moreover, $M\not\subseteq M_{i}$ since otherwise $M_{i}$ would have been chosen instead of $P_{M}$. Thus, $M=\bigcup_{i\in I}M_{i}$ is the union of some elements $M_{i}$ in $\operatorname{\mathbb{P_{\max}}}(H[P_{M}])$. Since $P_{M}$ is a non-prime module of $H$ it follows by Theorem 3.3(T3) that $M$ is a module of $H$. Since $H$ is a cograph, the children $M_{i}\in\operatorname{\mathbb{P_{\max}}}(H[P_{M}])$ of the non-prime module $P_{M}$ are the connected components of either $H[P_{M}]$ (if $P_{M}$ is parallel) or its complement $\overline{H[P_{M}]}$ (if $P_{M}$ is series). Since $M=\bigcup_{i\in I}M_{i}$ is the union of some elements in $\operatorname{\mathbb{P_{\max}}}(H[P_{M}])$ and $H[M]\subseteq H[P_{M}]$, we can conclude that $H[M]$, resp.  its complement $\overline{H[M]}$, has as its connected components $M_{i}$, $i\in I$. Thus, $\operatorname{\mathbb{P_{\max}}}(H[M])\subset\operatorname{\mathbb{P_{\max}}}(H[P_{M}])$. Hence, all $M_{i}$, $i\in I$ are strong modules in $H$ and, by the discussion above, all $M_{i}$ are modules of $H^{\prime}$.

Since all $M_{i}\in\operatorname{\mathbb{P_{\max}}}(H[M])$ are modules of $H^{\prime}$ and all $M^{\prime}_{j}\in\operatorname{\mathbb{P_{\max}}}(H^{\prime}[M])$ are strong in $H^{\prime}$, it holds that no $M_{i}\in\operatorname{\mathbb{P_{\max}}}(H[M])$ can overlap any $M^{\prime}_{j}\in\operatorname{\mathbb{P_{\max}}}(H^{\prime}[M])$. Therefore, if $M_{i}\cap M^{\prime}_{j}\neq\emptyset$ then either $M^{\prime}_{j}\subsetneq M_{i}$ or $M_{i}\subseteq M^{\prime}_{j}$ for any $i$ and $j$. If $M^{\prime}_{j}\subsetneq M_{i}$ then $M_{i}$ must be the union of some elements in $\operatorname{\mathbb{P_{\max}}}(H^{\prime}[M])$. However, since $M$ is prime in $H^{\prime}$ no union of elements in $\operatorname{\mathbb{P_{\max}}}(H^{\prime}[M])$, besides $M$ itself, is a module of $H^{\prime}$ (cf. Theorem 3.3(T2)). Thus, $M_{i}$ cannot be a module of $H^{\prime}$; a contradiction. Hence, $M_{i}\subseteq M^{\prime}_{j}$ and therefore, each $M^{\prime}_{j}$ is the union of some elements in $\operatorname{\mathbb{P_{\max}}}(H[M])$. Note that this holds for any $M^{\prime}_{j}\in\operatorname{\mathbb{P_{\max}}}(H^{\prime}[M])$, i.e., there are distinct sets $I_{1},\ldots,I_{|\operatorname{\mathbb{P_{\max}}}(H^{\prime}[M])|}$ with $I_{j}\subsetneq\{1,\ldots,|\operatorname{\mathbb{P_{\max}}}(H[M])|\}$ such that $M^{\prime}_{j}=\bigcup_{i\in I_{j}}M_{i}$. Hence, all $M^{\prime}_{j}$ are modules of $H$.

Since, $M$ is prime in $H^{\prime}$ and $M$ did not contain any other prime module, it holds that all $H^{\prime}[M^{\prime}_{j}]$ are cographs. Moreover, since all $M^{\prime}_{j}$ are modules in $H$ and $M$ is prime in $H^{\prime}$ it holds that there are at least two distinct $M^{\prime}_{k},M^{\prime}_{l}\in\operatorname{\mathbb{P_{\max}}}(H^{\prime}[M])$ with $xy\in E(H^{\prime})$ if and only if $xy\not\in E(H)$. Thus, $F^{\prime\prime}=\{\{x,y\}\mid x\in M^{\prime}_{k},y\in M^{\prime}_{l}\}\subseteq F$. Now, since all $H^{\prime}[M^{\prime}_{j}]$ are cographs it holds that $H^{\prime}[M^{\prime}_{k}\cup M^{\prime}_{l}]$ is a cograph.

