Mapping the circumstellar SiO maser emission in R Leo

TL;DR

This paper uses high-resolution interferometry to map SiO maser emissions around R Leo, revealing spatial distributions that challenge existing maser pumping theories and providing insights into the star's circumstellar environment.

Contribution

First detailed mapping of 29SiO v=0 J=1-0 emission in R Leo, comparing spatial distributions of multiple SiO maser lines at different frequencies.

Findings

28SiO v=2 maser is closer to the star than v=1.

86 GHz maser occurs in a farther shell than 43 GHz.

Observed distributions differ from theoretical predictions.

Abstract

The study of the innermost circumstellar layers around AGB stars is crucial to understand how these envelopes are formed and evolve. The SiO maser emission occurs at a few stellar radii from the central star, providing direct information on the stellar pulsation and on the chemical and physical properties of these regions. Our data also shed light on several aspects of the SiO maser pumping theory that are not well understood yet. We aim to determine} the relative spatial distribution of the 43 GHz and 86 GHz SiO maser lines in the oxygen-rich evolved star R Leo. We have imaged with milliarcsecond resolution, by means of Very Long Baseline Interferometry, the 43 GHz (28SiO v=1, 2 J=1-0 and 29SiO v=0 J=1-0) and 86 GHz (28SiO v=1 J=2-1 and 29SiO v=0 J=2-1) masing regions. We confirm previous results obtained in other oxygen-rich envelopes. In particular, when comparing the 43 GHz emitting regions, the 28SiO v=2 transition is produced in an inner layer, closer to the central star. On the other hand, the 86 GHz line arises in a clearly farther shell. We have also mapped for the first time the 29SiO v=0 J=1-0 emission in R Leo. The already reported discrepancy between the observed distributions of the different maser lines and the theoretical predictions is also found in R Leo.

Figures

Tables

Table 1. Table 1: Observed maser transitions and results of the fits.

specie	transition	restoring	$\overline{R}$	$△R$	center
		beam ($mas$${}^2$)	($mas$)	($mas$)	($X_c$,$Y_c$)
28SiO	$v$=1    $J$=1–0	0.78$\times$0.50	29.24	6.42	(26.9,–21.3)
	$v$=1    $J$=2–1	0.50$\times$0.50	33.84	4.20	(–35.2,–4.7)
	$v$=2    $J$=1–0	0.50$\times$0.50	25.92	6.88	(25.5,–16.3)
29SiO	$v$=0    $J$=1–0	0.78$\times$0.22	one spot	—	—
	$v$=0    $J$=2–1	non–det.	—	—	—

Full text

*Aims. *We aim to determine the relative spatial distribution of the 43 GHz and 86 GHz SiO maser lines in the oxygen-rich evolved star R Leo.

*Methods. *We have imaged with milliarcsecond resolution, by means of Very Long Baseline Interferometry, the 43 GHz (28SiO $v$=1, 2 $J$=1–0 and 29SiO $v$=0 $J$=1–0) and 86 GHz (28SiO $v$=1 $J$=2–1 and 29SiO $v$=0 $J$=2–1) masing regions.

*Results. *We confirm previous results obtained in other oxygen-rich envelopes. In particular, when comparing the 43 GHz emitting regions, the 28SiO $v$=2 $J$=1–0 transition is produced in an inner layer, slightly closer to the central star than the $v$=1 $J$=1–0. On the other hand, the 86 GHz 28SiO $v$=1 $J$=2–1 line arises in a clearly farther shell. We have also mapped for the first time the 29SiO $v$=0 $J$=1–0 emission in R Leo. The already reported discrepancy between the observed distributions of the different maser lines and the theoretical predictions is also found in R Leo.

††offprints: R. Soria-Ruiz

1 Introduction

Along the Asymptotic Giant Branch phase, many stars exhibit maser amplification in different molecular lines. In oxygen rich stars, [O]/[C]$>$1, O-bearing compounds are mainly formed and maser emission is presented in SiO, H2O and OH. The study of these different molecules provides information of the overall envelope, from the inner layers dominated by the stellar pulsation (SiO masers) to the outermost regions where the circumstellar material is expanding at constant velocity (OH masers).

The very long baseline interferometry is a unique technique to study the compact and very bright SiO emission, and therefore, it is particularly helpful in understanding the different and complex processes occuring in these inner regions of the envelope. On the other hand, the current models of pumping, either collisional or radiative, do not reproduce some characteristics of the SiO masers that have been observed, as for example, their relative location in the envelope. To test these models and constrain the physical parameters of these inner shells better, it is very useful to perform simultaneous observations of several maser transitions. For this reason, we have carried out multi-line and multi-epoch observations in a sample of AGB stars. We present in this paper the latest results for the Mira-type variable R Leo.