Now, consider the graph $H^{\prime\prime}=G\bigtriangleup F\setminus F^{\prime\prime}$, and in particular the subgraph $H^{\prime\prime}[M]=G[M]\bigtriangleup F[M]\setminus F^{\prime\prime}$. Again, since all $H^{\prime}[M^{\prime}_{j}]$ with $M^{\prime}_{j}\in\operatorname{\mathbb{P_{\max}}}(H^{\prime}[M])$ are cographs it holds that $H[M^{\prime}_{j}]\simeq H^{\prime}[M^{\prime}_{j}]\simeq H^{\prime\prime}[M^{\prime}_{j}]$. By construction of $F^{\prime\prime}$ for the previously chosen $M^{\prime}_{k}$ and $M^{\prime}_{l}$ it holds that $H^{\prime}[M^{\prime}_{k}\cup M^{\prime}_{l}]\simeq H^{\prime\prime}[M^{\prime}_{k}\cup M^{\prime}_{l}]$ as well as $H[M\setminus(M^{\prime}_{k}\cup M^{\prime}_{l})]\simeq H^{\prime\prime}[M\setminus(M^{\prime}_{k}\cup M^{\prime}_{l})]$ is a cograph. Moreover, since for all $x\in M^{\prime}_{k}\cup M^{\prime}_{l}$ and all $y\in M\setminus(M^{\prime}_{k}\cup M^{\prime}_{l})$ we have $xy\in E(H)$ if and only if $xy\in E(H^{\prime\prime})$ it holds that $H^{\prime\prime}[M]$ is a cograph as well. Note that $F^{\prime\prime}\subseteq F[M]$ and $F^{\prime\prime}\neq\emptyset$ and therefore, $|F[M]\setminus F^{\prime\prime}|<|F[M]|$. But then, since $F[M]\setminus F^{\prime\prime}$ is an edit set for $G[M]$ and by Lemma 3.7 the set $F$ is not optimal; a contradiction. Thus, $F^{\prime}$ cannot be a proper subset of $F$, which proves Claim 3.

Claim 1 and 3 immediately imply that $F=F^{\prime}$. In particular, we have F^{\prime}=\mathop{\vphantom{\bigcup}\mathchoice{\ooalign{\displaystyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\displaystyle\cdot}}}}{\ooalign{\textstyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\textstyle\cdot}}}}{\ooalign{\scriptstyle\bigcup\cr\raise-6.61116pt\hbox{\scalebox{2.0}{\scriptstyle\cdot}}}}{\ooalign{\scriptscriptstyle\bigcup\cr\raise-4.72224pt\hbox{\scalebox{2.0}{\scriptscriptstyle\cdot}}}}}_{i=1}^{n}\mathop{\vphantom{\bigcup}\mathchoice{\ooalign{\displaystyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\displaystyle\cdot}}}}{\ooalign{\textstyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\textstyle\cdot}}}}{\ooalign{\scriptstyle\bigcup\cr\raise-6.61116pt\hbox{\scalebox{2.0}{\scriptstyle\cdot}}}}{\ooalign{\scriptscriptstyle\bigcup\cr\raise-4.72224pt\hbox{\scalebox{2.0}{\scriptscriptstyle\cdot}}}}}_{j=1}^{l_{i}}\theta^{\prime}_{M^{\star}_{i}(j)}=\mathop{\vphantom{\bigcup}\mathchoice{\ooalign{\displaystyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\displaystyle\cdot}}}}{\ooalign{\textstyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\textstyle\cdot}}}}{\ooalign{\scriptstyle\bigcup\cr\raise-6.61116pt\hbox{\scalebox{2.0}{\scriptstyle\cdot}}}}{\ooalign{\scriptscriptstyle\bigcup\cr\raise-4.72224pt\hbox{\scalebox{2.0}{\scriptscriptstyle\cdot}}}}}_{i=1}^{n}\mathop{\vphantom{\bigcup}\mathchoice{\ooalign{\displaystyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\displaystyle\cdot}}}}{\ooalign{\textstyle\bigcup\cr\raise-9.4445pt\hbox{\scalebox{2.0}{\textstyle\cdot}}}}{\ooalign{\scriptstyle\bigcup\cr\raise-6.61116pt\hbox{\scalebox{2.0}{\scriptstyle\cdot}}}}{\ooalign{\scriptscriptstyle\bigcup\cr\raise-4.72224pt\hbox{\scalebox{2.0}{\scriptscriptstyle\cdot}}}}}_{j=1}^{l_{i}}\theta_{M^{\star}_{i}(j)}=F. ∎

It can easily be seen by the latter results that each of the modules in $\mathcal{N}(\mathcal{M})=\{N^{\star}_{1},\ldots,N^{\star}_{m}\}$ that is created by a pairwise module merge is either already a module of $G$, or a union of elements from $\operatorname{\mathbb{P_{\max}}}(G[M])$ of some prime module $M$ of $G$.

5.2 A modular-decomposition-based Heuristic for Cograph Editing

Although the (decision version of the) optimal cograph-editing problem is NP-complete [38, 39], it is fixed-parameter tractable (FPT) [49, 6, 39]. However, the best-known run-time for an FPT-algorithm is $\mathcal{O}(4.612^{k}+|V|^{4.5})$, where the parameter $k$ denotes the number of edits. These results are of little use for practical applications, because the parameter $k$ can become quite large. An exact algorithm that runs in $O(3^{|V|}|V|)$-time is introduced in [53]. Moreover, approximation algorithms are described in [46, 16]. In the following we provide an alternative exact algorithm for the cograph-editing problem based on pairwise module-merge. The virtue of this algorithm is that it can be adopted very easily to design a cograph-editing heuristic.

Algorithm 1 contains two points at which the choice of a particular module or a particular pair of modules affects performance and efficiency. First, the function get-module-pair() returns two modules of $\mathcal{P}$ in the correct order of the sequence of pairwise module merge operations that transforms $G$ into $H$ (cf. Theorem 5.5). Second, subroutine get-module-pair-edit() is used to compute the edits needed to merge the modules $M_{i}$ and $M_{j}$ to a new module such that these edits affect only the vertices within $P_{p}$ (cf. Lemma 5.4).

Lemma 5.6**.**

Let $\mathcal{P}(G)$ be the set of all strong prime modules of $G$ and suppose that Algorithm 1 is applied on the graph $G$ with $n=|V(G)|$. If get-module-pair() is an “oracle” that always returns the correct pair $M_{i}$ and $M_{j}$ and get-module-pair-edit() returns the correct edit set $\theta$, then Alg. 1 computes an optimally edited cograph $H$ in $O(m\Lambda h(G))\leq O(n^{2}h(G))$ time, where $m$ denotes the number of strong prime modules in $G$ and $\Lambda=\max_{P\in\mathcal{P}(G)}|\operatorname{\mathbb{P_{\max}}}(G[P])|$ is the size of the largest maximal strong partition among all prime modules $P\in\mathcal{P}(G)$, and $h(G)$ is the maximal cost for evaluating get-module-pair() and get-module-pair-edit().

Proof.

The correctness of Algorithm 1 follows directly from Lemma 5.4 and Theorem 5.5.

The modular decomposition tree of a graph $G=(V,E)$ can be computed in linear-time, i.e., $O(|V|+|E|)\leq O(n^{2})$ with $n=|V(G)|$, see [9, 13, 40, 41, 52]. It yields the partial order $P_{1},\dots,P_{m}$ of the prime modules of $G$ (line 5) in time $O(n)$ by depth first search. Then, we have to resolve each of the $m$ prime modules and in each step in the worst case all modules have to be merged stepwisely, resulting in an effort of $O(|\operatorname{\mathbb{P_{\max}}}(G[P_{p}])|)$ merging steps in each iteration. Since $m\leq n$ and $\Lambda\leq n$ we obtain $O(n^{2}h(G))$ as an upper bound. ∎