2 VLBA observations

The observations were made with the NRAO111The National Radio Astronomy Observatory is a facility of the National Science Foundation operated under cooperative agreement by Associated Universities, Inc. Very Long Baseline Array (VLBA) on 2002 december 7. Nearly simultaneous observations of different 43 GHz and 86 GHz 28SiO and 29SiO maser transitions were performed in the variable star R Leo. The 86 GHz lines were observed in between the two 43 GHz scans, and, therefore, we can assume for our purpouses that the observations were simultaneous.

The data correlation was done at the VLBA correlator located in Socorro (New Mexico). Left and right circular polarizations (LCP & RCP) were measured for the 28SiO $v$=1 and $v$=2 $J$=1–0 lines, whereas only the LCP was observed in the other transitions. Since no significant difference was found between the maps, less than 5%, the final image is the average of both polarizations.

Standard procedures for spectral line VLBI data reduction were followed in the calibration and production of the maps. The amplitude calibration was done using the system temperatures and antenna gain corrections for the 86 GHz and 29SiO data, and the template method for the other 43 GHz data. The phase errors were removed in a two-step process: first, the single-band delay corrections were derived from the continuum calibrators, OJ287 and 3C273. Second, the fringe-rates were estimated by selecting a bright and simple-structured channel; the corrections found were subsequently applied to the maser source. The maps were produced using the CLEAN deconvolution algorithm.

3 Results and Data Fits

The results are presented as follows (Figs. 1–2): for each observed line, we show the integrated emission map in Jy beam*-1* km s*-1* units (center panel), the spectrum of the cross-correlated emission for the different maser components (numbered panels), the total power spectrum (AC) of one of the VLBA antennas and of the emission in the map (XC) (upper-left panel), and the ratio of these two magnitudes (upper-right panel). We have also estimated the size of the total masing regions by fitting our data to rings. Only those components with SNR$\geq$6 have been included in the fits. The results derived from the calculations are summarized in Table 1: characteristic ring radius ($\bar{R}$), ring width ($\triangle{R}$) and center of the ring ($X_{\rm c}$,$Y_{\rm c}$) (see details on the fitting process in Soria-Ruiz et al., 2005). In particular, the angular sizes derived for the 28SiO $v$=1 and $v$=2 $J$=1–0 regions (Table 1) are compatible with previous observations performed in R Leo by Cotton et al. (2004). Among the six transitions observed only the 29SiO $v$=0 $J$=2–1 has not been detected. A more detailed description of the maps is given in the subsequent section.

4 Relative spatial distribution and pumping mechanisms

Our maps show that the spatial distribution of the $v$=1 and $v$=2 maser spots is similar although not all the components appear in both transitions (Fig. 1). Concerning the relative location of the 43 GHz 28SiO maser layers, the $v$=2 emission is produced in a closer region of the envelope, assuming that the centroids of all the emissions are coincident. This is also consistent with previously reported results in other oxygen rich envelopes (see e.g. Desmurs et al., 2000; Cotton et al., 2004; Soria-Ruiz et al., 2004, 2005). In contrast to the 43 GHz regions, this first map of the 28SiO $v$=1 $J$=2–1 emission in R Leo reveals that the components of this maser line are situated in a significantly outer region of the envelope, with a very different spot distribution. Since the $J$=2–1 emission has been imaged only in a very few sources, this result in R Leo is particularly important to test the proposed SiO maser mechanisms. Finally, the 29SiO $v$=0 $J$=1–0 map consisted of one maser spot, thus making difficult to derive any spatial information. The total power and recovered emission are shown in Figure 2.

Current pumping models, either radiative (Bujarrabal, 1994a, b) or collisional (Humphreys et al., 2002), predict that the different rotational maser lines within the same vibrational state are produced under similar conditions and therefore are expected to be located in the same region of the envelope. As previously mentioned, we find a contradiction between these theoretical predictions and our observational results. This discrepancy has also been observed in other oxygen-rich stars; IRC +10011 (Soria-Ruiz et al., 2005) and TX Cam (Soria-Ruiz et al., 2006). Further calculations of the excitation of the SiO molecule in AGB stars have shown that the conditions under which the different maser transitions occur change drastically when the line overlap between infrared lines of H2O and 28SiO is introduced in the pumping models (Bujarrabal et al., 1996; Soria-Ruiz et al., 2004); such a mechanism could explain the lack of coincidence between the spots of different $J$–transitions within a vibrational state.

Nevertheless, although these new maps support the relevance of line overlaps in the SiO maser pumping in O–rich shells, we think that similar studies should be performed in a larger number of evolved stars. In particular, it would be necessary to have data on all types of long-period variable stars, namely, Mira-type, semirregular and irregular variables, as well as supergiant stars.

Acknowledgements.

This work has been financially supported by the Spanish DGI (MCYT) under projects AYA2000-0927 and AYA2003-7584. All plots have been made using the GILDAS software package (http://www.iram.fr/IRAMFR/GILDAS).