In practice, the exact computation of the optimal editing requires exponential effort. To be more precise, we show now the complexity $h(G)$ as in Lemma 5.6 using a naive brute-force method. Given a prime module $P$ with $\lambda=|\operatorname{\mathbb{P_{\max}}}(G[P])|$ child modules there are $\lambda\choose 2$ possibilities for selecting the first module pair that has to be merged. After merging those two modules there are at most $\lambda-1$ modules left from which possibly two more have to be merged. In general in the $i$-th merging step there are at most $\lambda-i\choose 2$ possible merge pairs left. This process have to repeat at most $(\lambda-4)$ times, since any module with less than four child modules cannot be prime. In the worst case this adds up to $\prod_{i=4}^{\lambda}{i\choose 2}=\prod_{i=4}^{\lambda}{\frac{i!}{2!(i-2)!}}=\prod_{i=4}^{\lambda}{\frac{i\cdot(i-1)}{2}}$ merge sequences per prime module of $G$ which gives $O((\lambda!)^{2})$ executions of get-module-pair() per prime module in $G$. Finding the optimal edit set for one merge operation of two modules $M_{1},M_{2}\in\operatorname{\mathbb{P_{\max}}}(G[P])$ requires checking the $2^{\lambda-2}$ combinations to add or remove edges to adjust the out${}_{M_{1}}$- and out${}_{M_{2}}$-neighbors w.r.t. to the remaining $\lambda-2$ modules. Therefore, for each of the remaining modules $M\in\operatorname{\mathbb{P_{\max}}}(G[P])\setminus\{M_{1},M_{2}\}$ there are either only edges or only non-edges between the vertices from $M$ and $M_{1}\cup M_{2}$. In summary, for a given prime module $P$ the graph $G[P]$ can be optimally edited to a cograph in $O((\lambda!)^{2}2^{\lambda})$ time. Therefore, with $\Lambda=\max_{P}|\operatorname{\mathbb{P_{\max}}}(G[P])|$ being the size of the largest maximal strong partition among all prime modules $P$ of $G$, it follows that $h(G)\in O((\Lambda!)^{2}2^{\Lambda})$. We note in passing that $\Lambda$ is always less than or equal to the maximum degree in the modular decomposition tree, which is also known as modular-width [18, 1]. Hence, the latter findings together with Lemma 5.6 imply the following

Observation 1**.**

The optimal cograph editing problem parameterized by the modular-width $k$ can be solved in $O((k!)^{2}2^{k}|V|^{2})$ time and thus, it is in FPT.

Practical heuristics for get-module-pair() and get-module-pair-edit() can be implemented to run in polynomial time. In particular, as a main result, we can observe that it is always possible to find an optimal edit set by stepwisely merging only pairs of modules. Based on this, we provide in the following several strategies to improve the runtime of these heuristics.

A simple greedy strategy yields a heuristic with $O(|V|^{3})$ time complexity as follows: In each call of get-module-pair() select the pair $(M_{i},M_{j})$ in $\mathcal{P}$ where the edit set that adjusts the out${}_{M_{i}}$- and out${}_{M_{j}}$-neighbors so that the out${}_{M_{i}\cup M_{j}}$-neighborhood becomes identical in $G^{\star}[P_{p}]$ has minimum cardinality. This minimum edit set can be obtained from get-module-pair-edit() by adjusting only the out-neighbors of the smaller module to be identical to the out-neighbors of the larger module. The pseudocode for this heuristic is given in Algorithm 2 which is, in fact, a natural extension of the exact Algorithm 1. A detailed numerical evaluation will be discussed elsewhere.

Lemma 5.7**.**

Algorithm 2 outputs a cograph and has a time complexity of $O(|V|^{3})$.

Proof.

First we show that Algorithm 2 constructs a cograph. To this end we show that in each iteration of the main for-loop (Lines 16 to 41) the corresponding prime module $P_{p}$ is edited such that the resulting subgraph $G^{\star}[P_{p}]$ is a cograph and $P_{p}$ is still a module of $G^{\star}$.

Due to the processing order of the prime modules $P_{1}$, …, $P_{m}$ constructed in Line 4, we may assume that, upon processing a prime module $P_{p}$, the induced subgraphs $G^{\star}[M],M\in\operatorname{\mathbb{P_{\max}}}(G[P_{p}])$ are already cographs and all $M$ are modules of $G^{\star}$. This holds in particular for the prime modules that do not contain any other prime module in the input graph $G$ and which, therefore, are processed first. Hence, it suffices to show that if all $G^{\star}[M]$, $M\in\operatorname{\mathbb{P_{\max}}}(G[P_{p}])$, are already cographs and all $M$ are modules in $G^{\star}$, then executing the $p-th$ iteration of the for-loop results in an updated intermediate graph $G^{\prime}$ with $G^{\prime}[P_{p}]$ being a cograph and $P_{p}$ as well as all modules $M\in\operatorname{\mathbb{P_{\max}}}(G[P_{p}])$ remain modules of $G^{\prime}$.

In Line 17, we define $\mathcal{P}=\operatorname{\mathbb{P_{\max}}}(G[P_{p}])$ and therefore, by assumption, all $G^{\star}[M]$, $M\in\mathcal{P}$ are cographs and all $M$ are modules of $G^{\star}$. In particular, the two sets $M_{i}$ and $M_{j}$ that are chosen first (in Line 20) are already cographs. Moreover, since $M_{i}$ and $M_{j}$ are modules of $G^{\star}$ if follows that $G^{\star}[M_{i}\cup M_{j}]$ is either the disjoint union G^{\star}[M_{i}]\mathbin{\mathchoice{\ooalign{\displaystyle\cup$\cr$\displaystyle\cdot}}{\ooalign{\textstyle\cup$\cr$\textstyle\cdot}}{\ooalign{\scriptstyle\cup$\cr$\scriptstyle\cdot}}{\ooalign{\scriptscriptstyle\cup$\cr$\scriptscriptstyle\cdot}}}G^{\star}[M_{j}] or the join $G^{\star}[M_{i}]\oplus G^{\star}[M_{j}]$ of $G^{\star}[M_{i}]$ and $G^{\star}[M_{j}]$. Thus, $G^{\star}[M_{i}\cup M_{j}]$ is already a cograph and none of the edges within $M_{i}\cup M_{j}$ is edited further. It remains to show that applying the edits constructed in Line 24 result in the (new) merged module $M_{i}\cup M_{j}$ of $G^{\star}\Delta\theta$. Note, if $M_{i}\cup M_{j}$ is already a module of $G^{\star}$ then Lines 22 to 26 are not executed and therefore, $\theta=\emptyset$, which implies that $M_{i}\cup M_{j}$ remains a module of $G^{\star}\Delta\theta$. On the other hand, if $M_{i}\cup M_{j}$ is no module of $G^{\star}$ then the for-loop in Lines 12 to 26 iterates over all modules $M_{k}$ in $\mathcal{P}\setminus\{M_{i},M_{j}\}$ and adjusts the edges between $M_{j}$ and $M_{k}$ to be in accordance to the edges between $M_{i}$ and $M_{k}$. Note that all those edits are within $P_{p}$. In particular, the out${}_{M_{i}\cup M_{j}}$-neighborhood was adjusted only between vertices from $M_{j}$ and vertices from $P_{p}\setminus(M_{i}\cup M_{j})$. After applying these edits, $M_{i}\cup M_{j}$ is therefore a module in $G^{\star}[P_{p}]\Delta\theta$. In particular, the out${}_{P_{p}}$-neighborhood has not changed and $P_{p}$ is therefore a module of $G^{\star}$ as well as of $G^{\star}\Delta\theta$. Then, it follows by Lemma 3.1 that $M_{i}\cup M_{j}$ is a module in $G^{\star}\Delta\theta$. To see that also all $M_{k}\in\mathcal{P}\setminus\{M_{i},M_{j}\}$ remain modules in $G^{\star}\Delta\theta$ note first that $\mathcal{P}$ is a partition of $P_{p}$ and second, that only edges between $M_{j}$ and $M_{k}$ are edited for some $M_{k}\in\mathcal{P}\setminus\{M_{i},M_{j}\}$. Moreover, if a (non)edge between $M_{j}$ and $M_{k}$ is edited, then all (non)edges $\{xy\mid x\in M_{j},y\in M_{k}\}$ between $M_{j}$ and $M_{k}$ are edited. Thus all $M_{k}\in\mathcal{P}\setminus\{M_{i},M_{j}\}$ remain modules of $G^{\star}[P_{p}]\Delta\theta$ and therefore modules $G^{\star}\Delta\theta$.

Now consider the prime module $P_{p+1}$ that is processed in the next iteration of the main for-loop. It can be easily seen that for $P_{p+1}$ we also have: $G^{\star}[M],M\in\operatorname{\mathbb{P_{\max}}}(G[P_{p+1}])$ is a cograph and all $M$ are modules of $G^{\star}$, since all prime modules of $G$ that are subsets of $P_{p+1}$ are already processed, and therefore, are all those $M$ are non-prime modules of $G^{\star}$ and form cographs $G^{\star}[M]$. Hence, by the same argumentation as before, $G^{\star}[P_{p+1}]$ is edited to a cograph by the next execution of the main for-loop. Thus, after processing all prime modules of $G$ the final graph $H$ is a cograph.

Next, we show that Algorithm 2 has a time complexity of $O(|V|^{3})$. Creating the modular decomposition in Line 3 can be done in linear time by the algorithms presented in, e.g., [13, 41, 52]. Note that “linear” in this context means linear in the number of edges, i.e., $O(|V|+|E|)\in O(|V|^{2})$. Initializing the matrices $A$ and $B$ (Lines 8 to 15) requires time $O(|V|^{3})$ since the corresponding for-loop iterates over every ordered set of 3 strong modules of $G$ and there are at most $O(|V|)$ such modules. Moreover, checking if the out-neighborhoods of two modules $M_{i}$ and $M_{j}$ w.r.t. a third module $M_{k}$ are identical (the if-statements in Lines 9 to 11) can be done in constant time by checking the adjacencies between three arbitrary vertices, exactly one from each of the three modules. For the remaining Lines 16 to 41 we can consider how often the inner while-loop (Lines 18 to 40) is executed. Therefore, note that within each execution always two modules are merged and there are $O(n)$ of those merge operations at most. This can most easily be seen by considering the matrix $A$ which has $\operatorname{MDs}(G)$ rows and columns at first with $|\operatorname{MDs}(G)|<|V|$. Each row, respectively each column, of $A$ represents a module that is possibly selected for merging. Moreover, within each iteration of the while-loop, the matrix $A$ is reduced by one row, respectively one column. This leads to no more than $|V|$ many executions of the while-loop. Selecting the two modules $M_{i}$ and $M_{j}$ in Line 20 requires $O(|V^{2}|)$ time. Although, the for-loop in Lines 23 to 25 is executed $O(|V|)$ times and each partial edit set that is computed in Line 24 might contain more than $O(|V|)$ many edits, the whole edit set $\theta$ (constructed within Lines 23 to 25) contains no more than $O(|V|^{2})$ edits. Thus, executing Lines 12 to 26 requires $O(|V|^{2})$ time at most. Adjusting the matrix $A$ is done in two steps. Lines 28 to 30 iterates over $O(|V|)$ many modules $M_{k}$ and Lines 32 to 34 iterates over $O(|V|^{2})$ many pairs of modules $(M_{k},M_{l})$. Shrinking the matrices $A$ and $B$ in Lines 35 and 36 can technically be done in time $O(|V|)$ if we use a labeling function $l\colon\mathbb{N}\times\mathbb{N}$ to index the values within the matrices, i.e., instead of reading $A_{ij}$ we read $A_{l(i),l(j)}$. Then we just have to relabel those indices, i.e., $l(x)\leftarrow l(x)+1$ for all $x>j$. In that way we do not have to remove anything from $A$ or $B$. Line 37 and 38 can also be done in $O(|V|)$ time and applying the edits in Line 39 requires at most $O(|V|^{2})$ time. In summary, executing a single iteration of the main for-loop requires $O(|V|^{2})$ time, which yields a total time complexity of $O(|V|^{3})$. ∎

The heuristic as given in Algorithm 2 is deterministic and therefore lacks of a randomization component which would be helpful in order to sample solutions and construct a consensus cograph. However, randomization can be introduced easily by selecting a pair of modules $M_{i}$ and $M_{j}$ in line 20 with a probability inversely correlated with the value of $A_{ij}\cdot|M_{j}|$. Moreover, with probability $p=|M_{i}|/(|M_{i}|+|M_{j}|)$ the edits $\{xy\mid x\in M_{j},y\in M_{k}\}$ can be selected in line 24 and otherwise $\{xy\mid x\in M_{i},y\in M_{k}\}$ with probability $1-p$.

An even simpler (but probably less accurate) heuristic with time complexity $O(|V|^{2})$ can be obtained by randomly selecting the next pair of modules $M_{i}$ and $M_{j}$ that have to be merged. Such a procedure would not require the computation of the matrices $A$ and $B$ at all. Nevertheless, this $O(|V|^{2})$-time heuristic requires that computing the edit set $\theta$ can be done in $O(|V|)$ time. However, this is possible if we only track the $O(|V|)$ many edits on the corresponding quotient graph $G^{\star}[P_{p}]/\operatorname{\mathbb{P_{\max}}}(G[P_{p}])$ and recover the $O(|V|^{2})$ many individual edits from that only once in a single post-processing step at the end.

Cograph editing heuristics based on the destruction of P4s requires $O(|V|^{4})$ time merely for enumerating all P4s. Thus, using module merges as editing operation may lead to significantly faster cograph editing heuristics.
